Quickstart: Deploy an application using the Dapr extension for Azure Kubernetes Service (AKS) or Arc-enabled Kubernetes

In this quickstart, you use the Dapr extension in an AKS or Arc-enabled Kubernetes cluster. You deploy a hello world example, which consists of a Python application that generates messages and a Node.js application that consumes and persists the messages.

Prerequisites

Clone the repository

  1. Clone the Dapr quickstart repository using the git clone command.

    git clone https://github.com/Azure-Samples/dapr-aks-extension-quickstart.git

  2. Change to the dapr-aks-extension-quickstart directory.

    cd dapr-aks-extension-quickstart

Create and configure a Redis store

Open the Azure portal to start the Azure Managed Redis creation flow.

  1. Fill out the recommended information according to the Create an Azure Managed Redis instance quickstart.

  2. Select Create to start the Redis instance deployment.

Verify resource information

  1. Once the Redis resource is deployed, navigate to its overview page.

  2. Take note of:

    • The hostname, found in the Essentials section of the resource overview page. The hostname format looks similar to: <your-cache-name>.<region>.redis.azure.net.
    • The SSL port, found in Settings > Advanced settings. The default value is 10000.

  3. In your terminal, enable access-key authentication on the default database.

    az redisenterprise database update \
    --cluster-name <REDIS_NAME> \
    --resource-group <RESOURCE_GROUP> \
    --access-keys-auth Enabled

  4. Retrieve the primary key for the default database and save it to an environment variable.

    export REDIS_PRIMARY_KEY=$(az redisenterprise database list-keys \
    --cluster-name <REDIS_NAME> \
    --resource-group <RESOURCE_GROUP> \
    --query primaryKey \
    -o tsv)

Enable public network access

For this scenario, your Azure Managed Redis instance uses public network access. Be sure to clean up resources after you finish with this quickstart.

  1. In the resource menu, under Settings, select Networking.

  2. Set Public network access to Enabled.

Configure the Dapr components

In the redis.yaml file, you configure the component to use access-key authentication with TLS.

- name: redisPassword
    secretKeyRef:
        name: redis-secret
        key: redisPassword
- name: useEntraID
    value: "false"
- name: enableTLS
  value: true

  1. In your preferred code editor, navigate to the deploy directory in the sample repo and open redis.yaml.

  2. For redisHost, replace the placeholder <REDIS_HOST>:10000 value with the Azure Managed Redis hostname you saved earlier from the Azure portal.

    - name: redisHost
  value: <your-cache-name>.<region>.redis.azure.net:10000

  3. Create the Kubernetes secret used by redisPassword.

    kubectl create secret generic redis-secret \
    --from-literal=redisPassword="$REDIS_PRIMARY_KEY"

Apply the configuration

Apply the redis.yaml file using the kubectl apply command.

kubectl apply -f ./deploy/redis.yaml

Expected output

component.dapr.io/statestore created

Deploy the Node.js app with the Dapr sidecar

Configure the Node.js app

  1. Go to the deploy directory and open workload-identity.yaml.

  2. Replace <MANAGED_IDENTITY_CLIENT_ID> with the client ID of the user-assigned managed identity you created.

  3. Apply the service account manifest before you deploy app manifests.

    kubectl apply -f ./deploy/workload-identity.yaml

In node.yaml, the pod spec uses the workload identity label and the shared workload-sa service account:

labels:
  app: node
  azure.workload.identity/use: "true"

Apply the configuration

  1. Apply the Node.js app deployment to your cluster using the kubectl apply command.

    kubectl apply -f ./deploy/node.yaml

  2. Kubernetes deployments are asynchronous, so before moving on to the next steps, verify the deployment is complete with the following command:

    kubectl rollout status deploy/nodeapp

  3. Access your service using the kubectl get svc command.

    kubectl get svc nodeapp

  4. Make note of the EXTERNAL-IP in the output, and set it as an environment variable.

    export EXTERNAL_IP=<EXTERNAL-IP>

Verify the Node.js service

  1. Using curl, call the service with your EXTERNAL-IP.

    curl $EXTERNAL_IP/ports

    Example output

    {"DAPR_HTTP_ENDPOINT":"http://localhost:3500","DAPR_GRPC_ENDPOINT":"http://localhost:50001"}

  2. Submit an order to the application.

    curl --request POST --data "@sample.json" --header Content-Type:application/json $EXTERNAL_IP/neworder

  3. Confirm the order.

    curl $EXTERNAL_IP/order

    Expected output

    { "orderId": "42" }

Deploy the Python app with the Dapr sidecar

Configure the Python app

In python.yaml, the pod spec uses the workload identity label and the shared workload-sa service account:

labels:
    app: python
    azure.workload.identity/use: "true"

Apply the configuration

  1. Deploy the Python app to your Kubernetes cluster using the kubectl apply command.

    kubectl apply -f ./deploy/python.yaml

  2. Kubernetes deployments are asynchronous, so before moving on to the next steps, verify the deployment is complete with the following command:

    kubectl rollout status deploy/pythonapp

Observe messages and confirm persistence

Now that both the Node.js and Python applications are deployed, you can watch messages come through.

  1. Get the logs of the Node.js app using the kubectl logs command.

    kubectl logs --selector=app=node -c node --tail=-1

    Expected output

    Got a new order! Order ID: 1
Successfully persisted state
Got a new order! Order ID: 2
Successfully persisted state
Got a new order! Order ID: 3
Successfully persisted state

  2. Using curl, call the Node.js app's order endpoint to get the latest order.

    curl $EXTERNAL_IP/order

    You should see the latest JSON output in the response.

Clean up resources

If you no longer plan to use the resources from this quickstart, you can remove the resource group, cluster, namespace, and all related resources using the az group delete command.

az group delete --name <your-resource-group>
