I connected WABA to ACS , is working , i can send message using the ACS with Javascript to my number. So basically WABA is OK , ACS is OK.
When i connect it to copilot studio ( i did like 15 times , recreated Agent , Recreated ACS , i try to unbind and bind it again a lot of times) i always get the same error.
"**Something unexpected happened. We're looking into it."
Cant find how to fix it , anyone can help me ?
**
Hello Ronan Vico,
From your description and the error log, it appears that your WhatsApp Business Account (WABA) and Azure Communication Services (ACS) are functioning separately, but when you attempt to connect ACS to Copilot Studio, you receive the error: "Something unexpected happened. We're looking into it."
This issue is fairly common when integrating ACS with Copilot Studio and is often due to configuration or permission settings. Here’s a troubleshooting guide to help you resolve it:
"Did you configure the account in the Copilot admin center and update the endpoint URL for the webhook in the Event section for the ACS resource?
You'll also need the ACS WhatsApp number channel id as a filter and will have to use Entra Authentication using an Azure App."
can you explain that ? I have the eventsubscription On and running , where should i go to update the endpoint that is not at the docs.
Hello Ronan Vico - Here’s a step-by-step guide on how to configure each part:
Set Up the Account in Copilot Admin Center
Go to the Microsoft Copilot Studio Admin Center.
In the Channels or Connections section, add or configure your Azure Communication Services (ACS) WhatsApp channel.
Enter the correct ACS resource and WhatsApp number or channel details.
Update the Webhook Endpoint URL in the Event Section for the ACS Resource
Open the Azure Portal and select your ACS resource.
Navigate to Events or Event Grid, then find your Event Subscription for WhatsApp messages.
Edit the Webhook endpoint URL so that it points to your Copilot Studio bot’s endpoint (for example: https://whatsapp.botframework.com/api/v1/bots/<bot-id>).).
This will ensure WhatsApp messages are sent to your Copilot Studio agent.
Apply the ACS WhatsApp Number Channel ID as a Filter
Within the Event Subscription settings, add filters to only trigger events for your specific WhatsApp number or channel.
Look for Filters or Advanced Filters and set it to match your WhatsApp channel ID.
Enable Entra Authentication (Azure AD App Registration)
Register an Azure AD (Entra) App in the Azure Portal.
Grant the necessary permissions for both ACS and Copilot Studio.
In your ACS Event Subscription, set the authentication type to Azure AD, and provide the App (client) ID and tenant ID.
This secures the webhook so only authenticated requests are processed.
Where to Update the Endpoint:
In the Azure Portal, under your ACS resource, go to Events > Event Grid System Topics > your topic > Event Subscriptions.
Edit the event subscription and update the Webhook URL to your Copilot Studio bot endpoint.
EventSubscription is On.
Yes i did all the steps from tutorial and videos from Microsoft.
Event subscription is running.
That part below is not at the documentation , where is this part at the microsoft docs ? Everything should go automatically ... Thats what they said at the Youtube video + docs at microsoft learn
"Did you configure the account in the Copilot admin center and update the endpoint URL for the webhook in the Event section for the ACS resource?
You'll also need the ACS WhatsApp number channel id as a filter and will have to use Entra Authentication using an Azure App."
Did you run through every step needed for getting WhatsApp through ACS to work with Copilot Studio?
Did you configure the account in the Copilot admin center and update the endpoint URL for the webhook in the Event section for the ACS resource?
You'll also need the ACS WhatsApp number channel id as a filter and will have to use Entra Authentication using an Azure App.
Can you give some pointers on how you are trying to connect ACS to Copilot Studio?
Kind regards
Kilian Tyncke
Voicinity | Founder
"Did you configure the account in the Copilot admin center and update the endpoint URL for the webhook in the Event section for the ACS resource?
You'll also need the ACS WhatsApp number channel id as a filter and will have to use Entra Authentication using an Azure App."
can you explain that ? I have the eventsubscription On and running , where should i go to update the endpoint that is not at the docs.
