Important
Items marked (preview) in this article are currently in public preview. This preview is provided without a service-level agreement, and we don't recommend it for production workloads. Certain features might not be supported or might have constrained capabilities. For more information, see Supplemental Terms of Use for Microsoft Azure Previews.
AI agents are powerful productivity assistants that can create workflows for business needs. However, observability can be a challenge, due to their complex interaction patterns. In this article, you learn how to run built-in evaluators locally on simple agent data or agent messages.
To build production-ready agentic applications and enable observability and transparency, developers need tools to assess not just the final output from an agent's workflows, but the quality and efficiency of the workflows themselves. For example, consider a typical agentic workflow:
An event like a user querying "weather tomorrow" triggers an agentic workflow. To produce a final response, the agentic workflow runs multiple steps that include reasoning through user intents, tool calling, and utilizing retrieval-augmented generation. In this process, it's crucial to evaluate each step of the workflow, and the quality and safety of the final output. We formulate these evaluation aspects into the following evaluators for agents:
- Intent resolution: Measures whether the agent correctly identifies the user's intent.
- Tool call accuracy: Measures whether the agent made the correct function tool calls to a user's request.
- Task adherence: Measures whether the agent's final response adheres to its assigned tasks, according to its system message and prior steps.
You can also assess other quality and safety aspects of your agentic workflows, by using our comprehensive suite of built-in evaluators. In general, agents emit agent messages. Transforming agent messages into the right evaluation data so that you can use our evaluators can be a nontrivial task. If you use Azure AI Foundry Agent Service to build your agent, you can seamlessly evaluate it via our converter support. If you build your agent outside Azure AI Foundry Agent Service, you can still use our evaluators as appropriate to your agentic workflow, by parsing your agent messages into the required data formats. See examples in Evaluate other agents.
Get started
Install the evaluators package from the Azure AI evaluation SDK:
pip install azure-ai-evaluation
Evaluate Azure AI agents
If you use Azure AI Foundry Agent Service, you can seamlessly evaluate your agents via our converter support for Azure AI agent threads and runs. We support this list of evaluators for Azure AI agent messages from our converter:
- Quality:
IntentResolution
,ToolCallAccuracy
,TaskAdherence
,Relevance
,Coherence
,Fluency
- Safety:
CodeVulnerabilities
,Violence
,Self-harm
,Sexual
,HateUnfairness
,IndirectAttack
,ProtectedMaterials
Note
ToolCallAccuracyEvaluator
supports only the Function Tool evaluation of the Azure AI Agent, and doesn't support the Built-in Tool evaluation. The agent messages must have at least one Function Tool actually called to be evaluated.
Here's an example that shows you how to seamlessly build and evaluate an Azure AI agent. Separately from evaluation, Azure AI Foundry Agent Service requires pip install azure-ai-projects azure-identity
, an Azure AI project connection string, and the supported models.
Create agent threads and runs
See the following code to create agent threads and runs:
import os, json
import pandas as pd
from azure.ai.projects import AIProjectClient
from azure.identity import DefaultAzureCredential
from typing import Set, Callable, Any
from azure.ai.projects.models import FunctionTool, ToolSet
from dotenv import load_dotenv
load_dotenv()
# Define a custom Python function.
def fetch_weather(location: str) -> str:
"""
Fetches the weather information for the specified location.
:param location (str): The location to fetch weather for.
:return: Weather information as a JSON string.
:rtype: str
"""
# In a real-world scenario, you'd integrate with a weather API.
# In the following code snippet, we mock the response.
mock_weather_data = {"Seattle": "Sunny, 25°C", "London": "Cloudy, 18°C", "Tokyo": "Rainy, 22°C"}
weather = mock_weather_data.get(location, "Weather data not available for this location.")
weather_json = json.dumps({"weather": weather})
return weather_json
user_functions: Set[Callable[..., Any]] = {
fetch_weather,
}
# Add tools that the agent will use.
functions = FunctionTool(user_functions)
toolset = ToolSet()
toolset.add(functions)
# Create the agent.
AGENT_NAME = "Seattle Tourist Assistant"
project_client = AIProjectClient.from_connection_string(
credential=DefaultAzureCredential(),
conn_str=os.environ["PROJECT_CONNECTION_STRING"],
)
agent = project_client.agents.create_agent(
model=os.environ["MODEL_DEPLOYMENT_NAME"],
name=AGENT_NAME,
instructions="You are a helpful assistant",
toolset=toolset,
)
print(f"Created agent, ID: {agent.id}")
thread = project_client.agents.create_thread()
print(f"Created thread, ID: {thread.id}")
# Create a message to thread.
MESSAGE = "Can you fetch me the weather in Seattle?"
message = project_client.agents.create_message(
thread_id=thread.id,
role="user",
content=MESSAGE,
)
print(f"Created message, ID: {message.id}")
run = project_client.agents.create_and_process_run(thread_id=thread.id, agent_id=agent.id)
print(f"Run finished with status: {run.status}")
if run.status == "failed":
print(f"Run failed: {run.last_error}")
print(f"Run ID: {run.id}")
# Display messages.
for message in project_client.agents.list_messages(thread.id, order="asc").data:
print(f"Role: {message.role}")
print(f"Content: {message.content[0].text.value}")
print("-" * 40)
Evaluate a single agent run
After you create agent runs, you can easily use our converter to transform the Azure AI agent thread data into the required evaluation data that the evaluators can understand.
import json, os
from azure.ai.evaluation import AIAgentConverter, IntentResolutionEvaluator
# Initialize the converter for Azure AI agents.
converter = AIAgentConverter(project_client)
# Specify the thread and run the ID.
thread_id = thread.id
run_id = run.id
converted_data = converter.convert(thread_id, run_id)
And that's it! You don't need to read the input requirements for each evaluator and do any work to parse them. You need only to select your evaluator and call the evaluator on this single run. For model choice, we recommend a strong reasoning model like o3-mini
and later models. We set up a list of quality and safety evaluators in quality_evaluators
and safety_evaluators
and reference them in Evaluating multiples agent runs or a thread.
# This is specific to agentic workflows.
from azure.ai.evaluation import IntentResolutionEvaluator, TaskAdherenceEvaluator, ToolCallAccuracyEvaluator
# Other quality, risk, and safety metrics:
from azure.ai.evaluation import RelevanceEvaluator, CoherenceEvaluator, CodeVulnerabilityEvaluator, ContentSafetyEvaluator, IndirectAttackEvaluator, FluencyEvaluator
from azure.ai.projects.models import ConnectionType
from azure.identity import DefaultAzureCredential
import os
from dotenv import load_dotenv
load_dotenv()
model_config = project_client.connections.get_default(
connection_type=ConnectionType.AZURE_OPEN_AI,
include_credentials=True) \
.to_evaluator_model_config(
deployment_name="o3-mini",
api_version="2023-05-15",
include_credentials=True
)
quality_evaluators = {evaluator.__name__: evaluator(model_config=model_config) for evaluator in [IntentResolutionEvaluator, TaskAdherenceEvaluator, ToolCallAccuracyEvaluator, CoherenceEvaluator, FluencyEvaluator, RelevanceEvaluator]}
## Using Azure AI Foundry Hub
azure_ai_project = {
"subscription_id": os.environ.get("AZURE_SUBSCRIPTION_ID"),
"resource_group_name": os.environ.get("AZURE_RESOURCE_GROUP"),
"project_name": os.environ.get("AZURE_PROJECT_NAME"),
}
## Using Azure AI Foundry Development Platform, example: AZURE_AI_PROJECT=https://your-account.services.ai.azure.com/api/projects/your-project
azure_ai_project = os.environ.get("AZURE_AI_PROJECT")
safety_evaluators = {evaluator.__name__: evaluator(azure_ai_project=azure_ai_project, credential=DefaultAzureCredential()) for evaluator in[ContentSafetyEvaluator, IndirectAttackEvaluator, CodeVulnerabilityEvaluator]}
# Reference the quality and safety evaluator list above.
quality_and_safety_evaluators = {**quality_evaluators, **safety_evaluators}
for name, evaluator in quality_and_safety_evaluators.items():
try:
result = evaluator(**converted_data)
print(name)
print(json.dumps(result, indent=4))
except:
print("Note: if there is no tool call to evaluate in the run history, ToolCallAccuracyEvaluator will raise an error")
pass
Output format
AI-assisted quality evaluators provide a result for a query and response pair. The result is a dictionary that contains:
{metric_name}
: Provides a numerical score, on a Likert scale (integer 1 to 5) or a float between 0 and 1.{metric_name}_label
: Provides a binary label (if the metric naturally outputs a binary score).{metric_name}_reason
: Explains why a certain score or label was given for each data point.
To further improve intelligibility, all evaluators accept a binary threshold (unless their outputs are already binary) and output two new keys. For the binarization threshold, a default is set, which the user can override. The two new keys are:
{metric_name}_result
: A "pass" or "fail" string based on a binarization threshold.{metric_name}_threshold
: A numerical binarization threshold set by default or by the user.additional_details
: Contains debugging information about the quality of a single agent run.
See the following example output for some evaluators:
{
"intent_resolution": 5.0, # likert scale: 1-5 integer
"intent_resolution_result": "pass", # pass because 5 > 3 the threshold
"intent_resolution_threshold": 3,
"intent_resolution_reason": "The assistant correctly understood the user's request to fetch the weather in Seattle. It used the appropriate tool to get the weather information and provided a clear and accurate response with the current weather conditions in Seattle. The response fully resolves the user's query with all necessary information.",
"additional_details": {
"conversation_has_intent": true,
"agent_perceived_intent": "fetch the weather in Seattle",
"actual_user_intent": "fetch the weather in Seattle",
"correct_intent_detected": true,
"intent_resolved": true
}
}
{
"task_adherence": 5.0, # likert scale: 1-5 integer
"task_adherence_result": "pass", # pass because 5 > 3 the threshold
"task_adherence_threshold": 3,
"task_adherence_reason": "The response accurately follows the instructions, fetches the correct weather information, and relays it back to the user without any errors or omissions."
}
{
"tool_call_accuracy": 1.0, # this is the average of all correct tool calls (or passing rate)
"tool_call_accuracy_result": "pass", # pass because 1.0 > 0.8 the threshold
"tool_call_accuracy_threshold": 0.8,
"per_tool_call_details": [
{
"tool_call_accurate": true,
"tool_call_accurate_reason": "The tool call is directly relevant to the user's query, uses the correct parameter, and the parameter value is correctly extracted from the conversation.",
"tool_call_id": "call_2svVc9rNxMT9F50DuEf1XExx"
}
]
}
Evaluate multiple agent runs or threads
To evaluate multiple agent runs or threads, we recommend using the batch evaluate()
API for asynchronous evaluation. First, convert your agent thread data into a file via our converter support:
import json
from azure.ai.evaluation import AIAgentConverter
# Initialize the converter.
converter = AIAgentConverter(project_client)
# Specify a file path to save the agent output (evaluation input data) to.
filename = os.path.join(os.getcwd(), "evaluation_input_data.jsonl")
evaluation_data = converter.prepare_evaluation_data(thread_ids=thread_id, filename=filename)
print(f"Evaluation data saved to {filename}")
With the evaluation data prepared in one line of code, you can select the evaluators to assess the agent quality and submit a batch evaluation run. In the following example, we reference the same list of quality and safety evaluators in section Evaluate a single agent run quality_and_safety_evaluators
:
import os
from dotenv import load_dotenv
load_dotenv()
# Batch evaluation API (local):
from azure.ai.evaluation import evaluate
response = evaluate(
data=filename,
evaluation_name="agent demo - batch run",
evaluators=quality_and_safety_evaluators,
# Optionally, log your results to your Azure AI Foundry project for rich visualization.
azure_ai_project={
"subscription_id": os.environ["AZURE_SUBSCRIPTION_ID"],
"project_name": os.environ["PROJECT_NAME"],
"resource_group_name": os.environ["RESOURCE_GROUP_NAME"],
}
)
# Inspect the average scores at a high level.
print(response["metrics"])
# Use the URL to inspect the results on the UI.
print(f'AI Foundary URL: {response.get("studio_url")}')
After the URL, you'll be redirected to Foundry. You can view your evaluation results in your Azure AI project and debug your application. Using reason fields and pass/fail, you can easily assess the quality and safety performance of your applications. You can run and compare multiple runs to test for regression or improvements.
With the Azure AI Evaluation SDK client library, you can seamlessly evaluate your Azure AI agents via our converter support, which enables observability and transparency into agentic workflows.
Evaluate other agents
If you're using agents outside Azure AI Foundry Agent Service, you can still evaluate them by preparing the right data for the evaluators of your choice.
Agents typically emit messages to interact with a user or other agents. Our built-in evaluators can accept simple data types such as strings in query
, response
, and ground_truth
according to the single-turn data input requirements. However, it can be a challenge to extract these simple data types from agent messages, due to the complex interaction patterns of agents and framework differences. For example, a single user query can trigger a long list of agent messages, typically with multiple tool calls invoked.
As illustrated in the following example, we enable agent message support specifically for the built-in evaluators IntentResolution
, ToolCallAccuracy
, and TaskAdherence
to evaluate these aspects of agentic workflow. These evaluators take tool_calls
or tool_definitions
as parameters unique to agents.
Evaluator | query |
response |
tool_calls |
tool_definitions |
---|---|---|---|---|
IntentResolutionEvaluator |
Required: Union[str, list[Message]] |
Required: Union[str, list[Message]] |
Doesn't apply | Optional: list[ToolCall] |
ToolCallAccuracyEvaluator |
Required: Union[str, list[Message]] |
Optional: Union[str, list[Message]] |
Optional: Union[dict, list[ToolCall]] |
Required: list[ToolDefinition] |
TaskAdherenceEvaluator |
Required: Union[str, list[Message]] |
Required: Union[str, list[Message]] |
Doesn't apply | Optional: list[ToolCall] |
Message
:dict
OpenAI-style message that describes agent interactions with a user, where thequery
must include a system message as the first message.ToolCall
:dict
that specifies tool calls invoked during agent interactions with a user.ToolDefinition
:dict
that describes the tools available to an agent.
For ToolCallAccuracyEvaluator
, either response
or tool_calls
must be provided.
Following are examples of the two data formats: simple agent data, and agent messages. However, due to the unique requirements of these evaluators, we recommend referring to the Sample notebooks, which illustrate the possible input paths for each evaluator.
As with other built-in AI-assisted quality evaluators, IntentResolutionEvaluator
and TaskAdherenceEvaluator
output a Likert score (integer 1-5; higher score is better). ToolCallAccuracyEvaluator
outputs the passing rate of all tool calls made (a float between 0 and 1) based on user query. To further improve intelligibility, all evaluators accept a binary threshold and output two new keys. For the binarization threshold, a default is set and the user can override it. The two new keys are:
{metric_name}_result
: A "pass" or "fail" string based on a binarization threshold.{metric_name}_threshold
: A numerical binarization threshold set by default or by the user.
Simple agent data
In simple agent data format, query
and response
are simple Python strings. For example:
import os
import json
from azure.ai.evaluation import AzureOpenAIModelConfiguration
from azure.identity import DefaultAzureCredential
from azure.ai.evaluation import IntentResolutionEvaluator, ResponseCompletenessEvaluator
model_config = AzureOpenAIModelConfiguration(
azure_endpoint=os.environ["AZURE_OPENAI_ENDPOINT"],
api_key=os.environ["AZURE_OPENAI_API_KEY"],
api_version=os.environ["AZURE_OPENAI_API_VERSION"],
azure_deployment=os.environ["MODEL_DEPLOYMENT_NAME"],
)
intent_resolution_evaluator = IntentResolutionEvaluator(model_config)
# Evaluate the query and response as strings.
# The following is a positive example. Intent is identified and understood and the response correctly resolves user intent.
result = intent_resolution_evaluator(
query="What are the opening hours of the Eiffel Tower?",
response="Opening hours of the Eiffel Tower are 9:00 AM to 11:00 PM.",
)
print(json.dumps(result, indent=4))
See the following output (reference Output format for details):
{
"intent_resolution": 5.0,
"intent_resolution_result": "pass",
"intent_resolution_threshold": 3,
"intent_resolution_reason": "The response provides the opening hours of the Eiffel Tower, which directly addresses the user's query. The information is clear, accurate, and complete, fully resolving the user's intent.",
"additional_details": {
"conversation_has_intent": true,
"agent_perceived_intent": "inquire about the opening hours of the Eiffel Tower",
"actual_user_intent": "inquire about the opening hours of the Eiffel Tower",
"correct_intent_detected": true,
"intent_resolved": true
}
}
See the following examples of tool_calls
and tool_definitions
for ToolCallAccuracyEvaluator
:
import json
query = "How is the weather in Seattle?"
tool_calls = [{
"type": "tool_call",
"tool_call_id": "call_CUdbkBfvVBla2YP3p24uhElJ",
"name": "fetch_weather",
"arguments": {
"location": "Seattle"
}
},
{
"type": "tool_call",
"tool_call_id": "call_CUdbkBfvVBla2YP3p24uhElJ",
"name": "fetch_weather",
"arguments": {
"location": "London"
}
}]
tool_definitions = [{
"name": "fetch_weather",
"description": "Fetches the weather information for the specified location.",
"parameters": {
"type": "object",
"properties": {
"location": {
"type": "string",
"description": "The location to fetch weather for."
}
}
}
}]
response = tool_call_accuracy(query=query, tool_calls=tool_calls, tool_definitions=tool_definitions)
print(json.dumps(response, indent=4))
See the following output (reference Output format for details):
{
"tool_call_accuracy": 0.5,
"tool_call_accuracy_result": "fail",
"tool_call_accuracy_threshold": 0.8,
"per_tool_call_details": [
{
"tool_call_accurate": true,
"tool_call_accurate_reason": "The TOOL CALL is directly relevant to the user's query, uses appropriate parameters, and the parameter values are correctly extracted from the conversation. It is likely to provide useful information to advance the conversation.",
"tool_call_id": "call_CUdbkBfvVBla2YP3p24uhElJ"
},
{
"tool_call_accurate": false,
"tool_call_accurate_reason": "The TOOL CALL is not relevant to the user's query about the weather in Seattle and uses a parameter value that is not present or inferred from the conversation.",
"tool_call_id": "call_CUdbkBfvVBla2YP3p24uhElJ"
}
]
}
Agent messages
In agent message format, query
and response
are a list of OpenAI-style messages. Specifically, query
carries the past agent-user interactions leading up to the last user query and requires the system message (of the agent) on top of the list; and response
carries the last message of the agent in response to the last user query. See the following example:
import json
# The user asked a question.
query = [
{
"role": "system",
"content": "You are a friendly and helpful customer service agent."
},
# Past interactions are omitted.
# ...
{
"createdAt": "2025-03-14T06:14:20Z",
"role": "user",
"content": [
{
"type": "text",
"text": "Hi, I need help with the last 2 orders on my account #888. Could you please update me on their status?"
}
]
}
]
# The agent emits multiple messages to fulfill the request.
response = [
{
"createdAt": "2025-03-14T06:14:30Z",
"run_id": "0",
"role": "assistant",
"content": [
{
"type": "text",
"text": "Hello! Let me quickly look up your account details."
}
]
},
{
"createdAt": "2025-03-14T06:14:35Z",
"run_id": "0",
"role": "assistant",
"content": [
{
"type": "tool_call",
"tool_call_id": "tool_call_20250310_001",
"name": "get_orders",
"arguments": {
"account_number": "888"
}
}
]
},
# Many more messages are omitted.
# ...
# Here is the agent's final response:
{
"createdAt": "2025-03-14T06:15:05Z",
"run_id": "0",
"role": "assistant",
"content": [
{
"type": "text",
"text": "The order with ID 123 has been shipped and is expected to be delivered on March 15, 2025. However, the order with ID 124 is delayed and should now arrive by March 20, 2025. Is there anything else I can help you with?"
}
]
}
]
# An example of tool definitions available to the agent:
tool_definitions = [
{
"name": "get_orders",
"description": "Get the list of orders for a given account number.",
"parameters": {
"type": "object",
"properties": {
"account_number": {
"type": "string",
"description": "The account number to get the orders for."
}
}
}
},
# Other tool definitions are omitted.
# ...
]
result = intent_resolution_evaluator(
query=query,
response=response,
# Optionally, provide the tool definitions.
tool_definitions=tool_definitions
)
print(json.dumps(result, indent=4))
See the following output (reference Output format for details):
{
"tool_call_accuracy": 0.5,
"tool_call_accuracy_result": "fail",
"tool_call_accuracy_threshold": 0.8,
"per_tool_call_details": [
{
"tool_call_accurate": true,
"tool_call_accurate_reason": "The TOOL CALL is directly relevant to the user's query, uses appropriate parameters, and the parameter values are correctly extracted from the conversation. It is likely to provide useful information to advance the conversation.",
"tool_call_id": "call_CUdbkBfvVBla2YP3p24uhElJ"
},
{
"tool_call_accurate": false,
"tool_call_accurate_reason": "The TOOL CALL is not relevant to the user's query about the weather in Seattle and uses a parameter value that is not present or inferred from the conversation.",
"tool_call_id": "call_CUdbkBfvVBla2YP3p24uhElJ"
}
]
}
This evaluation schema helps you parse your agent data outside Azure AI Foundry Agent Service, so that you can use our evaluators to support observability into your agentic workflows.
Sample notebooks
Now you're ready to try a sample for each of these evaluators:
- Intent resolution
- Tool call accuracy
- Task adherence
- Response completeness
- End-to-end Azure AI agent evaluation
Related content
- Azure AI Evaluation Python SDK client reference documentation
- Azure AI Evaluation SDK client troubleshooting guide
- Learn more about the evaluation metrics
- Evaluate your Generative AI applications remotely on the cloud
- Learn more about simulating test datasets for evaluation
- View your evaluation results in an Azure AI project
- Get started building a chat app by using the Azure AI Foundry SDK
- Get started with evaluation samples
