Hi, did you follow?
Be sure to refresh the AADConnect schema:
Custom Attribute in ON-PREM AD to sync with Azure AD Connect
Ramachandran Krishnamoorthy
26
Reputation points
Hi Team,
I have created a custom attribute in AD-ON PREM Server. I have already installed Azure AD Connect on the ON-PREM server. I think we need to choose customize synchronization options and need to checkbox directory extension attribute sync to add custom attribute added in AD to get sync with Azure. Is this the right steps? Whether this will impact any other attribute syncing with Azure from ON-PREM.
Please note that the attribute name that I have added in the server not appearing in the available attributes list to select.
Thanks,
Ram
Microsoft Security Microsoft Entra Microsoft Entra ID
{count} votes
-
Ramachandran Krishnamoorthy 26 Reputation points
2023-03-28T10:47:35.72+00:00 Attribute Editor in ON-PREM Shows the attribute name added to the schema. But not showing in Azure AD Connect.
-
Ramachandran Krishnamoorthy 26 Reputation points
2023-03-28T11:17:26.2033333+00:00 Attribute Editor in ON-PREM Shows the attribute name added to the schema. But not showing in Azure AD Connect.
-
Ken Longworth 0 Reputation points2024-02-02T20:02:12.3566667+00:00 Thank you! That resolved the issue.
Sign in to comment
Accepted answer
-
Andy David - MVP 157.4K Reputation points MVP Volunteer Moderator2023-03-28T11:20:53.5966667+00:00 -
Ramachandran Krishnamoorthy 26 Reputation points
2023-03-28T11:39:22.77+00:00 @Andy David - MVP , I followed the below documentation to add custom attribute in AD-ON PREM.
Then restarted Active Directory Domain Services to get reflected in all DC's.
Now, I am not seeing that attribute in the Connectors Page in Azure AD Connect to add the custom attribute or the Azure AD Connect not showing the attribute added in ON-PREM to select from Available options.
Adding this custom attribute to sync will impact other attributes?
Thanks,
Ram
-
Andy David - MVP 157.4K Reputation points MVP Volunteer Moderator
2023-03-28T11:41:56.0366667+00:00 Did you refresh the AAdConnect schema? https://learn.microsoft.com/en-us/azure/active-directory/hybrid/how-to-connect-installation-wizard#refresh-directory-schema
After that, you should heopfuly see it as available to map in AADConnect.
-
Ramachandran Krishnamoorthy 26 Reputation points
2023-03-28T11:45:38.19+00:00 - @Andy David - MVP FYI.
Azure AD Connect not showing the attribute name.
This is ON-PREM AD Attribute Editor Page for an user. This confirmed it is available in AD Schema.
Refresh directory schema - I will try this option via Azure AD Connect. Whether this will impact any other directory (or) schema level issue?
-
Andy David - MVP 157.4K Reputation points MVP Volunteer Moderator
2023-03-28T11:50:22.7166667+00:00 It wont affect anything, no.
-
Ramachandran Krishnamoorthy 26 Reputation points
2023-03-28T12:05:25.48+00:00 AAdConnect schema - Completed.
AAD Connect shows the custom attribute that I have added.
Adding this custom attribute will not impact any other attributes synchronization. Correct?
-
Andy David - MVP 157.4K Reputation points MVP Volunteer Moderator
2023-03-28T12:08:06.2633333+00:00 Correct.
-
Andy David - MVP 157.4K Reputation points MVP Volunteer Moderator
2023-03-28T12:10:49.78+00:00 If you could, please accept an answer so this can closed and others can benefit from it. Thank you!
-
Ramachandran Krishnamoorthy 26 Reputation points
2023-03-28T12:19:04.9366667+00:00 Sure, I will do it. I wanted to check why I cannot see the attribute name in the Users > Properties in Azure AD?
-
Andy David - MVP 157.4K Reputation points MVP Volunteer Moderator
2023-03-28T12:24:34.5233333+00:00 You wont see it there. Once synced to Azure, the new attribute is available to apps that support it or viewable in Graph:
-
Ramachandran Krishnamoorthy 26 Reputation points
2023-03-28T12:48:49.4433333+00:00 @Andy David - MVP Thanks. I used Microsoft Graph Explorer to query user information and I see my custom attribute. One last question. If I need to add any other custom attribute to sync with AD, I need to just refresh AAD Schema via AAD Application and add the custom attribute via available attributes. Correct?
-
Andy David - MVP 157.4K Reputation points MVP Volunteer Moderator
2023-03-28T12:53:40.56+00:00 yes, Add the attribute in AD, then refresh the AADConnect schema so it picks up that change in AADConnect, then you can add it in the AADConnect application. You need to do that each time you add additional AD on-prem attributes.
Sign in to comment -
