Thank you for that information, your AMD graphics on that processor does not support 'Hardware Accelerated GPU Scheduling' you will not be able to enable that on your device.
Hardware accellerated GPU scheduling missing from Windows 11 settings.
Anonymous
So this setting dosen't show up for me. I have tried The RegEdit solution by adding DWORD called "HwSchMode" with the vaue set to 2 and still nothing apears. What can I do now? Thanks.
Windows for home | Windows 11 | Settings
Locked Question. This question was migrated from the Microsoft Support Community. You can vote on whether it's helpful, but you can't add comments or replies or follow the question.
6 answers
Sort by: Most helpful
-
Anonymous
2024-01-10T17:44:20+00:00 -
Anonymous
2024-01-10T15:34:51+00:00 Images of RegEdit and Graphic settings.
-
Anonymous
2024-01-10T17:32:23+00:00 You seem to only have integrated AMD graphics on your processor, in Device Manager, expand the Processors section, what is the model of your AMD processor?
-
Anonymous
2024-01-10T17:14:35+00:00 Hi Dave, Thank you for your reply. For some context this is on my ROG ALLY Z1 Extreme. screenshot to follow.
-
Anonymous
2024-01-10T17:08:41+00:00 Hi, I am Dave, I will help you with this.
That setting (Hardware accelerated GPU scheduling ) will only appear in your Settings app, if your graphics card supports it and if it supports WDDM 2.7 or higher.
Open Device Manager, then expand the Display Adapters section, please provide a screenshot of that window.
