ProvisioningState VM Faild, schedule Start
Surapally Sravan Kumar
0
Reputation points
VM has automation scheduled auto start but it failed status we did reapply and redeploy also still same issue and I tried to open Microsoft case but we do not have scope of create a ticket please look into this issue
Azure Virtual Machines
{count} votes
-
Lijitha B 515 Reputation points Moderator2024-10-29T18:37:52.68+00:00 Welcome to the Microsoft Q&A Platform! Thank you for asking your question here.
Could you please confirm are you using Automation scripting in azure? if you provide a more information, it could be very helpful to identify the issue and resolve it.
-
Surapally Sravan Kumar 0 Reputation points
2024-10-30T06:52:52.6366667+00:00 @Lijitha B am using power shell script for the VM auto start through the automation account, when it runs it start but VM went to failed status
-
Lijitha B 515 Reputation points Moderator
2024-10-30T14:41:55.6866667+00:00 Hi Surapally Sravan Kumar,Thanks for your response.As you have mentioned, you are using a custom PowerShell script for VM auto-start through the automation account, please note that the issue is out of our scope. Hope you understand!
Thank you.
-
Surapally Sravan Kumar 0 Reputation points
2024-11-08T08:01:21.18+00:00 @Lijitha B it was configured long back of auto start the VMs through automation account last few days we getting this issue some times it working , I feel it issue on VM side not powershell script , Is possible to provide to log a ticket for this
-
Prrudram-MSFT 28,371 Reputation points Microsoft Employee Moderator2024-11-12T13:12:45.7166667+00:00 Hello @Surapally Sravan Kumar
I see you have already tried redeploy the VM and the state of the VM remained same. Please run an Update command using the CloudShell from Azure Portal.
az vm update -n <VMName> -g <ResourceGroupname>Possible Cause: This seems to be a guest agent issue. This retryable error is due to VM guest agent not responding.
If the above command brings back your VM to normal state. Please check the status of VM guest. Ensure the guest agent is up-to-date. If not, you need to make sure the the VM guest agent is updated by following this document
https://learn.microsoft.com/en-us/azure/virtual-machines/extensions/agent-windows#detect-the-azure-windows-vm-agent
Important:
Ensure that your VM has access to IP address 168.63.129.16 for the VM guest agent to communciate probably with azure backend. For more information, see What is IP address 168.63.129.16?.Ensure that DHCP is enabled inside the guest VM. This is required to get the host or fabric address from DHCP for the Azure Windows VM Agent and extensions to work. If you need a static private IP address, you should configure it through the Azure portal or PowerShell, and make sure the DHCP option inside the VM is enabled. Learn more about setting up a static IP address by using PowerShell.
Let me know the status. If none of this helps, we can get you help to log a support ticket.
-
Lijitha B 515 Reputation points Moderator
2024-11-13T09:11:23.09+00:00 Is the information provided by Prrudram-MSFT helpful? If you have any further queries, please feel free to let us know.
-
Lijitha B 515 Reputation points Moderator
2024-11-15T07:36:08.7933333+00:00 Hope you are doing well.
I just wanted to check if the information provided by Prrudram-MSFT above has resolved your query. If you have any further questions, please feel free to reach out.
