Description of the Problem
Hello,
I am suing the AKS-Construction Helper (https://github.com/Azure/AKS-Construction) to deploy a public azure kubernetes cluster. At the end, I get the following command and parameters file:
az deployment group create -g alfred-butler-dev-rg --template-uri https://github.com/Azure/AKS-Construction/releases/download/0.10.7/main.json --parameters \
resourceName=my-aks-dev\
managedNodeResourceGroup=my-managed-aks-dev-rg \
kubernetesVersion=1.32.4 \
agentCount=5 \
upgradeChannel=stable \
agentCountMax=10 \
osDiskType=Managed \
osDiskSizeGB=32 \
custom_vnet=true \
enable_aad=true \
AksDisableLocalAccounts=true \
enableAzureRBAC=true \
adminPrincipalId=$(az ad signed-in-user show --query id --out tsv) \
registries_sku=Basic \
acrPushRolePrincipalId=$(az ad signed-in-user show --query id --out tsv) \
azureFirewalls=true \
certManagerFW=true \
enableNodePublicIP=true \
omsagent=true \
retentionInDays=90 \
containerLogsV2BasicLogs=true \
serviceMeshProfile=NaN \
azurepolicy=audit \
podCidr=10.240.100.0/24 \
cniDynamicIpAllocation=true \
dnsZoneId=/subscriptions/72467751-07c0-46cb-8104-517f3e9cfd63/resourceGroups/civilia-dev-dns-rg/providers/Microsoft.Network/dnszones/dev-civilia.ca \
ingressApplicationGateway=true \
appGWcount=8 \
appGWsku=WAF_v2 \
appGWmaxCount=20 \
appgwKVIntegration=true \
keyVaultKmsCreate=true \
keyVaultKmsOfficerRolePrincipalId=$(az ad signed-in-user show --query id --out tsv) \
keyVaultAksCSI=true \
keyVaultCreate=true \
keyVaultOfficerRolePrincipalId=$(az ad signed-in-user show --query id --out tsv) \
oidcIssuer=true \
workloadIdentity=true \
enableSysLog=true
when I connect to the created cluster and check the pods in the kube-system namespace; I get the following:
kubectl get pods -o wide --namespace kube-system NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES aks-secrets-store-csi-driver-75kgs 2/3 CrashLoopBackOff 28 (3m42s ago) 54m 10.240.100.95 aks-userpool01-68104822-vmss000001 <none> <none> aks-secrets-store-csi-driver-hx8h5 1/3 CrashLoopBackOff 29 (3m17s ago) 58m 10.240.100.19 aks-agentpool-30311657-vmss000000 <none> <none> aks-secrets-store-csi-driver-qx4rg 2/3 CrashLoopBackOff 28 (4m25s ago) 54m 10.240.100.58 aks-userpool01-68104822-vmss000000 <none> <none> aks-secrets-store-csi-driver-wpgn6 2/3 CrashLoopBackOff 28 (4m37s ago) 54m 10.240.100.84 aks-userpool01-68104822-vmss000003 <none> <none> aks-secrets-store-csi-driver-x6dt8 1/3 CrashLoopBackOff 27 (3m44s ago) 53m 10.240.100.106 aks-userpool01-68104822-vmss000004 <none> <none> aks-secrets-store-csi-driver-x8bq4 2/3 CrashLoopBackOff 28 (4m17s ago) 54m 10.240.100.51 aks-userpool01-68104822-vmss000002 <none> <none> aks-secrets-store-provider-azure-c57hs 1/1 Running 0 54m 10.240.0.9 aks-userpool01-68104822-vmss000001 <none> <none> aks-secrets-store-provider-azure-h2rl5 1/1 Running 0 54m 10.240.0.7 aks-userpool01-68104822-vmss000002 <none> <none> aks-secrets-store-provider-azure-l5scf 1/1 Running 0 58m 10.240.0.4 aks-agentpool-30311657-vmss000000 <none> <none> aks-secrets-store-provider-azure-txqkz 1/1 Running 0 54m 10.240.0.6 aks-userpool01-68104822-vmss000003 <none> <none> aks-secrets-store-provider-azure-wzsmn 1/1 Running 0 53m 10.240.0.5 aks-userpool01-68104822-vmss000004 <none> <none> aks-secrets-store-provider-azure-xbn44 1/1 Running 0 54m 10.240.0.8 aks-userpool01-68104822-vmss000000 <none> <none> ama-logs-5r878 2/2 Running 0 54m 10.240.100.76 aks-userpool01-68104822-vmss000003 <none> <none> ama-logs-c8j4w 2/2 Running 0 53m 10.240.100.109 aks-userpool01-68104822-vmss000004 <none> <none> ama-logs-drpzj 2/2 Running 0 57m 10.240.100.30 aks-agentpool-30311657-vmss000000 <none> <none> ama-logs-l66xn 2/2 Running 0 54m 10.240.100.94 aks-userpool01-68104822-vmss000001 <none> <none> ama-logs-rs-78d658c9-tfkh7 1/1 Running 0 57m 10.240.100.13 aks-agentpool-30311657-vmss000000 <none> <none> ama-logs-tpxdj 2/2 Running 0 54m 10.240.100.62 aks-userpool01-68104822-vmss000000 <none> <none> ama-logs-zz7xd 2/2 Running 0 54m 10.240.100.39 aks-userpool01-68104822-vmss000002 <none> <none> azure-cns-8z68p 1/1 Running 0 54m 10.240.0.7 aks-userpool01-68104822-vmss000002 <none> <none> azure-cns-9ztdr 1/1 Running 0 54m 10.240.0.6 aks-userpool01-68104822-vmss000003 <none> <none> azure-cns-fdmtr 1/1 Running 0 54m 10.240.0.8 aks-userpool01-68104822-vmss000000 <none> <none> azure-cns-g6ssq 1/1 Running 0 58m 10.240.0.4 aks-agentpool-30311657-vmss000000 <none> <none> azure-cns-jdgpt 1/1 Running 0 54m 10.240.0.9 aks-userpool01-68104822-vmss000001 <none> <none> azure-cns-tlgf5 1/1 Running 0 53m 10.240.0.5 aks-userpool01-68104822-vmss000004 <none> <none> azure-policy-86887785db-k885d 1/1 Running 0 60m 10.240.100.24 aks-agentpool-30311657-vmss000000 <none> <none> azure-policy-webhook-6fbc657745-9jddk 0/1 CrashLoopBackOff 9 (4m21s ago) 27m 10.240.100.104 aks-userpool01-68104822-vmss000004 <none> <none> azure-wi-webhook-controller-manager-58bf869886-6gdll 0/1 CrashLoopBackOff 15 (2m33s ago) 57m 10.240.100.25 aks-agentpool-30311657-vmss000000 <none> <none> azure-wi-webhook-controller-manager-58bf869886-tjb4d 0/1 CrashLoopBackOff 15 (2m26s ago) 57m 10.240.100.22 aks-agentpool-30311657-vmss000000 <none> <none> cloud-node-manager-d2lf8 1/1 Running 0 54m 10.240.0.6 aks-userpool01-68104822-vmss000003 <none> <none> cloud-node-manager-pj9sq 1/1 Running 0 58m 10.240.0.4 aks-agentpool-30311657-vmss000000 <none> <none> cloud-node-manager-s5j29 1/1 Running 0 54m 10.240.0.7 aks-userpool01-68104822-vmss000002 <none> <none> cloud-node-manager-tsjvv 1/1 Running 0 54m 10.240.0.8 aks-userpool01-68104822-vmss000000 <none> <none> cloud-node-manager-z2zpg 1/1 Running 0 54m 10.240.0.9 aks-userpool01-68104822-vmss000001 <none> <none> cloud-node-manager-zc2mw 1/1 Running 0 53m 10.240.0.5 aks-userpool01-68104822-vmss000004 <none> <none> coredns-77f74c584-2slsm 0/1 Running 0 60m 10.240.100.7 aks-agentpool-30311657-vmss000000 <none> <none> coredns-autoscaler-79bcb4fd6b-l9k2q 1/1 Running 22 (5m28s ago) 60m 10.240.100.14 aks-agentpool-30311657-vmss000000 <none> <none> csi-azuredisk-node-fc5b9 3/3 Running 0 54m 10.240.0.7 aks-userpool01-68104822-vmss000002 <none> <none> csi-azuredisk-node-fw45w 3/3 Running 0 54m 10.240.0.8 aks-userpool01-68104822-vmss000000 <none> <none> csi-azuredisk-node-jvtmx 3/3 Running 0 53m 10.240.0.5 aks-userpool01-68104822-vmss000004 <none> <none> csi-azuredisk-node-nk7gk 3/3 Running 0 58m 10.240.0.4 aks-agentpool-30311657-vmss000000 <none> <none> csi-azuredisk-node-ttpj8 3/3 Running 0 54m 10.240.0.9 aks-userpool01-68104822-vmss000001 <none> <none> csi-azuredisk-node-zkzpv 3/3 Running 0 54m 10.240.0.6 aks-userpool01-68104822-vmss000003 <none> <none> csi-azurefile-node-7fdzf 3/3 Running 0 54m 10.240.0.6 aks-userpool01-68104822-vmss000003 <none> <none> csi-azurefile-node-8mhbt 3/3 Running 0 54m 10.240.0.7 aks-userpool01-68104822-vmss000002 <none> <none> csi-azurefile-node-8w2pd 3/3 Running 0 58m 10.240.0.4 aks-agentpool-30311657-vmss000000 <none> <none> csi-azurefile-node-kcrsv 3/3 Running 0 54m 10.240.0.9 aks-userpool01-68104822-vmss000001 <none> <none> csi-azurefile-node-l5nkt 3/3 Running 0 54m 10.240.0.8 aks-userpool01-68104822-vmss000000 <none> <none> csi-azurefile-node-w6mpb 3/3 Running 0 53m 10.240.0.5 aks-userpool01-68104822-vmss000004 <none> <none> ingress-appgw-deployment-5c9c7bbdbc-jwgsm 0/1 CrashLoopBackOff 19 (4m37s ago) 60m 10.240.100.16 aks-agentpool-30311657-vmss000000 <none> <none> konnectivity-agent-7ccd6c6945-vfl72 0/1 Running 2 (2m27s ago) 8m27s 10.240.100.54 aks-userpool01-68104822-vmss000000 <none> <none> konnectivity-agent-autoscaler-844df78bbd-bl2w7 0/1 CrashLoopBackOff 4 (47s ago) 3m27s 10.240.100.33 aks-agentpool-30311657-vmss000000 <none> <none> kube-proxy-chrrl 1/1 Running 0 58m 10.240.0.4 aks-agentpool-30311657-vmss000000 <none> <none> kube-proxy-kslf5 1/1 Running 0 53m 10.240.0.5 aks-userpool01-68104822-vmss000004 <none> <none> kube-proxy-lbf4z 1/1 Running 0 54m 10.240.0.9 aks-userpool01-68104822-vmss000001 <none> <none> kube-proxy-lsrqm 1/1 Running 0 54m 10.240.0.8 aks-userpool01-68104822-vmss000000 <none> <none> kube-proxy-mfkgf 1/1 Running 0 54m 10.240.0.7 aks-userpool01-68104822-vmss000002 <none> <none> kube-proxy-txpsl 1/1 Running 0 54m 10.240.0.6 aks-userpool01-68104822-vmss000003 <none> <none> metrics-server-6c47bdccfd-fwgjc 1/2 CrashLoopBackOff 15 (2m32s ago) 60m 10.240.100.8 aks-agentpool-30311657-vmss000000 <none> <none> metrics-server-6c47bdccfd-kjdsz 1/2 CrashLoopBackOff 15 (2m13s ago) 60m 10.240.100.10 aks-agentpool-30311657-vmss000000 <none> <none>
It turns out all the failing deployments and their corresponding pods are due to failing readiness and liveness probes (like the following logs from the ingress-appgw deployment):
Events: Type Reason Age From Message
Warning FailedScheduling 59m (x17 over 62m) default-scheduler no nodes available to schedule pods Warning FailedScheduling 59m default-scheduler 0/1 nodes are available: 1 node(s) had untolerated taint {node.cloudprovider.kubernetes.io/uninitialized: true}. preemption: 0/1 nodes are available: 1 Preemption is not helpful for scheduling. Normal Scheduled 59m default-scheduler Successfully assigned kube-system/ingress-appgw-deployment-5c9c7bbdbc-jwgsm to aks-agentpool-30311657-vmss000000 Normal Pulling 59m kubelet Pulling image "mcr.microsoft.com/azure-application-gateway/kubernetes-ingress:1.8.1" Normal Pulled 59m kubelet Successfully pulled image "mcr.microsoft.com/azure-application-gateway/kubernetes-ingress:1.8.1" in 1.586s (1.586s including waiting). Image size: 27686229 bytes. Warning Unhealthy 56m (x8 over 59m) kubelet Liveness probe failed: Get "http://10.240.100.16:8123/health/alive": dial tcp 10.240.100.16:8123: connect: connection refused Normal Created 54m (x6 over 59m) kubelet Created container: ingress-appgw-container Normal Started 54m (x6 over 59m) kubelet Started container ingress-appgw-container Normal Killing 14m (x17 over 58m) kubelet Container ingress-appgw-container failed liveness probe, will be restarted Warning Unhealthy 14m (x114 over 59m) kubelet Readiness probe failed: Get "http://10.240.100.16:8123/health/ready": dial tcp 10.240.100.16:8123: connect: connection refused Warning BackOff 4m15s (x166 over 53m) kubelet Back-off restarting failed container ingress-appgw-container in pod ingress-appgw-deployment-5c9c7bbdbc-jwgsm_kube-system(522153dc-3909-4fb8-af56-44e2e6d90c91) Normal Pulled 70s (x20 over 58m) kubelet Container image "mcr.microsoft.com/azure-application-gateway/kubernetes-ingress:1.8.1" already present on machine
I also noticed that the following command fails for any pod (i have to describe the pod to get the logs instead):
kubectl logs ingress-appgw-deployment-5c9c7bbdbc-jwgsm --namespace kube-system Error from server: Get "https://10.240.0.4:10250/containerLogs/kube-system/ingress-appgw-deployment-5c9c7bbdbc-jwgsm/ingress-appgw-container": EOF
Did anyone get these issues? I am confused and stuck to find a solution. Thanks.
Hi Aniss Chohra,
The error indicates that the Kubelet API on the node (port 10250) is not responding properly. It's a node-level issue, not a problem with the pod itself.
When you run kubectl logs, the API server proxies the request to the Kubelet on the node where the pod is running, over HTTPS on port 10250.
If that fails with an EOF (End of File), it means the Kubelet is not serving logs properly or the API server can't establish a full TLS connection with the Kubelet
Kubelet is unhealthy due to a NotReady node, taint issues, or broken cloud node manager or networking.
TLS cert mismatch or bootstrap failure prevents the Kubelet from authenticating or accepting requests, often due to cloud-init issues, custom VNETs, or faulty Azure extensions.
CNI or networking issues, especially in custom VNET setups, may block traffic to port 10250 due to restrictive network rules or NSGs.
Broken image or VMSS nodes if the node image is corrupted or the bootstrapping failed, the kubelet may be running but not fully functional
Check the Node State that the logs show messages related to nodes not being available for scheduling. You can check the status of your nodes by running kubectl get nodes -o wide to ensure they are in a Ready state and taints like node.cloudprovider.kubernetes.io/uninitialized: true. If they are in NotReady, investigate further using kubectl describe node <node-name> to look for any specific error messages.
SSH Into the Node (if allowed)
If you're using a custom VNET and enabled public IPs or Azure Bastion, try:
az aks ssh -n <cluster-name> -g <resource-group> --node <node-name>
Then on the node:
sudo journalctl -u kubelet -f
This will show you what's going wrong with the kubelet.
Run Logs via kubectl describe as a fallback since kubectl logs is failing, you can get some hints from:
kubectl describe pod <pod-name> -n kube-system
Restart the Node (if not too disruptive) and if you can afford to, try cordoning and restarting the problematic node:
kubectl cordon <node-name>
kubectl drain <node-name> --ignore-daemonsets --delete-emptydir-data
In Azure:
az vmss restart --name <vmss-name> --resource-group <rg-name>
Then uncordon:
kubectl uncordon <node-name>
Deploy a Minimal Cluster to Compare if this persists and blocks everything, spin up a simpler AKS cluster without custom_vnet, ingressApplicationGateway, azurepolicy, workloadIdentity
Then confirm if logging works. This will confirm whether it's the base AKS config or an integration (e.g., CSI or AGIC) causing node corruption.
https://learn.microsoft.com/en-us/azure/aks/node-access
https://learn.microsoft.com/en-us/azure/aks/kubelet-logs
https://www.kubernet.dev/troubleshooting-kubernetes-node-not-ready-errors-a-comprehensive-guide/
If you found information helpful, please click "Upvote" on the post to let us know any further queries feel free to reach out us we are happy to assist you.
Thank You.
@Pramidha Yathipathi I just checked the state of all nodes and they are all in ready state. My first intuition here is that it might be as you mentioned related to a networking issue (VNET config, maybe firewall block? ). Do you have any idea on where to start looking? These are the firewall rules in case:
Also, below is our VNET configuration:
and our nodes status:
Hi Aniss Chohra,
Based on CrashLoopBackOff & Network Clues the azure-wi-webhook-controller fails because it's unable to serve HTTPS (via Mutating Webhook) or talk to the Kubernetes API Server due to:
Missing webhook TLS secret
CNI/VNET misrouting
NSG/firewall blocking port 443, 10250, or 6443 (API server)
Validation Checklist for Networking/VNET Issues Webhook Service DNS Resolution & Connectivity from inside a pod (busybox or alpine) in the cluster:
kubectl run tmp-shell --rm -i --tty --image=alpine -- /bin/sh
apk add curl bind-tools
Check DNS resolution of the webhook service
nslookup azure-wi-webhook.kube-system.svc.cluster.local
Test connectivity to the webhook service (mutating/validating webhook)
curl -v https://azure-wi-webhook.kube-system.svc:443 --insecure
If this fails — the service is unreachable, misconfigured, or blocked by CNI rules or firewall/NSG.
Check your NSG Rules (Azure Portal or CLI):
Ensure that inbound/outbound rules allow:
From AKS subnet to:
Port 443 (for HTTPS webhook)
Port 6443 (Kubernetes API Server)
Port 10250 (Kubelet)
Between pods and services within the cluster VNET or you can validate with CLI:
az network nsg list-effective --vm-name <node-name> --resource-group <rg-name>
Look for NSG rules that might block intra-node or pod-to-node traffic.
Check Pod IP Routing if inside a failing pod (if you can catch it running before it crashes):
kubectl exec -n kube-system <azure-wi-webhook-pod> -- sh -c "ip route"
Ensure the pod has a route to the kube-system service CIDR and a default gateway, as misconfigured CNI plugins—especially in custom VNETs—can cause misrouted or blackholed traffic, leading to webhook unreachability.
Check if the webhook pod exposes the expected port
kubectl get svc -n kube-system azure-wi-webhook
kubectl describe svc -n kube-system azure-wi-webhook
Please share the failed pods describe to get the detailed information.
kubectl describe pod <podname> -n kube-system
https://learn.microsoft.com/en-us/azure/firewall/protect-azure-kubernetes-service
If you found information helpful, please click "Upvote" on the post to let us know any further queries feel free to reach out us we are happy to assist you.
Thank You.
Hi Aniss Chohra,
Just checking in to see if you had a chance to review the latest comment on your question. Feel free to reach out if you have any further queries.
If you found the information helpful, please click "Upvote" on the post to let us know.
Thank You.
Hello @Pramidha Yathipathi I re-deployed the AKS cluster without the advanced networking options and the firewall but keeping the CNI for networking; so I removed the separate VNets and used only one, removed the firewall and kept the App gateway. Now I am able to see that all the deployments in kube-system are working and ready, and I am also able to retrieve the logs of any pod using kubectl logs <pod-name> --namespace <namespace>. So the issue comes definitely from the firewall or the usage of different VNets that require more advanced firewall rules in addition to the ones in place. Any idea on how to change these firewall rules and fix the issue? because even though the current basic setting is working without a firewall, we would like later in our production environment to have an Azure Firewall setup and separate VNets for more robust security. I attached earlier screenshots about these firewall rules.
Hi Aniss Chohra,
Just checking in to see if you have got a chance to review the comment provided by "Pramidha Yathipathi" response to your question in resolving the issue.
If it was helpful, please click "Upvote" on this post to let us know.
Thank You.
Hi Aniss Chohra,
Just checking in to see if you have got a chance to review the comment provided by "Pramidha Yathipathi" response to your question in resolving the issue.
If it was helpful, please click "Upvote" on this post to let us know.
Thank You.
Hi Aniss Chohra,
Gather IP ranges: Collect the IP ranges for
AKS node subnet
Pod CIDR ranges (from your AKS cluster config)
Application Gateway subnet
Other VNets/subnets peered
Check peering configs: Confirm peering allows forwarded traffic.
Create/adjust firewall rules:
Create Network Rules to allow traffic between these IP ranges on required ports.
Create Application Rules or Network Rules for outbound traffic to Azure services.
Use service tags where possible to simplify.
Use Azure Firewall Diagnostic Logs
Enable diagnostics to see what traffic is blocked.
Analyze the logs to pinpoint which IPs or ports are being denied.
Adjust rules accordingly.
https://learn.microsoft.com/en-us/azure/aks/limit-egress-traffic?tabs=aks-with-system-assigned-identities
https://learn.microsoft.com/en-us/azure/architecture/guide/aks/aks-firewall
If you found information helpful, please click "Upvote" on the post to let us know any further queries feel free to reach out us we are happy to assist you.
Thank You.
