Troubleshoot SQL Server ingestion

This page describes common issues with the Microsoft SQL Server connector in Databricks Lakeflow Connect and how to resolve them.

For general troubleshooting guidance that applies to all managed ingestion pipelines, see Troubleshoot managed ingestion pipelines.

Check if CDC is enabled for a database or a table

To check if CDC is enabled for database <database-name>:

select is_cdc_enabled from sys.databases where name='<database-name>';

To check if CDC is enabled for table <schema-name>.<table-name>:

select t.is_tracked_by_cdc
from sys.tables t join sys.schemas s on t.schema_id = s.schema_id
where s.name='<schema-name>' and t.name='<table-name>';

Check if change tracking is enabled for a database or a table

To check if change tracking is enabled for database\<database-name\>:

select ctdb.*

from sys.change_tracking_databases ctdb join sys.databases db

    on db.database_id  = ctdb.database_id

where db.name = '<MyDatabaseName>'

To check if change tracking is enabled for table <schema-name>.<table-name>:

select s.name schema_name, t.name table_name, ct.*

from sys.change_tracking_tables ct join sys.tables t

    on ct.object_id = t.object_id

    join sys.schemas s on t.schema_id = s.schema_id

where s.name = '<MySchemaName>' and t.name = '<MyTableName>'

Time out on waiting for table token

The ingestion pipeline might time out while waiting for information to be provided by the gateway. This might be because:

• You are running an older version of the gateway.
• There was an error generating the necessary information. Check the gateway driver logs for errors.

Note

The full refresh flow significantly reduces the occurrence of timeout errors during full refresh operations. See Full refresh behavior (CDC).

default auth: cannot configure default credentials

If you receive this error, there is an issue with discovering the current user credentials. Try replacing the following:

w = WorkspaceClient()

with:

w = WorkspaceClient(host=input('Databricks Workspace URL: '), token=input('Token: '))

See Authentication in the Databricks SDK for Python documentation.

tech.replicant.common.ExtractorException: com.microsoft.sqlserver.jdbc.SQLServerException: Invalid column name 'SERIAL_NUMBER'.

You might receive this error if you're using an older version of an internal table. Run the following on the connected database:

drop table dbo.replicate_io_audit_ddl_trigger_1;

PERMISSION_DENIED: You are not authorized to create clusters. Please contact your administrator.

Contact a Databricks account admin to grant you Unrestricted cluster creation permissions.

DLT ERROR CODE: INGESTION_GATEWAY_INTERNAL_ERROR

Check the stdout file(s) in the driver logs.

Source table naming conflict

Ingestion pipeline error: "org.apache.spark.sql.catalyst.ExtendedAnalysisException: Cannot have multiple queries named `XYZ_snapshot_load` for `XYZ`. Additional queries on that table must be named. Note that unnamed queries default to the same name as the table.

This indicates that there is a name conflict due to multiple source tables named XYZ in different source schemas that are being ingested by the same ingestion pipeline to the same destination schema.

Create multiple gateway-pipeline pairs writing these conflicting tables to different destination schemas.

Incompatible schema changes

An incompatible schema change causes the ingestion pipeline to fail with an INCOMPATIBLE_SCHEMA_CHANGE error. To continue replication, trigger a full refresh of the affected tables.

Note

Databricks can not guarantee that at time the ingestion pipeline fails for an incompatible schema change, all rows prior to the schema change have been ingested.

NON_INCREMENTAL_SCHEMA_CHANGE

NON_INCREMENTAL_SCHEMA_CHANGE: Column '<column>' was added to table '<table>'. A full refresh is required to continue incremental ingestion.

This error occurs when a new column is added to a source table while incremental ingestion is active. The connector cannot backfill values for the new column from historical change data, so a full refresh is required.

Run a full refresh of the affected table to resume ingestion. See Fully refresh target tables.

MISSING_TABLE_IN_SOURCE

MISSING_TABLE_IN_SOURCE: Table '<schema>.<table>' could not be found in the source database.

This error occurs when a table that was previously available in the source database can no longer be found. Common causes include:

• The table was renamed or dropped in the source.
• The table is temporarily unavailable, for example during a maintenance window.

To resolve:

• If the table is temporarily unavailable, wait for maintenance to complete, then retry the pipeline.
• If the table was renamed or recreated, run a full refresh of the affected table.
• If the table was dropped intentionally, remove it from the pipeline.

TLS server certificate errors

For troubleshooting TLS server certificate validation errors, see Troubleshoot TLS certificate errors.
