Errors from APIM creator tool

Question

Errors from APIM creator tool

Ali Shemirani 1

We are using creator tools to generate ARM templates from a given swagger.json file. the swagger file is already validated using OpenAPI specification and successfully goes through creator tool with no error. Now having ARM template files and passing it through CI/CD pipeline recommended by Microsoft we are getting different errors and we have to manually change ARM template files to skip the issues (the expectation is that when ARM templates are successfully generated by creator tools it should execute with no problem)

Here is the content of creator.yml and swagger json file

creator.yml

--------------------------------------

version: 0.0.1
apimServiceName: apim-common-dev-01
apis:
    - name: loan-details1
      type: http
      serviceUrl: https://devpoc-api.cudirect.com
      openApiSpec: .\openapi.json
      suffix: loaddetails1
      subscriptionRequired: true
      isCurrent: true
      products: LoanDetails_Product1
products:
    - displayName: LoanDetails_Product1
      description: Loan Details
      subscriptionRequired: true
      approvalRequired: true
      subscriptionsLimit: 1
      state: notPublished
backends:
    - title: myBackend
      description:
      url: https://dev-connect.cudl.com/LoanDetailsAPI
      protocol: http
      tls:
        validateCertificateChain: false
        validateCertificateName: false
outputLocation: C:\temp\creator
linked: false
linkedTemplatesBaseUrl : https://mystorageaccount.blob.core.windows.net/mycontainer

openapi.json

------------------------------------

{
  "openapi": "3.0.1",
  "info": {
    "title": "Loan Details",
    "version": "1"
  },
  "servers": [
    {
      "url": "https://dev-connect.cudl.com/LoanDetailsAPI"
    }
  ],
  "paths": {
    "/v1/applications/{applicationId}/applicants": {
      "get": {
        "tags": [
          "Application"
        ],
        "description": "<b>SSO Permission Required</b>: Applicants - View",
        "parameters": [
          {
            "name": "CUDC.Lender",
            "in": "header",
            "schema": {
              "type": "string"
            }
          },
          {
            "name": "applicationId",
            "in": "path",
            "required": true,
            "schema": {
              "type": "integer",
              "format": "int32"
            }
          }
        ],
        "responses": {
          "200": {
            "description": "Success",
            "content": {
              "application/json": {
                "schema": {
                  "$ref": "#/components/schemas/ApplicantsResponse"
                }
              },
              "text/json": {
                "schema": {
                  "$ref": "#/components/schemas/ApplicantsResponse"
                }
              },
              "application/xml": {
                "schema": {
                  "$ref": "#/components/schemas/ApplicantsResponse"
                }
              },
              "text/xml": {
                "schema": {
                  "$ref": "#/components/schemas/ApplicantsResponse"
                }
              }
            }
          },
          "404": {
            "description": "Not Found"
          }
        }
      }
    },
    "/v1/applications/{applicationId}/basic": {
      "get": {
        "tags": [
          "Application"
        ],
        "description": "<b>SSO Permission Required</b>: Application-Basic - View",
        "parameters": [
          {
            "name": "CUDC.Lender",
            "in": "header",
            "schema": {
              "type": "string"
            }
          },
          {
            "name": "applicationId",
            "in": "path",
            "required": true,
            "schema": {
              "type": "integer",
              "format": "int32"
            }
          }
        ],
        "responses": {
          "200": {
            "description": "Success",
            "content": {
              "application/json": {
                "schema": {
                  "$ref": "#/components/schemas/ApplicationBasic"
                }
              },
              "text/json": {
                "schema": {
                  "$ref": "#/components/schemas/ApplicationBasic"
                }
              },
              "application/xml": {
                "schema": {
                  "$ref": "#/components/schemas/ApplicationBasic"
                }
              },
              "text/xml": {
                "schema": {
                  "$ref": "#/components/schemas/ApplicationBasic"
                }
              }
            }
          },
          "404": {
            "description": "Not Found"
          }
        }
      }
    },
    "/v1/applications/{applicationId}/decisions": {
      "get": {
        "tags": [
          "Application"
        ],
        "description": "<b>SSO Permission Required</b>: Decisions - View",
        "parameters": [
          {
            "name": "CUDC.Lender",
            "in": "header",
            "schema": {
              "type": "string"
            }
          },
          {
            "name": "applicationId",
            "in": "path",
            "required": true,
            "schema": {
              "type": "integer",
              "format": "int32"
            }
          }
        ],
        "responses": {
          "200": {
            "description": "Success",
            "content": {
              "application/json": {
                "schema": {
                  "type": "array",
                  "items": {
                    "$ref": "#/components/schemas/Decision"
                  }
                }
              },
              "text/json": {
                "schema": {
                  "type": "array",
                  "items": {
                    "$ref": "#/components/schemas/Decision"
                  }
                }
              },
              "application/xml": {
                "schema": {
                  "type": "array",
                  "items": {
                    "$ref": "#/components/schemas/Decision"
                  }
                }
              },
              "text/xml": {
                "schema": {
                  "type": "array",
                  "items": {
                    "$ref": "#/components/schemas/Decision"
                  }
                }
              }
            }
          },
          "404": {
            "description": "Not Found"
          }
        }
      }
    },
    "/v1/applications/{applicationId}/decisions/current": {
      "get": {
        "tags": [
          "Application"
        ],
        "description": "<b>SSO Permission Required</b>: Decisions - View",
        "parameters": [
          {
            "name": "CUDC.Lender",
            "in": "header",
            "schema": {
              "type": "string"
            }
          },
          {
            "name": "applicationId",
            "in": "path",
            "required": true,
            "schema": {
              "type": "integer",
              "format": "int32"
            }
          }
        ],
        "responses": {
          "200": {
            "description": "Success",
            "content": {
              "application/json": {
                "schema": {
                  "$ref": "#/components/schemas/Decision"
                }
              },
              "text/json": {
                "schema": {
                  "$ref": "#/components/schemas/Decision"
                }
              },
              "application/xml": {
                "schema": {
                  "$ref": "#/components/schemas/Decision"
                }
              },
              "text/xml": {
                "schema": {
                  "$ref": "#/components/schemas/Decision"
                }
              }
            }
          },
          "404": {
            "description": "Not Found"
          }
        }
      }
    },
    "/v1/applications/{applicationId}/decisions/{decisionId}": {
      "get": {
        "tags": [
          "Application"
        ],
        "description": "<b>SSO Permission Required</b>: Decisions - View",
        "parameters": [
          {
            "name": "CUDC.Lender",
            "in": "header",
            "schema": {
              "type": "string"
            }
          },
          {
            "name": "applicationId",
            "in": "path",
            "required": true,
            "schema": {
              "type": "integer",
              "format": "int32"
            }
          },
          {
            "name": "decisionId",
            "in": "path",
            "required": true,
            "schema": {
              "type": "integer",
              "format": "int32"
            }
          }
        ],
        "responses": {
          "200": {
            "description": "Success",
            "content": {
              "application/json": {
                "schema": {
                  "$ref": "#/components/schemas/Decision"
                }
              },
              "text/json": {
                "schema": {
                  "$ref": "#/components/schemas/Decision"
                }
              },
              "application/xml": {
                "schema": {
                  "$ref": "#/components/schemas/Decision"
                }
              },
              "text/xml": {
                "schema": {
                  "$ref": "#/components/schemas/Decision"
                }
              }
            }
          },
          "404": {
            "description": "Not Found"
          }
        }
      }
    },
    "/v1/applications/{applicationId}/decisions/{decisionId}/stipulations/{stipulationId}": {
      "get": {
        "tags": [
          "Application"
        ],
        "description": "<b>SSO Permission Required</b>: Decisions - View",
        "parameters": [
          {
            "name": "CUDC.Lender",
            "in": "header",
            "schema": {
              "type": "string"
            }
          },
          {
            "name": "applicationId",
            "in": "path",
            "required": true,
            "schema": {
              "type": "integer",
              "format": "int32"
            }
          },
          {
            "name": "decisionId",
            "in": "path",
            "required": true,
            "schema": {
              "type": "integer",
              "format": "int32"
            }
          },
          {
            "name": "stipulationId",
            "in": "path",
            "required": true,
            "schema": {
              "type": "integer",
              "format": "int32"
            }
          }
        ],
        "responses": {
          "200": {
            "description": "Success",
            "content": {
              "application/json": {
                "schema": {
                  "$ref": "#/components/schemas/DecisionStipulation"
                }
              },
              "text/json": {
                "schema": {
                  "$ref": "#/components/schemas/DecisionStipulation"
                }
              },
              "application/xml": {
                "schema": {
                  "$ref": "#/components/schemas/DecisionStipulation"
                }
              },
              "text/xml": {
                "schema": {
                  "$ref": "#/components/schemas/DecisionStipulation"
                }
              }
            }
          },
          "404": {
            "description": "Not Found"
          }
        }
      }
    },
    "/v1/applications/{applicationId}/funding/current": {
      "get": {
        "tags": [
          "Application"
        ],
        "description": "<b>SSO Permission Required</b>: Funding - View",
        "parameters": [
          {
            "name": "CUDC.Lender",
            "in": "header",
            "schema": {
              "type": "string"
            }
          },
          {
            "name": "applicationId",
            "in": "path",
            "required": true,
            "schema": {
              "type": "integer",
              "format": "int32"
            }
          }
        ],
        "responses": {
          "200": {
            "description": "Success",
            "content": {
              "application/json": {
                "schema": {
                  "$ref": "#/components/schemas/Funding"
                }
              },
              "text/json": {
                "schema": {
                  "$ref": "#/components/schemas/Funding"
                }
              },
              "application/xml": {
                "schema": {
                  "$ref": "#/components/schemas/Funding"
                }
              },
              "text/xml": {
                "schema": {
                  "$ref": "#/components/schemas/Funding"
                }
              }
            }
          },
          "404": {
            "description": "Not Found"
          }
        }
      }
    }
  },
  "components": {
    "schemas": {
      "Address": {
        "type": "object",
        "properties": {
          "id": {
            "type": "integer",
            "format": "int32"
          },
          "type": {
            "type": "string",
            "nullable": true
          },
          "addressLine1": {
            "type": "string",
            "nullable": true
          },
          "addressLine2": {
            "type": "string",
            "nullable": true
          },
          "city": {
            "type": "string",
            "nullable": true
          },
          "state": {
            "type": "string",
            "nullable": true
          },
          "internationalStateProvince": {
            "type": "string",
            "nullable": true
          },
          "zip": {
            "type": "string",
            "nullable": true
          },
          "country": {
            "type": "string",
            "nullable": true
          }
        },
        "additionalProperties": false
      },
      "Applicant": {
        "type": "object",
        "properties": {
          "id": {
            "type": "integer",
            "format": "int32"
          },
          "type": {
            "type": "string",
            "nullable": true
          },
          "firstName": {
            "type": "string",
            "nullable": true
          },
          "middleName": {
            "type": "string",
            "nullable": true
          },
          "lastName": {
            "type": "string",
            "nullable": true
          },
          "suffix": {
            "type": "string",
            "nullable": true
          },
          "tin": {
            "type": "string",
            "nullable": true
          },
          "emailAddresses": {
            "type": "array",
            "items": {
              "$ref": "#/components/schemas/Email"
            },
            "nullable": true
          },
          "addresses": {
            "type": "array",
            "items": {
              "$ref": "#/components/schemas/Address"
            },
            "nullable": true
          },
          "phoneNumbers": {
            "type": "array",
            "items": {
              "$ref": "#/components/schemas/PhoneNumber"
            },
            "nullable": true
          }
        },
        "additionalProperties": false
      },
      "ApplicantBasic": {
        "type": "object",
        "properties": {
          "id": {
            "type": "integer",
            "format": "int32"
          },
          "type": {
            "type": "string",
            "nullable": true
          },
          "firstName": {
            "type": "string",
            "nullable": true
          },
          "middleName": {
            "type": "string",
            "nullable": true
          },
          "lastName": {
            "type": "string",
            "nullable": true
          },
          "suffix": {
            "type": "string",
            "nullable": true
          }
        },
        "additionalProperties": false
      },
      "ApplicantsResponse": {
        "type": "object",
        "properties": {
          "applicationId": {
            "type": "integer",
            "format": "int32"
          },
          "applicants": {
            "type": "array",
            "items": {
              "$ref": "#/components/schemas/Applicant"
            },
            "nullable": true
          }
        },
        "additionalProperties": false
      },
      "ApplicationBasic": {
        "type": "object",
        "properties": {
          "id": {
            "type": "integer",
            "format": "int32"
          },
          "decisionId": {
            "type": "integer",
            "format": "int32",
            "nullable": true
          },
          "fundingId": {
            "type": "integer",
            "format": "int32",
            "nullable": true
          },
          "status": {
            "type": "string",
            "nullable": true
          },
          "stage": {
            "type": "string",
            "nullable": true
          },
          "queueName": {
            "type": "string",
            "nullable": true
          },
          "productType": {
            "type": "string",
            "nullable": true
          },
          "transactionType": {
            "type": "string",
            "nullable": true
          },
          "loanPurpose": {
            "type": "string",
            "nullable": true
          },
          "submittedBy": {
            "type": "string",
            "nullable": true
          },
          "applicants": {
            "type": "array",
            "items": {
              "$ref": "#/components/schemas/ApplicantBasic"
            },
            "nullable": true
          },
          "collaterals": {
            "type": "array",
            "items": {
              "$ref": "#/components/schemas/CollateralVehicle"
            },
            "nullable": true
          }
        },
        "additionalProperties": false
      },
      "CollateralVehicle": {
        "type": "object",
        "properties": {
          "id": {
            "type": "integer",
            "format": "int32"
          },
          "type": {
            "type": "string",
            "nullable": true
          },
          "make": {
            "type": "string",
            "nullable": true
          },
          "model": {
            "type": "string",
            "nullable": true
          },
          "year": {
            "type": "string",
            "nullable": true
          },
          "purchasePrice": {
            "type": "number",
            "format": "double",
            "nullable": true
          },
          "valuationType": {
            "type": "string",
            "nullable": true
          },
          "valuationAmount": {
            "type": "number",
            "format": "double",
            "nullable": true
          }
        },
        "additionalProperties": false
      },
      "Decision": {
        "type": "object",
        "properties": {
          "id": {
            "type": "integer",
            "format": "int32"
          },
          "applicationId": {
            "type": "integer",
            "format": "int32"
          },
          "decisionDate": {
            "type": "string",
            "format": "date-time"
          },
          "amount": {
            "type": "number",
            "format": "double",
            "nullable": true
          },
          "rate": {
            "type": "number",
            "format": "double",
            "nullable": true
          },
          "termMonths": {
            "type": "integer",
            "format": "int32",
            "nullable": true
          },
          "tier": {
            "type": "string",
            "nullable": true
          },
          "policy": {
            "type": "string",
            "nullable": true
          },
          "queueName": {
            "type": "string",
            "nullable": true
          },
          "status": {
            "type": "string",
            "nullable": true
          },
          "decisionedBy": {
            "type": "string",
            "nullable": true
          },
          "reasons": {
            "type": "array",
            "items": {
              "$ref": "#/components/schemas/DecisionReason"
            },
            "nullable": true
          },
          "stipulations": {
            "type": "array",
            "items": {
              "$ref": "#/components/schemas/DecisionStipulation"
            },
            "nullable": true
          }
        },
        "additionalProperties": false
      },
      "DecisionReason": {
        "type": "object",
        "properties": {
          "id": {
            "type": "integer",
            "format": "int32",
            "nullable": true
          },
          "decisionId": {
            "type": "integer",
            "format": "int32"
          },
          "description": {
            "type": "string",
            "nullable": true
          },
          "code": {
            "type": "string",
            "nullable": true
          },
          "isCounterJustification": {
            "type": "boolean"
          }
        },
        "additionalProperties": false
      },
      "DecisionStipulation": {
        "type": "object",
        "properties": {
          "id": {
            "type": "integer",
            "format": "int32"
          },
          "applicationId": {
            "type": "integer",
            "format": "int32"
          },
          "decisionId": {
            "type": "integer",
            "format": "int32"
          },
          "description": {
            "type": "string",
            "nullable": true
          },
          "isCompleted": {
            "type": "boolean"
          },
          "completedOn": {
            "type": "string",
            "format": "date-time",
            "nullable": true
          },
          "isWaived": {
            "type": "boolean"
          }
        },
        "additionalProperties": false
      },
      "Email": {
        "type": "object",
        "properties": {
          "type": {
            "type": "string",
            "nullable": true
          },
          "emailAddress": {
            "type": "string",
            "nullable": true
          }
        },
        "additionalProperties": false
      },
      "Funding": {
        "type": "object",
        "properties": {
          "id": {
            "type": "integer",
            "format": "int32"
          },
          "applicationId": {
            "type": "integer",
            "format": "int32"
          },
          "sellerCode": {
            "type": "string",
            "nullable": true
          },
          "loanAmount": {
            "type": "number",
            "format": "double",
            "nullable": true
          },
          "netLoanAmount": {
            "type": "number",
            "format": "double",
            "nullable": true
          },
          "sellerAdminFee": {
            "type": "number",
            "format": "double",
            "nullable": true
          },
          "netSellerAdminFee": {
            "type": "number",
            "format": "double",
            "nullable": true
          },
          "totalProceeds": {
            "type": "number",
            "format": "double",
            "nullable": true
          },
          "vin": {
            "type": "string",
            "nullable": true
          },
          "method": {
            "type": "string",
            "nullable": true
          },
          "tier": {
            "type": "string",
            "nullable": true
          },
          "rate": {
            "type": "number",
            "format": "double",
            "nullable": true
          },
          "termMonths": {
            "type": "integer",
            "format": "int32",
            "nullable": true
          },
          "fundedDate": {
            "type": "string",
            "format": "date-time"
          },
          "fundedBy": {
            "type": "string",
            "nullable": true
          }
        },
        "additionalProperties": false
      },
      "PhoneNumber": {
        "type": "object",
        "properties": {
          "type": {
            "type": "string",
            "nullable": true
          },
          "number": {
            "type": "string",
            "nullable": true
          },
          "extension": {
            "type": "string",
            "nullable": true
          }
        },
        "additionalProperties": false
      }
    },
    "securitySchemes": {
      "Basic": {
        "type": "http",
        "description": "",
        "scheme": "Basic"
      }
    }
  },
  "security": [
    {
      "Basic": []
    }
  ]
}

-------------------------------------------

MuthuKumaranMurugaachari-MSFT 22,441 Reputation points Moderator

2022-10-06T15:39:08.04+00:00

@Ali Shemirani Thank you for reaching out to Microsoft Q&A. Based on your statement, you have created ARM templates using Creator tool and faced issues during the deployment.

I used creator.yml and openapi.json that you shared above and generated ARM templates using latest version of azure-api-management-devops-resource-kit. However, I was able to successfully deploy the templates without any issues. Can you please share more details such full error message, correlation ID, timestamp etc. about the error/issues you were facing? That would help in better understand the issue.

I would also like to let you know that both Creator and Extractor tools are part of open-source repo azure-api-management-devops-resource-kit. If you find a bug or issue with tools, the best way to report is in GitHub so that experts can review and mitigate the issue.

1 answer

Your answer

MuthuKumaranMurugaachari-MSFT 22,441 Reputation points Moderator

2022-10-06T15:39:08.04+00:00

@Ali Shemirani Thank you for reaching out to Microsoft Q&A. Based on your statement, you have created ARM templates using Creator tool and faced issues during the deployment.

I used creator.yml and openapi.json that you shared above and generated ARM templates using latest version of azure-api-management-devops-resource-kit. However, I was able to successfully deploy the templates without any issues. Can you please share more details such full error message, correlation ID, timestamp etc. about the error/issues you were facing? That would help in better understand the issue.

I would also like to let you know that both Creator and Extractor tools are part of open-source repo azure-api-management-devops-resource-kit. If you find a bug or issue with tools, the best way to report is in GitHub so that experts can review and mitigate the issue.

Answer 1

Ali Shemirani 1

Here are a few screenshot from the error I get. so after ARM template generation and running "apim-common-dev-01-parameters.json" through the pipeline I get error in screenshot "Error1.png" and it complains a required "type" property is missing in the generated file so I have to edit the file and replace it with "type": "string" so it doesn't complain

The error message I receive in Error2.png is when I fixed above and run "loan-details1.api.template.json" file through the pipeline and I get the error that the parameter is missing, so I had to add another override and have the same value passed in the pipeline.

With these changes I could get the pipeline to work but that is not expected.

Can you please tell how you ran the pipeline that you do not encounter these issues?

MuthuKumaranMurugaachari-MSFT 22,441 Reputation points Moderator

2022-10-07T13:35:52.383+00:00

@Ali Shemirani I generated ARM templates and tested with azure CLI. Let me validate this with pipeline and get back to you.
MuthuKumaranMurugaachari-MSFT 22,441 Reputation points Moderator

2022-10-10T18:34:26.44+00:00

@Ali Shemirani Thank you for your patience. I verified the templates generated and parameter file which follows ARM parameter file syntax correctly. Refer Parameter file (also https://learn.microsoft.com/en-us/azure/azure-resource-manager/templates/template-tutorial-use-parameter-file?tabs=azure-powershell#add-parameter-files).

I think Creator tool created parameter files correctly, but the issue appeared to be in azure devops pipeline/configuration. Can you validate your templates and try deploying via PowerShell or CLI? This way we can focus on the pipeline deployment.

Also, I would like to let you know that if you want master template which links other templates for azure devops you can set property linked as true. Refer docs for more info.

Share via

Errors from APIM creator tool

1 answer

Your answer
