How to create an undetermined amount of grid columns?

Charles He-MSFT 96 Reputation points Microsoft Employee
2020-02-25T02:32:13.2+00:00

Source thread: How to create an undertermined amount of grid columns?, answered by Peter Fleischer.

I have a text property bound to a TextBox. For each letter in the TextBox, I want to create a gird cell with a TextBlock inside it. So if I have a six letter word in the TextBox I get six grid columns with a TextBlock inside each column. How can I do this?

Windows Presentation Foundation
Windows Presentation Foundation
A part of the .NET Framework that provides a unified programming model for building line-of-business desktop applications on Windows.
2,701 questions
{count} votes

Accepted answer
  1. Alex Li-MSFT 1,096 Reputation points
    2020-02-25T02:42:53.713+00:00

    Hi,

    Welcome to our Microsoft Q&A platform!

    You can use ItemsTemplate in ControlTemplate of TextBox. Try following demo.

    Xaml:

    <Window x:Class="Window80"
            xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
            xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
            xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
            xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
            xmlns:local="clr-namespace:WpfApp1"
            mc:Ignorable="d"
            Title="Window80" Height="450" Width="800">
      <Window.DataContext>
        <local:Window80VM/>
      </Window.DataContext>
      <StackPanel>
        <TextBox Text="{Binding Word, UpdateSourceTrigger=PropertyChanged}" Margin="5"/>
        <TextBox Margin="5">
          <TextBox.Template>
            <ControlTemplate>
              <ItemsControl ItemsSource="{Binding LetterList}">
                <ItemsControl.ItemTemplate>
                  <DataTemplate>
                    <Border BorderBrush="Red" BorderThickness="2" Width="20" Margin="5 0 5 0">
                      <TextBlock Text="{Binding}" HorizontalAlignment="Center"/>
                    </Border>
                  </DataTemplate>
                </ItemsControl.ItemTemplate>
                <ItemsControl.ItemsPanel>
                  <ItemsPanelTemplate>
                    <VirtualizingStackPanel IsItemsHost="True"
                                      Orientation="Horizontal"
                                      VerticalAlignment="Top"/>
                  </ItemsPanelTemplate>
                </ItemsControl.ItemsPanel>
              </ItemsControl>
            </ControlTemplate>
          </TextBox.Template>
        </TextBox>
      </StackPanel>
    </Window>


    and ViewModel:

    Imports System.ComponentModel
    Imports System.Runtime.CompilerServices

    Public Class Window80VM
      Implements INotifyPropertyChanged

      Private _word As String
      Public Property Word As String
        Get
          Return Me._word
        End Get
        Set(value As String)
          Me._word = value
          LetterList = (From item In value).ToList
          OnPropertyChanged(NameOf(LetterList))
        End Set
      End Property

      Public Property LetterList As List(Of Char)

      Public Class Letter
        Public Property l As String
      End Class

      Public Event PropertyChanged As PropertyChangedEventHandler Implements INotifyPropertyChanged.PropertyChanged
      Private Sub OnPropertyChanged(<CallerMemberName> Optional propName As String = "")
        RaiseEvent PropertyChanged(Me, New PropertyChangedEventArgs(propName))
      End Sub

    End Class



    Thanks.

    2 people found this answer helpful.
    0 comments No comments
