How to use Microsoft Fabric notebooks

The Microsoft Fabric notebook is a primary code item for developing Apache Spark jobs and machine learning experiments. It's a web-based interactive surface used by data scientists and data engineers to write code benefiting from rich visualizations and Markdown text. Data engineers write code for data ingestion, data preparation, and data transformation. Data scientists also use notebooks to build machine learning solutions, including creating experiments and models, model tracking, and deployment.

With a Fabric notebook, you can:

• Get started with zero set-up effort.
• Easily explore and process data with intuitive low-code experience.
• Keep data secure with built-in enterprise security features.
• Analyze data across raw formats (CSV, txt, JSON, etc.), processed file formats (parquet, Delta Lake, etc.), using powerful Spark capabilities.
• Be productive with enhanced authoring capabilities and built-in data visualization.

This article describes how to use notebooks in data science and data engineering experiences.

Security context of running notebook

The execution of a notebook can be triggered by three different manners in Fabric with full flexibility to meet different scenarios:

• Interactive run: User manually triggers the execution via the different UX entries or calling the REST API. The execution would be running under the current user's security context.
• Run as pipeline activity: The execution is triggered from Fabric Data Factory pipeline. You can find the detail steps in the Notebook Activity. The execution would be running under the pipeline owner's security context.
• Scheduler: The execution is triggered from a scheduler plan. The execution would be running under the security context of the user who setup/update the scheduler plan.

The flexibility of these execution options with different security context allows you to meet different scenarios and requirements, but also requires you to be aware of the security context when you design and develop your notebook, otherwise it may cause unexpected behavior and even some security issues.

The first time when a notebook is created, a warning message will be shown to remind you the risk of running the code without reviewing it.

Here are some best practices to help you avoid security issues:

• Before you manually run the notebook, Open the Notebook setting and check the Detail section under the About panel for the modification update, make sure you are OK with the latest change.
• Before you add a notebook activity to a pipeline, Open the Notebook setting and check the Detail section under the About panel for the modification update, make sure you are OK with the latest change. If you are not sure about the latest change, better open the Notebook to review the change before you add it into the pipeline.
• Before you update the scheduler plan, Open the Notebook setting and check the Detail section under the About panel for the modification update, make sure you are OK with the latest change. If you are not sure about the latest change, better open the Notebook to review the change before you update the scheduler plan.
• Separate the workspace into different stage (dev, test, prod) and control the access of different stage to avoid the security issue. Only add the user who you trust to the prod stage.

Create notebooks

You can either create a new notebook or import an existing notebook.

Create a new notebook

Like other standard Fabric item creation processes, you can easily create a new notebook from the Fabric Data Engineering homepage, the workspace New option, or the Create Hub.

Import existing notebooks

You can import one or more existing notebooks from your local computer using the entry in the workspace toolbar. Fabric notebooks recognize the standard Jupyter Notebook .ipynb files, and source files like .py, .scala, and .sql, and create new notebook items accordingly.

Export a notebook

You can export your notebook to other standard formats. Synapse notebook can be exported into:

• The standard notebook file (.ipynb) that is used for Jupyter notebooks.
• An HTML file (.html) that can be opened from a browser directly.
• A Python file (.py).
• A Latex file (.tex).

Save a notebook

In Fabric, a notebook will by default save automatically after you open and edit it; you don't need to worry about losing code changes. You can also use Save a copy to clone another copy in the current workspace or to another workspace.

If you prefer to save a notebook manually, you can switch to the Manual save option to have a local branch of your notebook item, and then use Save or CTRL+s to save your changes.

You can also switch to manual save mode by selecting Edit -> Save options -> Manual. To turn on a local branch of your notebook then save it manually, select Save or use the Ctrl+s keyboard shortcut.

Connect lakehouses and notebooks

Fabric notebooks now support close interactions with lakehouses; you can easily add a new or existing lakehouse from the Lakehouse explorer.

You can navigate to different lakehouses in the Lakehouse explorer and set one lakehouse as the default by pinning it. Your default is then mounted to the runtime working directory, and you can read or write to the default lakehouse using a local path.

Note

You must restart the session after pinning a new lakehouse or renaming the default lakehouse.

Add or remove a lakehouse

Selecting the X icon beside a lakehouse name removes it from the notebook tab, but the lakehouse item still exists in the workspace.

Select Add lakehouse to add more lakehouses to the notebook, either by adding an existing one or creating a new lakehouse.

Explore a lakehouse file

The subfolder and files under the Tables and Files section of the Lake view appear in a content area between the lakehouse list and the notebook content. Select different folders in the Tables and Files section to refresh the content area.

Folder and file operations

If you select a file (.csv, .parquet, .txt, .jpg, .png, etc.) with a right mouse click, you can use the Spark or Pandas API to load the data. A new code cell is generated and inserted beneath the focus cell.

You can easily copy a path with a different format from the select file or folder and use the corresponding path in your code.

Notebook resources

The notebook resource explorer provides a Unix-like file system to help you manage your folders and files. It offers a writeable file system space where you can store small-sized files, such as code modules, semantic models, and images. You can easily access them with code in the notebook as if you were working with your local file system.

Note

• The maximum Resource storages for both built-in folder and environment folder are 500 MB, with a single file size up to 100 MB. They both allow up to 100 file/folder instances in total.
• When using notebookutils.notebook.run(), use the notebookutils.nbResPath command to access the target notebook resource. The relative path builtin/ will always point to the root notebook’s built-in folder.

Built-in resources folder

The built-in resources folder is a system predefined folder for each notebook item instance. Here are the key capabilities for the notebook resources.

• You can use common operations such as create/delete, upload/download, drag/drop, rename, duplicate, and search through the UI.
• You can use relative paths like builtin/YourData.txt for quick exploration. The notebookutils.nbResPath method helps you compose the full path.
• You can easily move your validated data to a lakehouse via the Write to lakehouse option. Fabric has embedded rich code snippets for common file types to help you quickly get started.
• These resources are also available for use in the Reference notebook run case via notebookutils.notebook.run().

Environment resources folder

Environment Resources Folder is a shared repository designed to streamline collaboration across multiple notebooks.

• You can find the Resources tab inside the environment and have the full operations to manage the resource files here. These files can be shared across multiple notebooks once the notebook is attached to the current environment.



• In the Notebook page, you can easily find a second root folder under Resources inherited from the attached environment.



• You can also operate on the files/folders just same with the Built-in resources folder.

• The Environment resource path will be automatically mounted to the notebook cluster, you can use the relative path /env to access the environment resources.

File editor

The file editor allows you to view and edit files directly within the notebook's resource folder and environment resource folder in notebook. Supported file types include CSV, TXT, HTML, YML, PY, SQL, and more. With the file editor, you can easily access and modify files within the notebook, it support Keyword highlighting and provides necessary language service when opening and editing code files like .py and .sql.

• You can access this feature through 'View and edit' in the file menu. Double-click on file is a faster way.



• Content change on file editor need to be saved manually by clicking the Save button or keyboard shortcut: Ctrl+S, file editor doesn't support auto-save.

• File editor is also affected by notebook mode. You can only view files but cannot edit them if you are in the notebook mode without editing permission.

Note

Here are some limitations for file editor.

• File size limit is 1 MB.
• These file types are not supported for viewing and editing: .xlsx and .parquet.

Collaborate in a notebook

The Fabric notebook is a collaborative item that supports multiple users editing the same notebook.

When you open a notebook, you enter the co-editing mode by default, and every notebook edit is automatically saved. If your colleagues open the same notebook at the same time, you see their profile, run output, cursor indicator, selection indicator, and editing trace. By using the collaboration features, you can easily accomplish pair programming, remote debugging, and tutoring scenarios.

Share a notebook

Sharing a notebook is a convenient way for you to collaborate with team members. Authorized workspace roles can view or edit/run notebooks by default. You can share a notebook with specified permissions granted.

1. Select Share on the notebook toolbar.



2. Select the corresponding category of people who can view this notebook. You can choose Share, Edit, or Run permissions for the recipients.



3. After you select Apply, you can either send the notebook directly or copy the link to others. Recipients can then open the notebook with the corresponding view granted by their permission level.



4. To further manage your notebook permissions, select Workspace item list > More options, and then select Manage permissions. From that screen, you can update the existing notebook access and permissions.



Comment a code cell

Commenting is another useful feature for collaborative scenarios. Currently, Fabric supports adding cell-level comments.

1. Select the Comments button on the notebook toolbar or cell comment indicator to open the Comments pane.



2. Select code in the code cell, select New in the Comments pane, add comments, and then select Post comment to save.



3. If you need them, find the Edit comment, Resolve thread, and Delete thread options by selecting the More option next to your comment.

Tagging others in a comment

"Tagging" refers to mentioning and notifying a user in a comment thread, enhancing collaboration efficiently on the specifics.

1. Select a section of code in a cell and new a comment thread.

2. Input user name and choose the correct one on the suggestion list if you want to mention someone for discussion about a certain section.

3. Share your insights and Post them.

4. An Email notification will be triggered, and user clicks on Open Comments link to quickly locate this cell.

5. Moreover, authorize and configure the permissions for users when tagging someone who doesn’t have access, ensuring that your code assets are well managed.

Note

For a comment item, the tagged user will not receive an Email notification anymore if you updates the comment within one hour. But it will send Email notification to the new tagged user.

Notebook mode switcher

Fabric notebooks support four modes that you can easily switch: Develop mode，Run only mode, Edit mode and View mode. Each mode maps to a specific permission combination. When sharing the notebook to other team members, you can grant proper permissions to the recipients, and they will see the best available notebook mode according to their permission, and they will be able to switch between the mode they have permission to.

• Develop mode: Read, execute, write permission needed.
• Run only mode: Read, execute permission needed.
• Edit mode: Read, write permission needed.
• View mode: Read permission needed.
