Creare un chatbot RAG con l'API NoSQL di Azure Cosmos DB
In questa guida viene illustrato come creare un'applicazione Rag Pattern usando un subset del set di dati Movie Lens. Questo esempio usa Python SDK per Azure Cosmos DB for NoSQL per eseguire la ricerca vettoriale per RAG, archiviare e recuperare la cronologia della chat e archiviare i vettori della cronologia della chat da usare come cache semantica. Azure OpenAI viene usato per generare incorporamenti e completamenti LLM (Large Language Model).
Alla fine viene creata una semplice esperienza utente usando Gradio per consentire agli utenti di digitare domande e visualizzare le risposte generate da Azure OpenAI o gestite dalla cache. Le risposte visualizzeranno anche un tempo trascorso per mostrare l'impatto della memorizzazione nella cache sulle prestazioni rispetto alla generazione di una risposta.
Suggerimento
È possibile trovare l'esempio completo di notebook Python qui.
Per altri esempi di RAG, vedere: AzureDataRetrievalAugmentedGenerationSamples
Importante
Questo esempio richiede di configurare gli account per Azure Cosmos DB per NoSQL e Azure OpenAI. Per iniziare, visitare:
1. Installare i pacchetti necessari
Installare i pacchetti Python necessari per interagire con Azure Cosmos DB e altri servizi.
! pip install --user python-dotenv
! pip install --user aiohttp
! pip install --user openai
! pip install --user gradio
! pip install --user ijson
! pip install --user nest_asyncio
! pip install --user tenacity
# Note: ensure you have azure-cosmos version 4.7 or higher installed
! pip install --user azure-cosmos
2. Inizializzare la connessione client
Popolare sample_env_file.env con le credenziali appropriate per Azure Cosmos DB e Azure OpenAI.
cosmos_uri = "https://<replace with cosmos db account name>.documents.azure.com:443/"
cosmos_key = "<replace with cosmos db account key>"
cosmos_database_name = "database"
cosmos_collection_name = "vectorstore"
cosmos_vector_property_name = "vector"
cosmos_cache_database_name = "database"
cosmos_cache_collection_name = "vectorcache"
openai_endpoint = "<replace with azure openai endpoint>"
openai_key = "<replace with azure openai key>"
openai_type = "azure"
openai_api_version = "2023-05-15"
openai_embeddings_deployment = "<replace with azure openai embeddings deployment name>"
openai_embeddings_model = "<replace with azure openai embeddings model - e.g. text-embedding-3-large"
openai_embeddings_dimensions = "1536"
openai_completions_deployment = "<replace with azure openai completions deployment name>"
openai_completions_model = "<replace with azure openai completions model - e.g. gpt-35-turbo>"
storage_file_url = "https://cosmosdbcosmicworks.blob.core.windows.net/fabcondata/movielens_dataset.json"
# Import the required libraries
import time
import json
import uuid
import urllib
import ijson
import zipfile
from dotenv import dotenv_values
from openai import AzureOpenAI
from azure.core.exceptions import AzureError
from azure.cosmos import PartitionKey, exceptions
from time import sleep
import gradio as gr
# Cosmos DB imports
from azure.cosmos import CosmosClient
# Load configuration
env_name = "sample_env_file.env"
config = dotenv_values(env_name)
cosmos_conn = config['cosmos_uri']
cosmos_key = config['cosmos_key']
cosmos_database = config['cosmos_database_name']
cosmos_collection = config['cosmos_collection_name']
cosmos_vector_property = config['cosmos_vector_property_name']
comsos_cache_db = config['cosmos_cache_database_name']
cosmos_cache = config['cosmos_cache_collection_name']
# Create the Azure Cosmos DB for NoSQL async client for faster data loading
cosmos_client = CosmosClient(url=cosmos_conn, credential=cosmos_key)
openai_endpoint = config['openai_endpoint']
openai_key = config['openai_key']
openai_api_version = config['openai_api_version']
openai_embeddings_deployment = config['openai_embeddings_deployment']
openai_embeddings_dimensions = int(config['openai_embeddings_dimensions'])
openai_completions_deployment = config['openai_completions_deployment']
# Movies file url
storage_file_url = config['storage_file_url']
# Create the OpenAI client
openai_client = AzureOpenAI(azure_endpoint=openai_endpoint, api_key=openai_key, api_version=openai_api_version)
3. Creare un database e contenitori con criteri vettoriali
Questa funzione accetta un oggetto di database, un nome di raccolta, il nome della proprietà del documento che archivia i vettori e il numero di dimensioni vettoriali usate per gli incorporamenti.
db = cosmos_client.create_database_if_not_exists(cosmos_database)
# Create the vector embedding policy to specify vector details
vector_embedding_policy = {
"vectorEmbeddings": [
{
"path":"/" + cosmos_vector_property,
"dataType":"float32",
"distanceFunction":"cosine",
"dimensions":openai_embeddings_dimensions
},
]
}
# Create the vector index policy to specify vector details
indexing_policy = {
"includedPaths": [
{
"path": "/*"
}
],
"excludedPaths": [
{
"path": "/\"_etag\"/?",
"path": "/" + cosmos_vector_property + "/*",
}
],
"vectorIndexes": [
{
"path": "/"+cosmos_vector_property,
"type": "quantizedFlat"
}
]
}
# Create the data collection with vector index (note: this creates a container with 10000 RUs to allow fast data load)
try:
movies_container = db.create_container_if_not_exists(id=cosmos_collection,
partition_key=PartitionKey(path='/id'),
indexing_policy=indexing_policy,
vector_embedding_policy=vector_embedding_policy,
offer_throughput=10000)
print('Container with id \'{0}\' created'.format(movies_container.id))
except exceptions.CosmosHttpResponseError:
raise
# Create the cache collection with vector index
try:
cache_container = db.create_container_if_not_exists(id=cosmos_cache,
partition_key=PartitionKey(path='/id'),
indexing_policy=indexing_policy,
vector_embedding_policy=vector_embedding_policy,
offer_throughput=1000)
print('Container with id \'{0}\' created'.format(cache_container.id))
except exceptions.CosmosHttpResponseError:
raise
4. Generare incorporamenti da Azure OpenAI
Questa funzione vettorializza l'input dell'utente per la ricerca vettoriale. Verificare che la dimensionalità e il modello usati corrispondano ai dati di esempio forniti oppure rigenerare i vettori con il modello desiderato.
from tenacity import retry, stop_after_attempt, wait_random_exponential
import logging
@retry(wait=wait_random_exponential(min=2, max=300), stop=stop_after_attempt(20))
def generate_embeddings(text):
try:
response = openai_client.embeddings.create(
input=text,
model=openai_embeddings_deployment,
dimensions=openai_embeddings_dimensions
)
embeddings = response.model_dump()
return embeddings['data'][0]['embedding']
except Exception as e:
# Log the exception with traceback for easier debugging
logging.error("An error occurred while generating embeddings.", exc_info=True)
raise
5. Caricare dati dal file JSON
Estrarre il set di dati MovieLens prevectorizzato dal file ZIP (vedere la relativa posizione nel repository notebook qui).
# Unzip the data file
with zipfile.ZipFile("../../DataSet/Movies/MovieLens-4489-256D.zip", 'r') as zip_ref:
zip_ref.extractall("/Data")
zip_ref.close()
# Load the data file
data = []
with open('/Data/MovieLens-4489-256D.json', 'r') as d:
data = json.load(d)
# View the number of documents in the data (4489)
len(data)
6. Archiviare dati in Azure Cosmos DB
Eseguire l'upsert dei dati in Azure Cosmos DB for NoSQL. I record vengono scritti in modo asincrono.
#The following code to get raw movies data is commented out in favour of
#getting prevectorized data. If you want to vectorize the raw data from
#storage_file_url, uncomment the below, and set vectorizeFlag=True
#data = urllib.request.urlopen(storage_file_url)
#data = json.load(data)
vectorizeFlag=False
import asyncio
import time
from concurrent.futures import ThreadPoolExecutor
async def generate_vectors(items, vector_property):
# Create a thread pool executor for the synchronous generate_embeddings
loop = asyncio.get_event_loop()
# Define a function to call generate_embeddings using run_in_executor
async def generate_embedding_for_item(item):
try:
# Offload the sync generate_embeddings to a thread
vectorArray = await loop.run_in_executor(None, generate_embeddings, item['overview'])
item[vector_property] = vectorArray
except Exception as e:
# Log or handle exceptions if needed
logging.error(f"Error generating embedding for item: {item['overview'][:50]}...", exc_info=True)
# Create tasks for all the items to generate embeddings concurrently
tasks = [generate_embedding_for_item(item) for item in items]
# Run all the tasks concurrently and wait for their completion
await asyncio.gather(*tasks)
return items
async def insert_data(vectorize=False):
start_time = time.time() # Record the start time
# If vectorize flag is True, generate vectors for the data
if vectorize:
print("Vectorizing data, please wait...")
global data
data = await generate_vectors(data, "vector")
counter = 0
tasks = []
max_concurrency = 5 # Adjust this value to control the level of concurrency
semaphore = asyncio.Semaphore(max_concurrency)
print("Starting doc load, please wait...")
def upsert_item_sync(obj):
movies_container.upsert_item(body=obj)
async def upsert_object(obj):
nonlocal counter
async with semaphore:
await asyncio.get_event_loop().run_in_executor(None, upsert_item_sync, obj)
# Progress reporting
counter += 1
if counter % 100 == 0:
print(f"Sent {counter} documents for insertion into collection.")
for obj in data:
tasks.append(asyncio.create_task(upsert_object(obj)))
# Run all upsert tasks concurrently within the limits set by the semaphore
await asyncio.gather(*tasks)
end_time = time.time() # Record the end time
duration = end_time - start_time # Calculate the duration
print(f"All {counter} documents inserted!")
print(f"Time taken: {duration:.2f} seconds ({duration:.3f} milliseconds)")
# Run the async function with the vectorize flag set to True or False as needed
await insert_data(vectorizeFlag) # or await insert_data() for default
7. Eseguire la ricerca vettoriale
Questa funzione definisce una ricerca vettoriale sui dati dei film e sulle raccolte di cache delle chat.
def vector_search(container, vectors, similarity_score=0.02, num_results=5):
results = container.query_items(
query='''
SELECT TOP @num_results c.overview, VectorDistance(c.vector, @embedding) as SimilarityScore
FROM c
WHERE VectorDistance(c.vector,@embedding) > @similarity_score
ORDER BY VectorDistance(c.vector,@embedding)
''',
parameters=[
{"name": "@embedding", "value": vectors},
{"name": "@num_results", "value": num_results},
{"name": "@similarity_score", "value": similarity_score}
],
enable_cross_partition_query=True,
populate_query_metrics=True
)
results = list(results)
formatted_results = [{'SimilarityScore': result.pop('SimilarityScore'), 'document': result} for result in results]
return formatted_results
8. Ottenere la cronologia della chat recente
Questa funzione fornisce il contesto di conversazione all'LLM, consentendo di avere una conversazione migliore con l'utente.
def get_chat_history(container, completions=3):
results = container.query_items(
query='''
SELECT TOP @completions *
FROM c
ORDER BY c._ts DESC
''',
parameters=[
{"name": "@completions", "value": completions},
],
enable_cross_partition_query=True
)
results = list(results)
return results
9. Funzioni di completamento chat
Definire le funzioni per gestire il processo di completamento della chat, incluse le risposte di memorizzazione nella cache.
def generate_completion(user_prompt, vector_search_results, chat_history):
system_prompt = '''
You are an intelligent assistant for movies. You are designed to provide helpful answers to user questions about movies in your database.
You are friendly, helpful, and informative and can be lighthearted. Be concise in your responses, but still friendly.
- Only answer questions related to the information provided below. Provide at least 3 candidate movie answers in a list.
- Write two lines of whitespace between each answer in the list.
'''
messages = [{'role': 'system', 'content': system_prompt}]
for chat in chat_history:
messages.append({'role': 'user', 'content': chat['prompt'] + " " + chat['completion']})
messages.append({'role': 'user', 'content': user_prompt})
for result in vector_search_results:
messages.append({'role': 'system', 'content': json.dumps(result['document'])})
response = openai_client.chat.completions.create(
model=openai_completions_deployment,
messages=messages,
temperature=0.1
)
return response.model_dump()
def chat_completion(cache_container, movies_container, user_input):
print("starting completion")
# Generate embeddings from the user input
user_embeddings = generate_embeddings(user_input)
# Query the chat history cache first to see if this question has been asked before
cache_results = get_cache(container=cache_container, vectors=user_embeddings, similarity_score=0.99, num_results=1)
if len(cache_results) > 0:
print("Cached Result\n")
return cache_results[0]['completion'], True
else:
# Perform vector search on the movie collection
print("New result\n")
search_results = vector_search(movies_container, user_embeddings)
print("Getting Chat History\n")
# Chat history
chat_history = get_chat_history(cache_container, 3)
# Generate the completion
print("Generating completions \n")
completions_results = generate_completion(user_input, search_results, chat_history)
print("Caching response \n")
# Cache the response
cache_response(cache_container, user_input, user_embeddings, completions_results)
print("\n")
# Return the generated LLM completion
return completions_results['choices'][0]['message']['content'], False
10. Memorizzare nella cache le risposte generate
Salvare le richieste utente e i completamenti generati nella cache per risposte future più veloci.
def cache_response(container, user_prompt, prompt_vectors, response):
chat_document = {
'id': str(uuid.uuid4()),
'prompt': user_prompt,
'completion': response['choices'][0]['message']['content'],
'completionTokens': str(response['usage']['completion_tokens']),
'promptTokens': str(response['usage']['prompt_tokens']),
'totalTokens': str(response['usage']['total_tokens']),
'model': response['model'],
'vector': prompt_vectors
}
container.create_item(body=chat_document)
def get_cache(container, vectors, similarity_score=0.0, num_results=5):
# Execute the query
results = container.query_items(
query= '''
SELECT TOP @num_results *
FROM c
WHERE VectorDistance(c.vector,@embedding) > @similarity_score
ORDER BY VectorDistance(c.vector,@embedding)
''',
parameters=[
{"name": "@embedding", "value": vectors},
{"name": "@num_results", "value": num_results},
{"name": "@similarity_score", "value": similarity_score},
],
enable_cross_partition_query=True, populate_query_metrics=True)
results = list(results)
return results
11. Creare un'esperienza utente semplice in Gradio
Creare un'interfaccia utente usando Gradio per interagire con l'applicazione di intelligenza artificiale.
chat_history = []
with gr.Blocks() as demo:
chatbot = gr.Chatbot(label="Cosmic Movie Assistant")
msg = gr.Textbox(label="Ask me about movies in the Cosmic Movie Database!")
clear = gr.Button("Clear")
def user(user_message, chat_history):
start_time = time.time()
response_payload, cached = chat_completion(cache_container, movies_container, user_message)
end_time = time.time()
elapsed_time = round((end
time - start_time) * 1000, 2)
details = f"\n (Time: {elapsed_time}ms)"
if cached:
details += " (Cached)"
chat_history.append([user_message, response_payload + details])
return gr.update(value=""), chat_history
msg.submit(user, [msg, chatbot], [msg, chatbot], queue=False)
clear.click(lambda: None, None, chatbot, queue=False)
# Launch the Gradio interface
demo.launch(debug=True)
# Be sure to run this cell to close or restart the Gradio demo
demo.close()
Soluzioni di database vettoriali
Estensione pgvector del server PostgreSQL di Azure
Contenuto correlato
- Versione di prova gratuita di 30 giorni senza sottoscrizione di Azure
- Versione di prova gratuita di 90 giorni e fino a $6.000 in crediti di velocità effettiva con Azure AI Advantage
