IoT Central Device registered but not provisioning

Reguis, Natalie 0 Reputation points

Hi, I need some help with devices on Azure Iot Central. My sensors are on Wanesy platform and I have added 1 to Iot Central. It shows as "Registered" but never goes to "Provisioned". Could you please help me to find out what is wrong?

Azure IoT Device Provisioning Service
Azure IoT Device Provisioning Service
A helper service for Azure IoT Hub that enables zero-touch, just-in-time provisioning to the right IoT hub without requiring human intervention.
99 questions
{count} votes

2 answers

Sort by: Most helpful
  1. AshokPeddakotla-MSFT 11,661 Reputation points

    @Reguis, Natalie Welcome to Microsoft Q&A forum!

    My sensors are on Wanesy platform and I have added 1 to Iot Central. It shows as "Registered" but never goes to "Provisioned". Could you please help me to find out what is wrong?

    Could you please confirm how exactly you have added the device?

    If your device is showing as "Registered" but not "Provisioned" in Azure IoT Central, it means that the device has successfully connected to the IoT Central application, but has not yet been provisioned with the necessary credentials to communicate with the IoT Hub.

    To provision the device, you need to create a device template in IoT Central that defines the device capabilities and properties, and then associate the device with the template. Once the device is associated with the template, IoT Central will generate the necessary credentials and configuration information for the device to connect to the IoT Hub.

    Please see IoT Central device connectivity guide for more details.

    If your device is still not showing as "Provisioned" after following these steps, there may be an issue with the device configuration or connectivity. You can try troubleshooting the issue by checking the device logs and verifying that the device is correctly configured to communicate with IoT Central.

    I hope this helps! Let us know if you have any further questions. Happy to assist you.

  2. Sander van de Velde 17,936 Reputation points MVP

    Hello Natalie Regius,

    to connect the Wanesy platform to IoT Central, you probably followed a tutorial like this one.

    I'm not familiar with the Wanasy platform but it seems there is no direct integration so you are supposed to put a 'bridge' Azure Function between your platform and IoT Central. (If you use another method, please share the tutorial)

    Can you check the logging of the Azure Function?

    There is should show that incoming Wanesy (lora) messages are arriving.

    The Azure Function logic tries to register a new device for each device if needed. Then it tries to send the message to IoT Central.

    If nothing happens over there, the configuration in the Wanesy platform must be checked.

    If a message arrives in the Azure Function, please check for any error text.

    If the response helped, do "Accept Answer". If it doesn't work, please let us know the progress. All community members with similar issues will benefit by doing so. Your contribution is highly appreciated.

    0 comments No comments
