RCA: Testing of the OPTIONS command failed

Question

Hi,
we use RCA to test our ActiveSync server. Recently we got the following error. This is really strange, since test passed multiple times and compared to trace data the response from our server is exactly the same as send before:

The Microsoft Remote Connectivity Analyzer assumes our server is sending the following HTTP response headers:

Pragma: no-cache
Allow:OPTIONS
Allow: POST
Public: OPTIONS, POST
MS-ASProtocolVersions: 2.5,12.0,12.1,14.0,14.1,16.0,16.1
MS-ASProtocolCommands: Autodiscover,Sync,SendMail,SmartForward,SmartReply,GetAttachment,FolderSync,FolderCreate,FolderDelete,FolderUpdate,MoveItems,GetItemEstimate,MeetingResponse,Search,Settings,Ping,ItemOperations,Provision,ResolveRecipients,Find,GetHierarchy Strict-Transport-Security: max-age=31536000
Content-Length: 0
Cache-Control: no-store
Cache-Control: no-cache
Cache-Control: must-revalidate
Content-Type: application/vnd.ms-sync.wbxml
Date: Sun, 11 Sep 2022 08:50:16 GMT
Expires: Thu, 19 Nov 1981 08:52:00 GMT
Set-Cookie: roundcube_sessid=9070757ab1b0a36ced98f2d865112a29; path=/; secure; HttpOnly
Server: Apache


The only strange thing is "Expires" header. We did not send it, but we added it. Then we tried again to send

Response: HTTP/1.1 200 Ok
Allow: OPTIONS, POST
Public: OPTIONS, POST
Content-Type: application/vnd.ms-sync.wbxml
MS-ASProtocolVersions: 2.5,12.0,12.1,14.0,14.1,16.0,16.1
MS-ASProtocolCommands: Autodiscover,Sync,SendMail,SmartForward,SmartReply,GetAttachment,FolderSync,FolderCreate,FolderDelete,FolderUpdate,MoveItems,GetItemEstimate,MeetingResponse,Search,Settings,Ping,ItemOperations,Provision,ResolveRecipients,Find,GetHierarchy
Content-Length: 0
Date: Sun, 11 Sep 2022 08:54:51 GMT
Expires: Sun, 11 Sep 2022 09:11:31 GMT

This is still not accepted by RCA. Everything should be according to [MS-ASHTTP].

Any hints?

Answer 1

@Joy Zhang-MSFT

Hi,
thank you for trying to provide help. Out server is NOT an Exchange server. This is an implementation of a ActiveSync server in PHP. And we found the bug our self. Server was not sending back the "MS-Server-ActiveSync" header. Fixing that, the conformance test passed successfully.
