moving controls inside tablelayoutpanel

ankit goel 766

I want to move and place controls inside tablelayoutpanel but it seems that i cannot move controls as they are stuck at some place inside tableoutpanel . Any suggestions .

2 answers

Your answer

Answer 1

Viorel 122.6K

For example, put a Panel control to the table's cell, then place your control (or more controls) to this panel. Maybe also set the Anchor property of the controls.

In simple cases, you can set the Margin property of the control instead of using panels.

Answer 2

Castorix31 90,686

You can use SetRow / SetColumn to move them

For example, to move a Button at 0,0 :

ankit goel 766 Reputation points

2022-11-06T12:50:17.263+00:00

This is the problem only that I am having . The control in you case button seems to get stuck in the top left corner of the cell whereas I want to centre it .
Castorix31 90,686 Reputation points

2022-11-06T14:19:49.34+00:00

You can see : How to: Align and Stretch a Control in a TableLayoutPanel Control
Anonymous

2022-11-10T06:21:59.43+00:00

Hi @ankit goel , Is there any update in this issue? If the answer is the right solution, please click "Accept Answer" and kindly upvote it. If you have extra questions about this answer, please click "Comment".

ankit goel 766

@Anonymous , THE PROBLEM HAS NOT BEEN SOLVED , I GO THROUGH THE LINK AT https://learn.microsoft.com/en-us/dotnet/desktop/winforms/controls/how-to-align-and-stretch-a-control-in-a-tablelayoutpanel-control?view=netframeworkdesktop-4.8 , BUT IT DOES NOT SOLVE MY PROBLEM .

THIS IS MY CUSTOMDATAGRIDVIEW

   public uneditabledatagridview()
        {
            this.ColumnHeadersDefaultCellStyle.Font = new Font("Tahoma", 9.75F, FontStyle.Bold);
            this.CellBorderStyle = DataGridViewCellBorderStyle.None;
            this.AllowUserToAddRows = false;
            this.AllowUserToDeleteRows = false;
            this.AllowUserToResizeRows = false;
            this.AllowUserToDeleteRows = false;
            this.BorderStyle = BorderStyle.None;
            this.RowHeadersBorderStyle = DataGridViewHeaderBorderStyle.None;
            this.ColumnHeadersBorderStyle = DataGridViewHeaderBorderStyle.None;
            this.RowHeadersVisible = false;
            // Set column width to autofit to fit content
            this.AutoSizeColumnsMode = DataGridViewAutoSizeColumnsMode.AllCells;
            InitializeComponent();
        }

below is the designer code of the page that contains this customcontrol

    private void InitializeComponent()
        {
            System.Windows.Forms.DataGridViewCellStyle dataGridViewCellStyle1 = new System.Windows.Forms.DataGridViewCellStyle();
            System.Windows.Forms.DataGridViewCellStyle dataGridViewCellStyle2 = new System.Windows.Forms.DataGridViewCellStyle();

            this.uneditabledatagridview1 = new Vijaykumarproject.supercontrols.uneditabledatagridview();
            this.Column1 = new System.Windows.Forms.DataGridViewTextBoxColumn();
            this.Column2 = new System.Windows.Forms.DataGridViewTextBoxColumn();
            this.tableLayoutPanel1.SuspendLayout();
            ((System.ComponentModel.ISupportInitialize)(this.uneditabledatagridview2)).BeginInit();

            this.SuspendLayout();
            //
            // tableLayoutPanel1
            //
            this.tableLayoutPanel1.CellBorderStyle = System.Windows.Forms.TableLayoutPanelCellBorderStyle.Single;
            this.tableLayoutPanel1.ColumnCount = 2;
            this.tableLayoutPanel1.ColumnStyles.Add(new System.Windows.Forms.ColumnStyle(System.Windows.Forms.SizeType.Percent, 50F));
            this.tableLayoutPanel1.ColumnStyles.Add(new System.Windows.Forms.ColumnStyle(System.Windows.Forms.SizeType.Percent, 50F));
            this.tableLayoutPanel1.Controls.Add(this.uneditabledatagridview1, 0, 0);
            this.tableLayoutPanel1.Controls.Add(this.uneditabledatagridview2, 1, 0);
            this.tableLayoutPanel1.Dock = System.Windows.Forms.DockStyle.Fill;
            this.tableLayoutPanel1.Location = new System.Drawing.Point(0, 0);
            this.tableLayoutPanel1.Name = "tableLayoutPanel1";
            this.tableLayoutPanel1.RowCount = 1;
            this.tableLayoutPanel1.RowStyles.Add(new System.Windows.Forms.RowStyle(System.Windows.Forms.SizeType.Percent, 13.33333F));
            this.tableLayoutPanel1.Size = new System.Drawing.Size(1433, 523);
            this.tableLayoutPanel1.TabIndex = 0;
            //

            //
            // uneditabledatagridview1
            //
            this.uneditabledatagridview1.AllowUserToAddRows = false;
            this.uneditabledatagridview1.AllowUserToDeleteRows = false;
            this.uneditabledatagridview1.AllowUserToResizeRows = false;
            this.uneditabledatagridview1.AutoSizeColumnsMode = System.Windows.Forms.DataGridViewAutoSizeColumnsMode.AllCells;
            this.uneditabledatagridview1.BackgroundColor = System.Drawing.Color.FromArgb(((int)(((byte)(255)))), ((int)(((byte)(255)))), ((int)(((byte)(192)))));
            this.uneditabledatagridview1.BorderStyle = System.Windows.Forms.BorderStyle.None;
            this.uneditabledatagridview1.CellBorderStyle = System.Windows.Forms.DataGridViewCellBorderStyle.None;
            this.uneditabledatagridview1.ColumnHeadersBorderStyle = System.Windows.Forms.DataGridViewHeaderBorderStyle.None;
            dataGridViewCellStyle1.Alignment = System.Windows.Forms.DataGridViewContentAlignment.MiddleLeft;
            dataGridViewCellStyle1.BackColor = System.Drawing.SystemColors.Control;
            dataGridViewCellStyle1.Font = new System.Drawing.Font("Tahoma", 9.75F, System.Drawing.FontStyle.Bold);
            dataGridViewCellStyle1.ForeColor = System.Drawing.SystemColors.WindowText;
            dataGridViewCellStyle1.SelectionBackColor = System.Drawing.SystemColors.Highlight;
            dataGridViewCellStyle1.SelectionForeColor = System.Drawing.SystemColors.HighlightText;
            dataGridViewCellStyle1.WrapMode = System.Windows.Forms.DataGridViewTriState.True;
            this.uneditabledatagridview1.ColumnHeadersDefaultCellStyle = dataGridViewCellStyle1;
            this.uneditabledatagridview1.ColumnHeadersHeightSizeMode = System.Windows.Forms.DataGridViewColumnHeadersHeightSizeMode.AutoSize;
            this.uneditabledatagridview1.Columns.AddRange(new System.Windows.Forms.DataGridViewColumn[] {
            this.Column1,
            this.Column2});
            dataGridViewCellStyle2.Alignment = System.Windows.Forms.DataGridViewContentAlignment.MiddleLeft;
            dataGridViewCellStyle2.BackColor = System.Drawing.Color.FromArgb(((int)(((byte)(255)))), ((int)(((byte)(255)))), ((int)(((byte)(192)))));
            dataGridViewCellStyle2.Font = new System.Drawing.Font("Microsoft Sans Serif", 7.8F, System.Drawing.FontStyle.Regular, System.Drawing.GraphicsUnit.Point, ((byte)(0)));
            dataGridViewCellStyle2.ForeColor = System.Drawing.SystemColors.ControlText;
            dataGridViewCellStyle2.SelectionBackColor = System.Drawing.SystemColors.Highlight;
            dataGridViewCellStyle2.SelectionForeColor = System.Drawing.SystemColors.HighlightText;
            dataGridViewCellStyle2.WrapMode = System.Windows.Forms.DataGridViewTriState.False;
            this.uneditabledatagridview1.DefaultCellStyle = dataGridViewCellStyle2;
            this.uneditabledatagridview1.Dock = System.Windows.Forms.DockStyle.Fill;
            this.uneditabledatagridview1.Location = new System.Drawing.Point(4, 4);
            this.uneditabledatagridview1.Name = "uneditabledatagridview1";
            this.uneditabledatagridview1.ReadOnly = true;
            this.uneditabledatagridview1.RowHeadersBorderStyle = System.Windows.Forms.DataGridViewHeaderBorderStyle.None;
            this.uneditabledatagridview1.RowHeadersVisible = false;
            this.uneditabledatagridview1.RowHeadersWidth = 51;
            this.uneditabledatagridview1.RowTemplate.Height = 24;
            this.uneditabledatagridview1.Size = new System.Drawing.Size(709, 515);
            this.uneditabledatagridview1.TabIndex = 0;
            this.uneditabledatagridview1.CellContentClick += new System.Windows.Forms.DataGridViewCellEventHandler(this.uneditabledatagridview1_CellContentClick);
            //
            // Column1
            //
            this.Column1.HeaderText = "Liabities";
            this.Column1.MinimumWidth = 6;
            this.Column1.Name = "Column1";
            this.Column1.ReadOnly = true;
            this.Column1.Width = 111;
            //
            // Column2
            //
            this.Column2.HeaderText = "companynamewithcurrentdate";
            this.Column2.MinimumWidth = 6;
            this.Column2.Name = "Column2";
            this.Column2.ReadOnly = true;
            this.Column2.Width = 302;
            //
            // balancesheet
            //
            this.AutoScaleDimensions = new System.Drawing.SizeF(8F, 16F);
            this.AutoScaleMode = System.Windows.Forms.AutoScaleMode.Font;
            this.BackColor = System.Drawing.Color.FromArgb(((int)(((byte)(255)))), ((int)(((byte)(255)))), ((int)(((byte)(192)))));
            this.ClientSize = new System.Drawing.Size(1433, 523);
            this.Controls.Add(this.tableLayoutPanel1);
            this.Name = "balancesheet";
            this.Text = "balancesheet";
            this.Load += new System.EventHandler(this.balancesheet_Load);
            this.tableLayoutPanel1.ResumeLayout(false);
            ((System.ComponentModel.ISupportInitialize)(this.uneditabledatagridview2)).EndInit();
            ((System.ComponentModel.ISupportInitialize)(this.uneditabledatagridview1)).EndInit();
            this.ResumeLayout(false);

        }

        #endregion

        private System.Windows.Forms.TableLayoutPanel tableLayoutPanel1;
        private supercontrols.uneditabledatagridview uneditabledatagridview1;

        private System.Windows.Forms.DataGridViewTextBoxColumn Column1;
        private System.Windows.Forms.DataGridViewTextBoxColumn Column2;

    }
}

and the results is

User's image

you can see that it is attached to top left side . i tried setting anchor property but no results
