MBR2GPT fails validation

John Lenz 1,726 Reputation points
2022-11-19T18:36:16.317+00:00

Win10 Pro current build
2TB HDD - WD20EZRZ-002Z5HB0

I am trying to move to Windows 11 from Windows 10
When I perform MBR2GPT /Validate I get the following error: Disk Layout validation failed for disk

Sector size is 512 bytes

I completed a Chkdsk on both system reserved and system partitions and fixed all issues. Runs clean.

What is nature of issue and how do I fix


Windows 10
Windows 10
A Microsoft operating system that runs on personal computers and tablets.
11,172 questions
0 comments No comments
{count} votes

Accepted answer
  1. Docs 15,491 Reputation points
    2022-11-21T00:01:45.667+00:00

    First scannow:

    Windows Resource Protection found corrupt files and successfully repaired them.

    Second scannow:

    Windows Resource Protection did not find any integrity violations.

    Open administrative command prompt and type or copy and paste:

    reagentc /info
    reagentc /disable
    diskpart
    sel dis 0
    det dis
    lis par
    sel par 4
    det par
    del par override
    lis par
    exit
    reagentc /enable
    reagentc /info

    Type:
    ctrl + a
    ctrl + c

    Paste the above commands with results into this thread typing: ctrl + v

    Reboot the computer and run mbr2gpt /validate

    Post images of the command with results.

    If validated then continue with the conversion: mbr2gpt /convert /allowfullos

    If the conversion is successful then boot using UEFI.

    In case there are any problems post a new disk management and new log file results (tuneup, diskpar, mbr2gpt)

    .
    .
    .
    .
    .

    Please remember to vote and to mark the replies as answers if they help.

    On the bottom of each post there is:

    Propose as answer = answered the question

    On the left side of each post there is /\ with a number: click = a helpful post
    .
    .
    .
    .
    .


2 additional answers

Sort by: Most helpful
  1. Docs 15,491 Reputation points
    2022-11-19T21:24:36.72+00:00

    Please run these bat scripts and post share links into this thread using one drive, drop box, or google drive.

    Tuneup plus
    diskpar info
    mbr2gpt

    https://www.tenforums.com/attachments/bsod-crashes-debugging/360137d1645183388-batch-files-use-bsod-debugging-tuneup_plus_log.bat

    https://www.tenforums.com/attachments/bsod-crashes-debugging/360998d1646031500-post-problem-reports-here-batch-files-use-bsod-debugging-diskparinfo.bat

    https://www.tenforums.com/attachments/bsod-crashes-debugging/360509d1645510785-post-problem-reports-here-batch-files-use-bsod-debugging-info_on_mbr2gpt.bat

    .
    .
    .
    .
    .

    Please remember to vote and to mark the replies as answers if they help.

    On the bottom of each post there is:

    Propose as answer = answered the question

    On the left side of each post there is /\ with a number: click = a helpful post
    .
    .
    .
    .
    .


  2. Docs 15,491 Reputation points
    2022-11-20T02:09:38.807+00:00

    This is an older script:

    https://www.tenforums.com/attachments/bsod-crashes-debugging/355861d1640707960-batch-files-use-bsod-debugging-diskparinfo.bat

    https://www.tenforums.com/bsod-crashes-debugging/162488-batch-files-use-bsod-debugging.html#Part3

    .
    .
    .
    .
    .
