Ciao Paolo,
Per gestire tutti i grafici per tutti i giocatori, e per modificare la loro formatazione dinamicamente in risposta ad una modifica dei valori nelle colonne E:F , cioè, le colonnePosizione 2015e Posizione 2014, prova quanto
segue:
- Alt+F11 per aprire l'editor di VBA
- Alt+IMper inserire un nuovo modulo di codice
- Nel nuovo modulo vuoto, incolla il seguente codice:
'=========>>
Option Explicit
'--------->>
Public Function DataAddress(aChartObj As ChartObject)
Dim MySeries As New ChartSeries
With MySeries
.Chart = aChartObj.Chart
.ChartSeries = 1
DataAddress = .XValues.Address
End With
End Function
'--------->>
Public Sub Tester()
Dim WB As Workbook
Dim SH As Worksheet
Dim Rng As Range
Dim arrInterYear
Dim chObj As ChartObject
Dim rPatterns As Range
Dim i As Long
Dim vValues As Variant
Dim MySeries As New ChartSeries
Set WB = ThisWorkbook
Set SH = WB.Sheets("Foglio1")
For Each chObj In SH.ChartObjects
With chObj.Chart.SeriesCollection(1)
Set Rng = SH.Range(DataAddress(chObj)).Offset(0, 2).Resize(, 2)
arrInterYear = Rng.Value
vValues = .Values
For i = 1 To UBound(vValues)
If arrInterYear(i, 1) < arrInterYear(i, 2) Then
.Points(i).Format.Fill.ForeColor.RGB =vbGreen
Else
.Points(i).Format.Fill.ForeColor.RGB = vbRed
End If
Next i
End With
Next chObj
End Sub
'<<=========
- Alt+IC per inserire un modulo Class
- Nel nuovo modulo vuoto, incolla il seguente codice:
'=========>>
Option Explicit
'This Class module provides an easy way to access the items in a
'chart's SERIES formula. It can be exported and then imported into
'any project
'Developed by John Walkenbach, JWALK AND ASSOCIATES
'Copyright 1999. All rights reserved.
'May be used and distributed freely, but may not be sold.
'http://www.j-walk.com/ss/
'===================================
' PROPERTIES FOR CHARTSERIES OBJECT
'===================================
'Chart (read/write)
'ChartSeries (read/write)
'SeriesName (read/write)
'XValues (read/write)
'Values (read/write)
'PlotOrder (read/write)
'SeriesNameType (read-only)
'XValuesType (read-only)
'ValuesType (read-only)
'PlotOrderType (read-only)
Dim CurrChart As Chart 'accessible to all procedures
Dim CurrSeries As Integer 'accessible to all procedures
'--------->>
Property Get Chart() As Chart
Set Chart = CurrChart
End Property
'--------->>
Property Let Chart(Cht)
Set CurrChart = Cht
End Property
'--------->>
Property Get ChartSeries()
ChartSeries = CurrSeries
End Property
'--------->>
Property Let ChartSeries(SeriesNum)
CurrSeries = SeriesNum
End Property
'--------->>
Property Get SeriesName() As Variant
If SeriesNameType = "Range" Then
Set SeriesName = Range(SERIESFormulaElement(CurrChart, CurrSeries, 1))
Else
SeriesName = SERIESFormulaElement(CurrChart, CurrSeries, 1)
End If
End Property
'--------->>
Property Let SeriesName(SName)
CurrChart.SeriesCollection(CurrSeries).Name = SName
End Property
'--------->>
Property Get SeriesNameType() As String
SeriesNameType = SERIESFormulaElementType(CurrChart, CurrSeries, 1)
End Property
'--------->>
Property Get XValues() As Variant
If XValuesType = "Range" Then
Set XValues = Range(SERIESFormulaElement(CurrChart, CurrSeries, 2))
Else
XValues = SERIESFormulaElement(CurrChart, CurrSeries, 2)
End If
End Property
'--------->>
Property Let XValues(XVals)
CurrChart.SeriesCollection(CurrSeries).XValues = XVals
End Property
'--------->>
Property Get XValuesType() As String
XValuesType = SERIESFormulaElementType(CurrChart, CurrSeries, 2)
End Property
'--------->>
Property Get Values() As Variant
If ValuesType = "Range" Then
Set Values = Range(SERIESFormulaElement(CurrChart, CurrSeries, 3))
Else
Values = SERIESFormulaElement(CurrChart, CurrSeries, 3)
End If
End Property
'--------->>
Property Let Values(Vals)
CurrChart.SeriesCollection(CurrSeries).Values = Vals
End Property
'--------->>
Property Get ValuesType() As String
ValuesType = SERIESFormulaElementType(CurrChart, CurrSeries, 3)
End Property
'--------->>
Property Get PlotOrder()
PlotOrder = SERIESFormulaElement(CurrChart, CurrSeries, 4)
End Property
'--------->>
Property Let PlotOrder(PltOrder)
CurrChart.SeriesCollection(CurrSeries).PlotOrder = PltOrder
End Property
'--------->>
Property Get PlotOrderType() As String
PlotOrderType = SERIESFormulaElementType(CurrChart, CurrSeries, 4)
End Property
'--------->>
Private Function SERIESFormulaElementType(ChartObj, SeriesNum, Element) As String
' Returns a string that describes the element of a chart's SERIES formula
' This function essentially parses and analyzes a SERIES formula
' Element 1: Series Name. Returns "Range" , "Empty", or "String"
' Element 2: XValues. Returns "Range", "Empty", or "Array"
' Element 3: Values. Returns "Range" or "Array"
' Element 4: PlotOrder. Always returns "Integer"
Dim SeriesFormula As String
Dim FirstComma As Integer, SecondComma As Integer, LastComma As Integer
Dim FirstParen As Integer, SecondParen As Integer
Dim FirstBracket As Integer, SecondBracket As Integer
Dim StartY As Integer
Dim SeriesName, XValues, Values, PlotOrder As Integer
' Exit if Surface chart (surface chrarts do not have SERIES formulas)
If ChartObj.ChartType >= 83 And ChartObj.ChartType <= 86 Then
SERIESFormulaElementType = "ERROR - SURFACE CHART"
Exit Function
End If
' Exit if nonexistent series is specified
If SeriesNum > ChartObj.SeriesCollection.Count Or SeriesNum < 1 Then
SERIESFormulaElementType = "ERROR - BAD SERIES NUMBER"
Exit Function
End If
' Exit if element is > 4
If Element > 4 Or Element < 1 Then
SERIESFormulaElementType = "ERROR - BAD ELEMENT NUMBER"
Exit Function
End If
' Get the SERIES formula
SeriesFormula = ChartObj.SeriesCollection(SeriesNum).Formula
' Get the First Element (Series Name)
FirstParen = InStr(1, SeriesFormula, "(")
FirstComma = InStr(1, SeriesFormula, ",")
SeriesName = Mid(SeriesFormula, FirstParen + 1, FirstComma - FirstParen - 1)
If Element = 1 Then
If IsRange(SeriesName) Then
SERIESFormulaElementType = "Range"
Else
If SeriesName = "" Then
SERIESFormulaElementType = "Empty"
Else
If TypeName(SeriesName) = "String" Then
SERIESFormulaElementType = "String"
End If
End If
End If
Exit Function
End If
' Get the Second Element (X Range)
If Mid(SeriesFormula, FirstComma + 1, 1) = "(" Then
' Multiple ranges
FirstParen = FirstComma + 2
SecondParen = InStr(FirstParen, SeriesFormula, ")")
XValues = Mid(SeriesFormula, FirstParen, SecondParen - FirstParen)
StartY = SecondParen + 1
Else
If Mid(SeriesFormula, FirstComma + 1, 1) = "{" Then
' Literal Array
FirstBracket = FirstComma + 1
SecondBracket = InStr(FirstBracket, SeriesFormula, "}")
XValues = Mid(SeriesFormula, FirstBracket, SecondBracket - FirstBracket + 1)
StartY = SecondBracket + 1
Else
' A single range
SecondComma = InStr(FirstComma + 1, SeriesFormula, ",")
XValues = Mid(SeriesFormula, FirstComma + 1, SecondComma - FirstComma - 1)
StartY = SecondComma
End If
End If
If Element = 2 Then
If IsRange(XValues) Then
SERIESFormulaElementType = "Range"
Else
If XValues = "" Then
SERIESFormulaElementType = "Empty"
Else
SERIESFormulaElementType = "Array"
End If
End If
Exit Function
End If
' Get the Third Element (Y Range)
If Mid(SeriesFormula, StartY + 1, 1) = "(" Then
' Multiple ranges
FirstParen = StartY + 1
SecondParen = InStr(FirstParen, SeriesFormula, ")")
Values = Mid(SeriesFormula, FirstParen + 1, SecondParen - FirstParen - 1)
LastComma = SecondParen + 1
Else
If Mid(SeriesFormula, StartY + 1, 1) = "{" Then
' Literal Array
FirstBracket = StartY + 1
SecondBracket = InStr(FirstBracket, SeriesFormula, "}")
Values = Mid(SeriesFormula, FirstBracket, SecondBracket - FirstBracket + 1)
LastComma = SecondBracket + 1
Else
' A single range
FirstComma = StartY
SecondComma = InStr(FirstComma + 1, SeriesFormula, ",")
Values = Mid(SeriesFormula, FirstComma + 1, SecondComma - FirstComma - 1)
LastComma = SecondComma
End If
End If
If Element = 3 Then
If IsRange(Values) Then
SERIESFormulaElementType = "Range"
Else
SERIESFormulaElementType = "Array"
End If
Exit Function
End If
' Get the Fourth Element (Plot Order)
PlotOrder = Mid(SeriesFormula, LastComma + 1, Len(SeriesFormula) - LastComma - 1)
If Element = 4 Then
SERIESFormulaElementType = "Integer"
Exit Function
End If
End Function
'--------->>
Private Function SERIESFormulaElement(ChartObj, SeriesNum, Element) As String
' Returns one of four elements in a chart's SERIES formula (as a string)
' This function essentially parses and analyzes a SERIES formula
' Element 1: Series Name. Can be a range reference, a literal value, or nothing
' Element 2: XValues. Can be a range reference (including a non-contiguous range), a literal array, or nothing
' Element 3: Values. Can be a range reference (including a non-contiguous range), or a literal array
' Element 4: PlotOrder. Must be an integer
Dim SeriesFormula As String
Dim FirstComma As Integer, SecondComma As Integer, LastComma As Integer
Dim FirstParen As Integer, SecondParen As Integer
Dim FirstBracket As Integer, SecondBracket As Integer
Dim StartY As Integer
Dim SeriesName, XValues, Values, PlotOrder As Integer
' Exit if Surface chart (surface chrarts do not have SERIES formulas)
If ChartObj.ChartType >= 83 And ChartObj.ChartType <= 86 Then
SERIESFormulaElement = "ERROR - SURFACE CHART"
Exit Function
End If
' Exit if nonexistent series is specified
If SeriesNum > ChartObj.SeriesCollection.Count Or SeriesNum < 1 Then
SERIESFormulaElement = "ERROR - BAD SERIES NUMBER"
Exit Function
End If
' Exit if element is > 4
If Element > 4 Then
SERIESFormulaElement = "ERROR - BAD ELEMENT NUMBER"
Exit Function
End If
' Get the SERIES formula
SeriesFormula = ChartObj.SeriesCollection(SeriesNum).Formula
' Get the First Element (Series Name)
FirstParen = InStr(1, SeriesFormula, "(")
FirstComma = InStr(1, SeriesFormula, ",")
SeriesName = Mid(SeriesFormula, FirstParen + 1, FirstComma - FirstParen - 1)
If Element = 1 Then
SERIESFormulaElement = SeriesName
Exit Function
End If
' Get the Second Element (X Range)
If Mid(SeriesFormula, FirstComma + 1, 1) = "(" Then
' Multiple ranges
FirstParen = FirstComma + 2
SecondParen = InStr(FirstParen, SeriesFormula, ")")
XValues = Mid(SeriesFormula, FirstParen, SecondParen - FirstParen)
StartY = SecondParen + 1
Else
If Mid(SeriesFormula, FirstComma + 1, 1) = "{" Then
' Literal Array
FirstBracket = FirstComma + 1
SecondBracket = InStr(FirstBracket, SeriesFormula, "}")
XValues = Mid(SeriesFormula, FirstBracket, SecondBracket - FirstBracket + 1)
StartY = SecondBracket + 1
Else
' A single range
SecondComma = InStr(FirstComma + 1, SeriesFormula, ",")
XValues = Mid(SeriesFormula, FirstComma + 1, SecondComma - FirstComma - 1)
StartY = SecondComma
End If
End If
If Element = 2 Then
SERIESFormulaElement = XValues
Exit Function
End If
' Get the Third Element (Y Range)
If Mid(SeriesFormula, StartY + 1, 1) = "(" Then
' Multiple ranges
FirstParen = StartY + 1
SecondParen = InStr(FirstParen, SeriesFormula, ")")
Values = Mid(SeriesFormula, FirstParen + 1, SecondParen - FirstParen - 1)
LastComma = SecondParen + 1
Else
If Mid(SeriesFormula, StartY + 1, 1) = "{" Then
' Literal Array
FirstBracket = StartY + 1
SecondBracket = InStr(FirstBracket, SeriesFormula, "}")
Values = Mid(SeriesFormula, FirstBracket, SecondBracket - FirstBracket + 1)
LastComma = SecondBracket + 1
Else
' A single range
FirstComma = StartY
SecondComma = InStr(FirstComma + 1, SeriesFormula, ",")
Values = Mid(SeriesFormula, FirstComma + 1, SecondComma - FirstComma - 1)
LastComma = SecondComma
End If
End If
If Element = 3 Then
SERIESFormulaElement = Values
Exit Function
End If
' Get the Fourth Element (Plot Order)
PlotOrder = Mid(SeriesFormula, LastComma + 1, Len(SeriesFormula) - LastComma - 1)
If Element = 4 Then
SERIESFormulaElement = PlotOrder
Exit Function
End If
End Function
'--------->>
Private Function IsRange(ref) As Boolean
' Returns True if ref is a Range
Dim x As Range
On Error Resume Next
Set x = Range(ref)
If Err = 0 Then IsRange = True Else IsRange = False
End Function
'<<=========
- Fai clic dx sulla linguetta del foglio
- Seleziona l'opzione Visualizza Codicedal menu contestuale risultante
- Incolla il seguente codice:
'=========>>
Option Explicit
'--------->>
Private Sub Worksheet_Change(ByVal Target As Range)
If Not Intersect(Target, Me.Columns("D:E")) Is Nothing Then
Call Tester
End If
End Sub
'<<=========
- Alt+Q per chiudere l'editor di VBA e tornare a Excel.
- Salva il file con un'estensione xlsm
Potresti scaricare il mio file di prova Paolo20151029.xlsm a:
**http://1drv.ms/1O9QTYU**
Supponiamo, come nel file di prova che ci siano due giocatori, i suoi dati e grafici potrebbero essere:
Modificando i dati Posizione 2015/2014, o premendo il pulsante, si otterrebbe qualcosa del genere:
===
Regards,
Norman
