why the WPF application consumes much more (nearly 40x) memory than winfom?

William Liu 556 Reputation points
2023-05-16T08:38:30.2066667+00:00

I found the default empty template with dotnet for wpf is consuming much more memory than winform application.

test steps:

  • Create test folder, projects and run them from powershell.
mkdir TestApp
cd .\TestApp\

dotnet new wpf -o testwpf
dotnet new winforms -o testwinform

dotnet run --project .\testwpf\
dotnet run --project .\testwinform\
  • Open task manager and view the memory usage for wpf and winform.

You will find winform use about 6~7M memory, and the wpf use around 260M memory! That`s horriable for a empty template project.

Is there anything wrong with my Windows laptop settings? or it`s just a by-design behavior?

Here is the dotnet --info output,

.NET SDK:
 Version:   7.0.203
 Commit:    5b005c19f5

Runtime Environment:
 OS Name:     Windows
 OS Version:  10.0.19045
 OS Platform: Windows
 RID:         win10-x64
 Base Path:   C:\Program Files\dotnet\sdk\7.0.203\

Host:
  Version:      7.0.5
  Architecture: x64
  Commit:       8042d61b17

.NET SDKs installed:
  6.0.408 [C:\Program Files\dotnet\sdk]
  7.0.203 [C:\Program Files\dotnet\sdk]
  7.0.300-preview.23179.2 [C:\Program Files\dotnet\sdk]

.NET runtimes installed:
  Microsoft.AspNetCore.App 5.0.17 [C:\Program Files\dotnet\shared\Microsoft.AspNetCore.App]
  Microsoft.AspNetCore.App 6.0.16 [C:\Program Files\dotnet\shared\Microsoft.AspNetCore.App]
  Microsoft.AspNetCore.App 7.0.5 [C:\Program Files\dotnet\shared\Microsoft.AspNetCore.App]
  Microsoft.NETCore.App 5.0.17 [C:\Program Files\dotnet\shared\Microsoft.NETCore.App]
  Microsoft.NETCore.App 6.0.16 [C:\Program Files\dotnet\shared\Microsoft.NETCore.App]
  Microsoft.NETCore.App 7.0.5 [C:\Program Files\dotnet\shared\Microsoft.NETCore.App]
  Microsoft.WindowsDesktop.App 5.0.17 [C:\Program Files\dotnet\shared\Microsoft.WindowsDesktop.App]
  Microsoft.WindowsDesktop.App 6.0.16 [C:\Program Files\dotnet\shared\Microsoft.WindowsDesktop.App]
  Microsoft.WindowsDesktop.App 7.0.5 [C:\Program Files\dotnet\shared\Microsoft.WindowsDesktop.App]

Other architectures found:
  x86   [C:\Program Files (x86)\dotnet]
    registered at [HKLM\SOFTWARE\dotnet\Setup\InstalledVersions\x86\InstallLocation]

Environment variables:
  Not set

global.json file:
  C:\Users\liu\source\repos\global.json

Learn more:
  https://aka.ms/dotnet/info

Download .NET:
  https://aka.ms/dotnet/download
Developer technologies | Windows Presentation Foundation
Developer technologies | .NET | Other
{count} votes

2 answers

Sort by: Most helpful
  1. Hui Liu-MSFT 48,681 Reputation points Microsoft External Staff
    2023-05-16T09:00:54.3566667+00:00

    Hi,@William Liu. Welcome Microsoft Q&A.

    The difference in memory usage between a WPF application and a WinForms application is not necessarily due to any settings on your Windows laptop. It's a result of the different architectures and technologies used by WPF and WinForms.

    WPF (Windows Presentation Foundation) is a more feature-rich and flexible UI framework compared to WinForms. It offers advanced graphics capabilities, hardware acceleration, vector-based rendering, and a more extensive set of controls. However, these additional features come at the cost of increased memory consumption.

    On the other hand, WinForms (Windows Forms) is a simpler and lightweight UI framework that provides basic UI controls and simpler rendering. It is designed to have a smaller memory footprint compared to WPF.

    The difference in memory usage you observed is expected and can be attributed to the underlying architectural and design choices of each framework. WPF applications tend to use more memory due to their advanced features and the overhead required for rendering and managing the UI elements.

    It's worth noting that the memory usage of an empty template project may not accurately represent the actual memory requirements of a real-world application. As you start adding functionality, controls, and resources to your application, the memory usage will vary based on your specific implementation.

    In summary, the higher memory usage of a WPF application compared to a WinForms application is generally a by-design behavior due to the differences in their respective architectures and feature sets.


    If the response is helpful, please click "Accept Answer" and upvote it.

    Note: Please follow the steps in our documentation to enable e-mail notifications if you want to receive the related email notification for this thread.


  2. davidjohnson 5 Reputation points
    2023-05-16T13:44:35.2433333+00:00

    The memory consumption of a WPF application can be influenced by several factors that may contribute to it appearing higher than a Windows Forms (WinForms) application. Here are a few possible reasons:

    Rendering Engine: WPF applications use a more advanced rendering engine that offers rich graphics capabilities, hardware acceleration, and resolution independence. This can lead to higher memory usage compared to the simpler drawing system used by WinForms.

    Resource Intensive Features: WPF provides powerful features like data binding, styling, animation, and visual effects. These features can require additional memory to store and process the associated resources.

    XAML and Object Model: WPF applications define their user interfaces using XAML, which is a more expressive and flexible markup language compared to the UI definition in WinForms. The XAML parsing and the creation of the associated object model can contribute to increased memory usage.

    Dependency Properties: WPF utilizes dependency properties, which add more functionality and flexibility compared to regular properties. However, dependency properties also consume more memory due to their design.

    UI Composition: WPF supports complex UI composition with features like control templating, visual trees, and visual elements. These capabilities allow for more dynamic and interactive user interfaces but can result in increased memory usage.

    It's important to note that the perceived memory consumption can vary depending on the specific implementation and complexity of the application. It's recommended to perform memory profiling and optimization techniques, such as using efficient data structures, minimizing resource usage, and properly managing object lifetimes, to optimize the memory consumption of your WPF application.

    regard;

    Davidjohnson
