Red Pass Filter for Image Processing in C#

Question

I am trying to code a Red Pass filer in C#. I might not be using the correct name for this, but I want to convert all the non-red pixel to black (0,0,0).

So, like how a high pass filter sets all frequencies below a giving setpoint to 0. I want to set all the non-red pixel to (0,0,0) aka Black.

My problem is that I am using images from a camera, so the red pixels are not (255,0,0) plus because of Light and shades on the object I am taking a picture of some of the red pixels are darker than others. Meaning this [Red Color] (https://i.stack.imgur.com/Hc42q.png) and this Red Color are on the same object in the image.

This is what I have Tried so for:

public bool IsRed(RGB color)
{
    // The pixel is a shade of red if the red value is greater than the green and blue values
    return color.Red > color.Green && color.Red > color.Blue;
}

public bool IsRed2(RGB color)
{
    // The pixel is a shade of red if the red value is within the range of 128 to 255.
    return color.Red >= 128 && color.Red <= 255;
}

public bool IsRed3(RGB color)
{
    // Convert the RGB values to HSL.
    double hue, saturation, lightness;
    RGBToHSL(color.Red, color.Green, color.Blue, out hue, out saturation, out lightness);

    // The pixel is a shade of red if the hue is within the range of 0 to 30 degrees or 330 to 360 degrees.
    return (hue >= 0 && hue <= 30) || (hue >= 330 && hue <= 360);
}

// Converts the given RGB values to HSL.
private void RGBToHSL(byte red, byte green, byte blue, out double hue, out double saturation, out double lightness)
{
    // Convert the RGB values to the range 0 to 1.
    double r = red / 255.0;
    double g = green / 255.0;
    double b = blue / 255.0;

    // Calculate the maximum and minimum RGB values.
    double max = Math.Max(r, Math.Max(g, b));
    double min = Math.Min(r, Math.Min(g, b));

    // Calculate the lightness.
    lightness = (max + min) / 2;

    // Calculate the saturation.
    if (max == min)
    {
        // The color is a shade of gray.
        hue = 0;
        saturation = 0;
    }
    else
    {
        // The color is not a shade of gray.
        double d = max - min;
        saturation = lightness > 0.5 ? d / (2 - max - min) : d / (max + min);

        // Calculate the hue.
        if (max == r)
        {
            hue = (g - b) / d + (g < b ? 6 : 0);
        }
        else if (max == g)
        {
            hue = (b - r) / d + 2;
        }
        else
        {
            hue = (r - g) / d + 4;
        }

        hue /= 6;
    }
}



This is how I am getting the RGB values from the image:

 private RGB[,] ImageToRGBByteArray(Bitmap _image, int height, int width)
    {
        Bitmap b = new Bitmap(_image);

        BitmapData bData = b.LockBits(new Rectangle(0, 0, _image.Width, _image.Height), ImageLockMode.ReadWrite, b.PixelFormat);

        /* GetBitsPerPixel just does a switch on the PixelFormat and returns the number */
        BitsPerPixel = GetBitsPerPixel(bData.PixelFormat);

        /*the size of the image in bytes */
        int size = bData.Stride * bData.Height;

        Stride = bData.Stride;
        /*Allocate buffer for image*/
        byte[] data = new byte[size];
        RGB[,] imagematrix = new RGB[height, width];
        int[,] imageData = new int[height, width];
        /*This overload copies data of /size/ into /data/ from location specified (/Scan0/)*/
        Marshal.Copy(bData.Scan0, data, 0, size);
        int i = 0;

        ModifiedHistogram = null;
        ImageData = null;
        ImageRGBData = null;
        Dictionary<RGB, int> modifiedHistogram = new Dictionary<RGB, int>();

        for (int y = 0; y < height; y++)
        {
            for (int x = 0; x < width; x++)
            {
                RGB tempValue = new RGB(data[i], data[i + 1], data[i + 2]);
                imagematrix[y, x] = tempValue;

                imageData[y, x] = (int)((data[i] + data[i + 1] + data[i + 2]) / 3D);

                if (!modifiedHistogram.ContainsKey(tempValue))
                    modifiedHistogram.Add(tempValue, 1);
                else
                    modifiedHistogram[tempValue]++;
                i += BitsPerPixel / 8;
            }
        }

        int maxValue = 0;
        string color = string.Empty;
        foreach (var kvp in modifiedHistogram)
        {
            if (kvp.Value > maxValue)
            {
                maxValue = kvp.Value;
                color = kvp.Key.ColorName;
            }
        }
        ImageData = imageData;
        ImageRGBData = imagematrix;
        ModifiedHistogram = modifiedHistogram;
        return imagematrix;
    }

so

data[i] = Red
data[i+2] = Green
data[i+3] = Blue

This is my Color class:

public class RGB
{
    public  byte Red { get; set; }
    public  byte Green { get; set; }
    public  byte Blue { get; set; }



    public RGB(byte red, byte green, byte blue)
    {
        Red = red;
        Green = green;
        Blue = blue;
        SetColorName();
    }


    public override bool Equals(object obj)
    {
         RGB other = obj as RGB;
        return other != null && other.ColorName == this.ColorName;
    }
}
