Record Navigation in AccessDB on UserForm

Question

Please, am creating a bible. So far so good, every other parts of the UI has been coded successfully but can't seem to code the "Next" and "Previous" navigation buttons. As designed, the user enters his or her desired bible reference through certain comboboxes (cmbBook, cmbChapter, cmbVerse), to generate the respective bible readings. The result is shown in a Label. From this point, I would want that when the "Next" button is clicked, the next bible verse is shown, and when the "Previous" button is clicked, the previous bible verse is shown. My access database has two columns namely the BibleReference and BibleReadings. See code, thank you.

Imports System.Data.OleDb 'for db

Public Class Form1

 Private connectionkjvbible As OleDbConnection = New OleDbConnection()

 Private Sub Form1_Load(sender As Object, e As EventArgs) Handles MyBase.Load
        Try
            connectionkjvbible.Open()
            checkConnection.Text = "Server Connected!"
            connectionkjvbible.Close()
        Catch ex As Exception
            Dim nex As String
            nex = MessageBox.Show("Sorry, databse server not connected!", "OfflineBible1 DB, Error", MessageBoxButtons.OK)
            If nex = DialogResult.OK Then
                Application.Exit()
            End If
        End Try
 End Sub

 Public Sub New()
        connectionkjvbible.ConnectionString = "Provider=Microsoft.ACE.OLEDB.12.0; Data Source=connectionkjvbible.accdb; Persist Security Info=False;"
 End Sub

 Search data and show in label - new testament

 Private Sub BtnSubmitToDatabase_Click(sender As Object, e As EventArgs) Handles BtnSubmitToDatabase.Click

        connectionkjvbible.Open()

        Dim command As OleDbCommand = New OleDbCommand()
        command.Connection = connectionkjvbible
        command.CommandText = "Select * from NewTestament where BibleReference='" & txt_WordID2.Text & "'"

        Dim reader As OleDbDataReader = command.ExecuteReader()
        Dim count As Integer = 0

        While reader.Read()
            count = count + 1
        End While

        connectionkjvbible.Close()

        If count = 1 Then
            connectionkjvbible.Open()
            command.Connection = connectionkjvbible
            command.CommandText = "Select BibleReadings from NewTestament where BibleReference='" & txt_WordID2.Text & "'"
            Dim dr As OleDbDataReader = command.ExecuteReader()

            While dr.Read()
                LblBibleVerses2.Text = dr("BibleReadings").ToString()
            End While

            dr.Close()
            connectionkjvbible.Close()
        Else
            MessageBox.Show("Sorry, this entry does Not exist in database. Please ensure your entry is correctly spelt.")
        End If

 End Sub

End Class

Answer 1

Hi

You may benefit from using a BindingNavigator, which is specifically designed for such tasks.

Here is a LINK that may help, and, if you Google for 'VB.NET BindingNavigator' you will get LOTS of info.

Answer 2

What i did was simple. The bible verses have sequential IDs in the database. When the user searches a bible reference, the corresponding ID of the reference in db is generated and shown in a label. To get the next verse, i simply increment the ID by 1, then retrieve the associated record. To get the previous verse, I decrement the ID by 1, and retrieve the associated record

 Dim NewT_Counter As Integer = 0
    Dim NewT_ID As Integer
    Dim NewT_IncrementedID As Integer

    Dim OldT_Counter As Integer = 0
    Dim OldT_ID As Integer
    Dim OldT_IncrementedID As Integer

    Dim BothT_Counter As Integer = 0
    Dim BothT_ID As Integer
    Dim BothT_IncrementedID As Integer

 'A. forward track verse (forward button)

    Private Sub BtnOfflineBibleForwardTrack_Click(sender As Object, e As EventArgs) Handles BtnOfflineBibleForwardTrack.Click

        '1. new testamneNt

 If RadiobuttonNewTestament.checked = true and RadiobuttonOldTestament.checked = false then

            If ComboBoxSearchBible.Text = "Revelation 22:21" And LblBibleIDNewtestament.Text = "7957" Then  'last reference in the bible
                'do nothing
            Else

                'a.LblBibleIDNewtestament.Text Convert from String to Integer, then increment obtained number by 1

                NewT_Counter += 1
                NewT_ID = LblBibleIDNewtestament.Text
                NewT_IncrementedID = NewT_ID + NewT_Counter
                LblBibleIDNewtestamentIncrement.Text = NewT_IncrementedID

                'b. submit value of LblBibleIDNewtestamentIncrement.Text, being ID into db to search and produce its corresponding bible verse

                '--> firstly, find out if ID as present in LblBibleIDNewtestamentIncrement.text, is in database

                connectionofflinebible1.Open()
                Dim command As OleDbCommand = New OleDbCommand()
                command.Connection = connectionofflinebible1
                command.CommandText = "Select * from NewTestament where ID=" & LblBibleIDNewtestamentIncrement.Text & ""

                '--> Notify and Prevent duplicate entries in database

                Dim reader As OleDbDataReader = command.ExecuteReader()
                Dim count As Integer = 0

                While reader.Read()
                    count = count + 1
                End While

                connectionofflinebible1.Close()

                '--> if the value of LblBibleIDNewtestamentIncrement.text in is in database, then fetch its corresponding value i.e. BibleReadings, and add to label (LblBibleVerses2)

                If count = 1 Then

                    connectionofflinebible1.Open()

                    command.Connection = connectionofflinebible1
                    command.CommandText = "Select BibleReadings from NewTestament where ID =" & LblBibleIDNewtestamentIncrement.Text & ""
                    Dim dr As OleDbDataReader = command.ExecuteReader()

                    While dr.Read()
                        LblBibleVerses2.Text = dr("BibleReadings").ToString()
                    End While

                    dr.Close()

                    connectionofflinebible1.Close()

                Else
                    MessageBox.Show("Sorry, this entry does not exist in database. Please ensure your entry is correctly spelt.")
                End If

                '--> if the value of LblBibleIDNewtestamentIncrement.text in is in database, then fetch its corresponding value i.e. BibleReference, and add to ComboBoxSearchBible

                If count = 1 Then

                    connectionofflinebible1.Open()

                    command.Connection = connectionofflinebible1
                    command.CommandText = "Select BibleReference from NewTestament where ID =" & LblBibleIDNewtestamentIncrement.Text & ""
                    Dim dr2 As OleDbDataReader = command.ExecuteReader()

                    While dr2.Read()
                        ComboBoxSearchBible.Text = dr2("BibleReference").ToString()
                    End While

                    dr2.Close()

                    connectionofflinebible1.Close()

                Else
                    MessageBox.Show("Sorry, this entry does not exist in database. Please ensure your entry is correctly spelt.")
                End If

            End If
 End If

        '2. old testament

 If RadiobuttonNewTestament.checked = false and RadiobuttonOldTestament.checked = true then

            If ComboBoxSearchBible.Text = "Malachi 4:6" And LblBibleIDOldtestament.Text = "23146" Then  'last reference in the bible
                'do nothing
            Else

                'a. LblBibleIDNewtestament.Text Convert from String To Integer, then increment obtained number by 1

                OldT_Counter += 1
                OldT_ID = LblBibleIDOldtestament.Text
                OldT_IncrementedID = OldT_ID + OldT_Counter
                LblBibleIDOldtestamentIncrement.Text = OldT_IncrementedID

                'b. submit value of LblBibleIDNewtestamentIncrement.Text, being ID into db to search and produce its corresponding bible verse

                '--> firstly, find out if ID as present in LblBibleIDNewtestamentIncrement.text, is in database

                connectionofflinebible1.Open()
                Dim command As OleDbCommand = New OleDbCommand()
                command.Connection = connectionofflinebible1
                command.CommandText = "Select * from OldTestament where ID=" & LblBibleIDOldtestamentIncrement.Text & ""

                '--> Notify and Prevent duplicate enteries in database

                Dim reader As OleDbDataReader = command.ExecuteReader()
                Dim count As Integer = 0

                While reader.Read()
                    count = count + 1
                End While

                connectionofflinebible1.Close()

                '--> if the value of LblBibleIDNewtestamentIncrement.text in is in database, then fetch its corresponding value i.e. BibleReadings, and add to label (LblBibleVerses2)

                If count = 1 Then

                    connectionofflinebible1.Open()

                    command.Connection = connectionofflinebible1
                    command.CommandText = "Select BibleReadings from OldTestament where ID =" & LblBibleIDOldtestamentIncrement.Text & ""
                    Dim dr As OleDbDataReader = command.ExecuteReader()

                    While dr.Read()
                        LblBibleVerses2.Text = dr("BibleReadings").ToString()
                    End While

                    dr.Close()

                    connectionofflinebible1.Close()

                Else
                    MessageBox.Show("Sorry, this entry does not exist in database. Please ensure your entry is correctly spelt.")
                End If

                '--> if the value of LblBibleIDNewtestamentIncrement.text in is in database, then fetch its corresponding value i.e. BibleReference, and add to ComboBoxSearchBible

                If count = 1 Then

                    connectionofflinebible1.Open()

                    command.Connection = connectionofflinebible1
                    command.CommandText = "Select BibleReference from OldTestament where ID =" & LblBibleIDOldtestamentIncrement.Text & ""
                    Dim dr2 As OleDbDataReader = command.ExecuteReader()

                    While dr2.Read()
                        ComboBoxSearchBible.Text = dr2("BibleReference").ToString()
                    End While

                    dr2.Close()

                    connectionofflinebible1.Close()

                Else
                    MessageBox.Show("Sorry, this entry does not exist in database. Please ensure your entry is correctly spelt.")
                End If

            End If
 End If

    End Sub

'B. backward track verse (previous button)

Private Sub BtnOfflineBibleBackwardTrack_Click(sender As Object, e As EventArgs) Handles BtnOfflineBibleBackwardTrack.Click

    '1. new testament

 If RadiobuttonNewTestament.checked = true and RadiobuttonOldTestament.checked = false then

        If ComboBoxSearchBible.Text = "Matthew 1:1" And LblBibleIDNewtestament.Text = "1" Then  'first reference in the bible
            'do nothing
        Else

            'a.LblBibleIDNewtestament.Text Convert from String To Integer, then increment obtained number by 1

            NewT_Counter -= 1
            NewT_ID = LblBibleIDNewtestament.Text
            NewT_IncrementedID = NewT_ID + NewT_Counter
            LblBibleIDNewtestamentIncrement.Text = NewT_IncrementedID 'decrement by 1

            'b. submit value of LblBibleIDNewtestamentIncrement.Text, being ID into db to search and produce its corresponding bible verse

            '--> firstly, find out if ID as present in LblBibleIDNewtestamentIncrement.text, is in database

            connectionofflinebible1.Open()
            Dim command As OleDbCommand = New OleDbCommand()
            command.Connection = connectionofflinebible1
            command.CommandText = "Select * from NewTestament where ID=" & LblBibleIDNewtestamentIncrement.Text & ""

            '--> Notify and Prevent duplicate enteries in database

            Dim reader As OleDbDataReader = command.ExecuteReader()
            Dim count As Integer = 0

            While reader.Read()
                count = count + 1
            End While

            connectionofflinebible1.Close()

            '--> if the value of LblBibleIDNewtestamentIncrement.text in is in database, then fetch its corresponding value i.e. BibleReadings, and add to label (LblBibleVerses2)

            If count = 1 Then

                connectionofflinebible1.Open()

                command.Connection = connectionofflinebible1
                command.CommandText = "Select BibleReadings from NewTestament where ID =" & LblBibleIDNewtestamentIncrement.Text & ""
                Dim dr As OleDbDataReader = command.ExecuteReader()

                While dr.Read()
                    LblBibleVerses2.Text = dr("BibleReadings").ToString()
                End While

                dr.Close()

                connectionofflinebible1.Close()

            Else
                MessageBox.Show("Sorry, this entry does not exist in database. Please ensure your entry is correctly spelt.")
            End If

            '--> if the value of LblBibleIDNewtestamentIncrement.text in is in database, then fetch its corresponding value i.e. BibleReference, and add to ComboBoxSearchBible

            If count = 1 Then

                connectionofflinebible1.Open()

                command.Connection = connectionofflinebible1
                command.CommandText = "Select BibleReference from NewTestament where ID =" & LblBibleIDNewtestamentIncrement.Text & ""
                Dim dr2 As OleDbDataReader = command.ExecuteReader()

                While dr2.Read()
                    ComboBoxSearchBible.Text = dr2("BibleReference").ToString()
                End While

                dr2.Close()

                connectionofflinebible1.Close()

            Else
                MessageBox.Show("Sorry, this entry does not exist in database. Please ensure your entry is correctly spelt.")
            End If

        End If
 End If

    '2. old testament

 If RadiobuttonNewTestament.checked = False and RadiobuttonOldTestament.checked = True then

        If ComboBoxSearchBible.Text = "Genesis 1:1" And LblBibleIDOldtestament.Text = "1" Then  'last reference in the bible
            'do nothing
        Else

            'a. LblBibleIDNewtestament.Text Convert from String To Integer, then increment obtained number by 1

            OldT_Counter -= 1
            OldT_ID = LblBibleIDOldtestament.Text
            OldT_IncrementedID = OldT_ID + OldT_Counter
            LblBibleIDOldtestamentIncrement.Text = OldT_IncrementedID

            'b. submit value of LblBibleIDNewtestamentIncrement.Text, being ID into db to search and produce its corresponding bible verse

            '--> firstly, find out if ID as present in LblBibleIDNewtestamentIncrement.text, is in database

            connectionofflinebible1.Open()
            Dim command As OleDbCommand = New OleDbCommand()
            command.Connection = connectionofflinebible1
            command.CommandText = "Select * from OldTestament where ID=" & LblBibleIDOldtestamentIncrement.Text & ""

            '--> Notify and Prevent duplicate entries in database

            Dim reader As OleDbDataReader = command.ExecuteReader()
            Dim count As Integer = 0

            While reader.Read()
                count = count + 1
            End While

            connectionofflinebible1.Close()

            '--> if the value of LblBibleIDNewtestamentIncrement.text in is in database, then fetch its corresponding value i.e. BibleReadings, and add to label (LblBibleVerses2)

            If count = 1 Then

                connectionofflinebible1.Open()

                command.Connection = connectionofflinebible1
                command.CommandText = "Select BibleReadings from OldTestament where ID =" & LblBibleIDOldtestamentIncrement.Text & ""
                Dim dr As OleDbDataReader = command.ExecuteReader()

                While dr.Read()
                    LblBibleVerses2.Text = dr("BibleReadings").ToString()
                End While

                dr.Close()

                connectionofflinebible1.Close()

            Else
                MessageBox.Show("Sorry, this entry does not exist in database. Please ensure your entry is correctly spelt.")
            End If

            '--> if the value of LblBibleIDNewtestamentIncrement.text in is in database, then fetch its corresponding value i.e. BibleReference, and add to ComboBoxSearchBible

            If count = 1 Then

                connectionofflinebible1.Open()

                command.Connection = connectionofflinebible1
                command.CommandText = "Select BibleReference from OldTestament where ID =" & LblBibleIDOldtestamentIncrement.Text & ""
                Dim dr2 As OleDbDataReader = command.ExecuteReader()

                While dr2.Read()
                    ComboBoxSearchBible.Text = dr2("BibleReference").ToString()
                End While

                dr2.Close()

                connectionofflinebible1.Close()

            Else
                MessageBox.Show("Sorry, this entry does not exist in database. Please ensure your entry is correctly spelt.")
            End If

        End If
 End if

End Sub

To return the counter to zero, add the following code in the button event that calls the container control that holds bible reference controls.

NewT_Counter = 0
    OldT_Counter = 0
    BothT_Counter = 0
