Intel to AMD, MBR to GPT, Secure Boot Windows UEFI + CSM Disabled BSOD

Question

• Build this computer in 2016 using Intel and Windows 7
• At some point I upgraded to Windows 10
• In 2021 I swapped Intel for AMD
• I did not do a fresh install of Windows 10
• Recently I wanted to upgrade to Windows 11
• I enabled TMP 2.0
• I used mbr2gpt and after some troubleshooting I managed to switch my drive to GPT
• Upgraded to Windows 11 successfully
• However I cannot boot into my system if I enable Secure Boot Windows UEFI in my BIOS
• I am met with two bluescreen issues:
  • 1: "A required device isn't connected or can't be accessed. 0xc000025"
  • 2: "The operating system couldn't be loaded... File: \windows\system32\DRIVERS\iaStorF.sys Error code: 0xc0000428"
• If I choose "Other OS" in my motherboard Secure Boot settings I can boot into windows successfully
• I have tried to rename and even disable "iaStorF.sys" but doing both will prompt me with a BSOD QR code error

Minidump issue:

My minidump never writes BSOD errors unless they happen while I am in Windows. If I BSOD before entering Windows I do not see a dump file in my minidump folder

AMD Ryzen 5600x

NVIDIA RTX 4070 Super

B550-F Gaming

All graphical, chipset, and motherboard firmware drivers are completely up to date.

Windows 11 is up to date as well.

Answer 1

Hello

Have we verified present device hardware is compatible with Windows 11(the device manufacturer website has the Windows 11 driver for this machine model)?

"iaStorF.sys" refers to " Intel Rapid Storage Technology driver". Try to download the latest verison from the intel website.

Anyway, I found a similar case. A fresh install may be an option. Or we may consider to work with secure boot disabled.

‎Fresh Windows10 install fails with IAstoravc.sys problem | DELL Technologies

Answer 2

Hello

Is your problem solved?

If the above reply is helpful to you, please mark your reply as an answer, thank you very much!

If you have any further questions, please do not hesitate to contact us.

Thanks
