Convert JSON output into CSV table in logic apps

Question

Hello I'm trying to execute below workflow but not able to achieve it

1. I'm getting data from HTTP action in the form of JSON
2. I need to achieve it to CSV form.

The Data Sample is attached below

{
  "data": {
    "Event1": {
      "Action": "Log in",
      "Data": "Master Vault",
      "IP_Address": "1.1.1.1",
      "Time": "2023-04-18 03:51:32",
      "Username": "Sam"
    },
    "Event2": {
      "Action": "Log in",
      "Data": "Master Vault",
      "IP_Address": "2.2.2.2",
      "Time": "2023-04-18 03:35:06",
      "Username": "John"
    },
    "Event3": {
      "Action": "Log in",
      "Data": "dext",
      "IP_Address": "3.3.3.3",
      "Time": "2023-04-18 03:34:46",
      "Username": "Rizwan"
    },
    "Event4": {
      "Action": "Log in",
      "Data": "google.com",
      "IP_Address": "4.4.4.4",
      "Time": "2023-04-18 03:34:08",
      "Username": "Prachi"
    }
  }
}

I tried to implement using variable but no progress, please let me know any working solution

Answer 1

Hi Narenda,

You can use the Compose function to change the inputs from your Parse JSON and change it into CSV format:

(See Beefcake's response)

https://stackoverflow.com/questions/48923628/logic-app-create-csv-table-from-json-output

Create_CSV_table": {
            "inputs": {
                "format": "CSV",
                "from": "@json(outputs('Parse JSON 2'))"
            },

You should then see your output as a CSV response. Let me know what you get for an output if you are having issues.

---

If this is helpful please accept answer.
