aks 1.24 ingress not exposed

Question

As soon as you upgrade from aks 1.2x version to 1.24, you will not be able to access the ingress through the controller.

In other words, I can't connect to the pod.
Is there any way to check this?
It worked fine in 1.23, but I can't connect as soon as I upgrade to 1.24.

With port-forward, the host connects to the pod.

Answer 1

Hi @owen.kim ,
Thanks for reaching out to Microsoft QnA.
Can you check the load balancer health probe configuration corresponding to nginx-ingress-controller service IP. If the health probe is configured with protocol “HTTP” and path “/” the nginx-ingress-controller service will most likely fail the load balancer probes.
Check the nginx ingress controller service describe output. If the "service.beta.kubernetes.io/azure-load-balancer-health-probe-request-path=/healthz" annotation is missing the LB health probes will possibly fail.
Could you please update the nginx-ingress-controller service to use the annotation "service.beta.kubernetes.io/azure-load-balancer-health-probe-request-path=/healthz" which will set the correct path of /healthz . That should make the health probes work as expected. If this doesn't help, please reach back and I would check into this further.
Thanks :)

----------

Please don't forget to Accept as answer and Upvote if you think the information provided was useful so that it can help others in the community looking for help on similar issues.

Answer 2

I found out that it only works with local traffic policy. May it help someone.

   service:
     externalTrafficPolicy: Local
     annotations:
       service.beta.kubernetes.io/azure-load-balancer-internal: "true"
       service.beta.kubernetes.io/azure-load-balancer-health-probe-request-path: /healthz

Answer 3

apiVersion: apps/v1
kind: Deployment
metadata:
  name: mario
  labels:
    app: mario
spec:
  replicas: 1
  selector:
    matchLabels:
      app: mario
  template:
    metadata:
      labels:
        app: mario
    spec:
      containers:
      - name: mario
        image: pengbai/docker-supermario
---
apiVersion: v1
kind: Service
metadata:
   name: mario
spec:
  selector:
    app: mario
  ports:
  - port: 80
    protocol: TCP
    targetPort: 8080
  type: ClusterIP
---

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: mario
spec:
  ingressClassName: nginx
  rules:
  - host: mario.test.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: mario
            port:
              number: 80
  tls:
  - hosts:
    - mario.test.com
    secretName: aks-ingress-tls

sample yaml

Answer 4

Thanks! solution still working.... at nov 2022 for kubernetes 1.24.6.

Answer 5

This isn't doing it for me, using internal load balancer. I have these annotations:

   service.beta.kubernetes.io/azure-load-balancer-internal: "true"
   service.beta.kubernetes.io/azure-load-balancer-health-probe-request-path: /healthz

Any idea @srbhatta-MSFT ?
