Microsoft Surface Pro 7 with Windows 11 enterprise, MARS agent gives error FX:{84AF3E24-7EE9-44C9-8007-3B5093D6D208}
Badari Prasad
0
Reputation points
Microsoft Surface Pro 7 with Windows 11 enterprise, running the Azure Backup MARS agent gives me the following error,
Unhandled exception in Managed Code Snap-in
FX:{84AF3E24-7EE9-44C9-8007-3B5093D6D208}
Could not load file or assembly 'CBSnapIn, Version=1.0.523.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35' or one of its dependencies. An attempt was made to load a program with an incorrect format.
Exception type:
System.BadImageFormatException
Exception Stack trace:
at System.Reflection.RuntimeAssembly._nLoad(AssemblyName fileName, String codeBase, Evidence assemblySecurity, RuntimeAssembly locationHint, StackCrawlMark& stackMark, IntPtr pPrivHostBinder, Boolean throwOnFileNotFound, Boolean forIntrospection, Boolean suppressSecurityChecks)
at System.Reflection.RuntimeAssembly.InternalLoadAssemblyName(AssemblyName assemblyRef, Evidence assemblySecurity, RuntimeAssembly reqAssembly, StackCrawlMark& stackMark, IntPtr pPrivHostBinder, Boolean throwOnFileNotFound, Boolean forIntrospection, Boolean suppressSecurityChecks)
at System.Activator.CreateInstance(String assemblyString, String typeName, Boolean ignoreCase, BindingFlags bindingAttr, Binder binder, Object[] args, CultureInfo culture, Object[] activationAttributes, Evidence securityInfo, StackCrawlMark& stackMark)
at System.Activator.CreateInstance(String assemblyName, String typeName)
at System.AppDomain.CreateInstance(String assemblyName, String typeName)
at System.AppDomain.CreateInstanceAndUnwrap(String assemblyName, String typeName)
at Microsoft.ManagementConsole.Internal.SnapInClient.CreateSnapIn(String assemblyName, String typeName)
at Microsoft.ManagementConsole.Internal.ClassLibraryServices.Microsoft.ManagementConsole.Internal.IClassLibraryServices.CreateSnapIn(String assemblyName, String typeName)
at Microsoft.ManagementConsole.Executive.SnapInInitializationOperation.OnStart()
at Microsoft.ManagementConsole.Executive.RunningOperationsTable.EnqueueOperation(Operation operation)
at Microsoft.ManagementConsole.Advanced.FrameworkSnapInFactory.Microsoft.ManagementConsole.Advanced.ISnapInFactory.CreateSnapIn(Int32 bookkeepingId, String snapInKey, Object& snapIn)
I have tried all the following recommended solutions but error still persists,
- Reinstalled Windows 11 enterprise
- Edited the registry HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\MMC\SnapIns. and deleted the CLSID folder
- Made sure that .NET Framework 3.5 is installed
- Renamed the mmc.exe in C:\Windows\System32 and ran the sfc /scannow to check and repair corrupted system files.
Please help, I need to setup the Azure backup !
-Badari
Azure Backup
{count} votes
-
SadiqhAhmed-MSFT 49,331 Reputation points Microsoft Employee Moderator2024-11-28T07:51:02.97+00:00 @Badari Prasad Greetings!
Based on the information shared, I understand that you are facing issues with MARS agent. In most cases, it could be a transient issue. However, in your case this appears to be a problem that needs attention, and I suggest you "Download the latest version of the Azure Backup agent" this should help resolve the issue. If this doesn't work, then try to remove below reg key and retry the operation.
Note: It is recommended to back up the registry key before making any changes to it.
"HKLM:\SOFTWARE\Microsoft\MMC\SnapIns\FX:{84AF3E24-7EE9-44C9-8007-3B5093D6D208}"Hope this helps! Let us know how it goes.
-
Badari Prasad 0 Reputation points
2024-11-28T07:59:19.5466667+00:00 @SadiqhAhmed-MSFT Thank you for the response.
I have tried installing the upgrade from the link that you gave me and the error was the same.
So I edited the registry and removed the "HKLM:\SOFTWARE\Microsoft\MMC\SnapIns\FX:{84AF3E24-7EE9-44C9-8007-3B5093D6D208}" as suggested, but now I get this error
Please advice, thank you.
-Badari
-
SadiqhAhmed-MSFT 49,331 Reputation points Microsoft Employee Moderator
2024-11-28T08:59:08.45+00:00 @Badari Prasad After removing the reg key, you need to reboot the machine and then retry the operation.
-
Badari Prasad 0 Reputation points
2024-11-28T10:18:15.7266667+00:00 @SadiqhAhmed-MSFT I have tried the following,
- Updated MARS agent from the link you sent, restarted the laptop and still got the same error
- Edited the registry and removed the key, restarted the laptop and still got the same error
- Unistalled MARS agent, restarted the laptop
- Reinstalled the MARS agent from the link you sent, restarted the laptop and still got the same error
- Edited the registry and removed the key, restarted the laptop and I am still getting the same error
Let me know what else I can try, thanks
-Badari
-
SadiqhAhmed-MSFT 49,331 Reputation points Microsoft Employee Moderator
2024-11-28T13:11:49.0366667+00:00 @Badari Prasad Sorry for the painful experience. The query needs a further deeper dive technically. I recommend you create a technical support ticket.
The ticket enables you to work closely with the support engineers and get a quick resolution to your issue.
Here is the link - https://docs.microsoft.com/en-us/azure/azure-portal/supportability/how-to-create-azure-support-request to create support case. Let us know if there are any challenges contacting Azure technical support.
