Hello!
I have an on-premise Exchange 2016 environment with one Edge and one Mailbox server. There is an EdgeSync between two server, but I don't know, how to identify which certificate use the EdgeSync. How can I check it?
Thanks.
Thank You for Your post. I have an internal certificate from our internal CA, but the Subject field contain only the Edge server name, but the Friendly Name field contain the following: Edge Subscription
Is this the certificate which use for EdgeSync?
Hi @adam900331 ,
Do you mean the you replaced the self-signed certificate with your own cert?
If you open the Edge Subscription fil which was created with New-EdgeSubscription -FileName cmdlet, and you will see the following parameters.
And form the following picture we could know the Self-signed certificate will be used for EdgeSync.
Which means the certificate will not be used for EdgeSync, it will use a special self-signed certificate.
Moreover, I think the the CA certificate you created will be used for mail routing, as you could see the two send connectors after deploying Edge Subscription.
The pictures are from: https://learn.microsoft.com/en-us/exchange/edge-subscription-credentials-exchange-2013-help
Regards,
Lou
Hi @adam900331 ,
Do the suggestions above help? If the issue has been resolved, please click “Accept as answer” to mark helpful reply as an answer, this will make answer searching in the forum easier and be beneficial to other community members as well.
Regards,
Lou
If the response is helpful, please click "Accept Answer" and upvote it.
Note: Please follow the steps in our documentation to enable e-mail notifications if you want to receive the related email notification for this thread.
Hi @adam900331 ,
It has been a long time since last reply, did these suggestions help you? If the above suggestion helps, please click “Accept as answer” to mark helpful reply as an answer.Your action would be helpful to other users who encounter the same issue and read this thread.
Regards,
Lou
If the response is helpful, please click "Accept Answer" and upvote it.
Note: Please follow the steps in our documentation to enable e-mail notifications if you want to receive the related email notification for this thread.
Hi @adam900331 ,
Simply run Get-ExchangeCertificate on Edge server.
This self-signed certificate will be used for EdgeSubscription.
If you want to renew the certificate, this article may help you: SMTP certificate renewal and EDGE subscription
Please Note: Since the web site is not hosted by Microsoft, the link may change without notice. Microsoft does not guarantee the accuracy of this information.
Regards,
Lou
