Hello ,
I am seeing below error when i see the Event viewer logs on which Azure Integration run time is installed .
I also see My linked service connection is failing .
TestConnection failed, error message: 'Type=Microsoft.DataTransfer.SecurityValidation.Exceptions.HostValidationException,Message=Access to msm-cgm is denied, resolved IP address is fe80::b3a9:613a:9d23:f49f%8, network type is OnPremise,Source=Microsoft.DataTransfer.SecurityValidation,StackTrace= at Microsoft.DataTransfer.SecurityValidation.HostValidator.HandleDisallowedHostWithLogging(Action1 writeLog, Boolean throwException, Tuple3 args, Boolean isOnPrem) at Microsoft.DataTransfer.SecurityValidation.HostValidator.IsAllowedHost(String host, NetworkType networkType, Boolean enableLocalMachineAccessFromOnPremise, Action1 writeAccessDeniedLog, Action1 writeDnsFailureLog, Boolean throwExceptionUponValidationFailure) at Microsoft.DataTransfer.SecurityValidation.HostValidator.IsAllowed(String hostOrUri, NetworkType networkType, Boolean enableLocalMachineAccessFromOnPremise, Action1 writeAccessDeniedLog, Action1 writeDnsFailureLog, Boolean throwExceptionUponValidationFailure) at Microsoft.DataTransfer.Common.HostValidationRuntimeCommonHelper.ValidateHostWithLogging(String host, Guid jobId, Guid activityId, ComputeType computeType, Boolean enableLocalMachineAccessFromOnPremise, Boolean disableLocalFolderPathValidation, Boolean throwExceptionUponValidationFailure, Boolean supportLocalFolderPathValidation, Boolean shouldValidateFolderPath) at Microsoft.DataTransfer.Runtime.FileServerConnectionSettings..ctor(IDictionary2 properties, Boolean skipHostValidation) at Microsoft.DataTransfer.Runtime.FileServerConnection..ctor(IDictionary2 properties) at Microsoft.DataTransfer.Runtime.FileServerConnector.CreateConnection(IDictionary2 properties) at Microsoft.DataTransfer.Runtime.Provider.HybridRuntimeConnection.Initialize(ConnectionSetting connectionSettings, PluginRegistration plugins, String dataFactoryName, String dataFactoryId, String dataFactoryRegionAbbrev, String linkedIRCredential, AzureCloudType azureCloudType, String miStoreVersion, DataTransferCredentials credentials) at Microsoft.DataTransfer.Runtime.Provider.HybridRuntimeConnection..ctor(ConnectionSetting connectionSettings, PluginRegistration plugins, IMemoryLimit memoryLimit, String dataFactoryName, String dataFactoryId, String dataFactoryRegionAbbrev, String linkedIRCredential, AzureCloudType azureCloudType, String miStoreVersion, DataTransferCredentials credentials) at Microsoft.DataTransfer.TransferTask.InteractiveTaskFactoryV2.ConnectorTestConnection(ConnectionSetting connectionSetting, TestConnectionV2Response response) at Microsoft.DataTransfer.TransferTask.InteractiveTaskFactoryV2.TestConnection(TestConnectionV2Request request, TestConnectionV2Response response, CancellationToken token) at Microsoft.DataTransfer.TransferTask.InteractiveTask2.Execute(),'. Log ID: Error
Hello @Madhukar Muddasani
Thanks for reaching out on this forum!
Did you check if the network connectivity between the Azure Integration Runtime and the host?
You can try reconfiguring the linked service connection and test the connection again.
I have the same issue. I have two independent servers running SHIRs. They updated on 06/16/2023 @ 03:16:20AM & every pipeline has failed since that update.
Current SHIR Version: 529.8535.1 (Data Factory V2).
Server-side diagnostics on the SHIR passes.
Data factory pipeline failure error example:
Operation on target [pipeline action] failed: ErrorCode=InvalidParameter,'Type=Microsoft.DataTransfer.Common.Shared.HybridDeliveryException,Message=The value of the property '' is invalid: 'Access to [servername] is denied, resolved IP address is [ipv6address]%5, network type is OnPremise'.,Source=,''Type=Microsoft.DataTransfer.SecurityValidation.Exceptions.HostValidationException,Message=Access to [servername] is denied, resolved IP address is [ipv6address]%5, network type is OnPremise,Source=Microsoft.DataTransfer.SecurityValidation,'
Server-side event log error example:
Copy failed with error: 'Type=Microsoft.DataTransfer.SecurityValidation.Exceptions.HostValidationException,Message=Access to [servername] is denied, resolved IP address is [ipv6address]%5, network type is OnPremise,Source=Microsoft.DataTransfer.SecurityValidation,StackTrace= at Microsoft.DataTransfer.SecurityValidation.HostValidator.HandleDisallowedHostWithLogging(Action`1 writeLog, Boolean throwException, Tuple`3 args, Boolean isOnPrem)
at Microsoft.DataTransfer.SecurityValidation.HostValidator.IsAllowedHost(String host, NetworkType networkType, Boolean enableLocalMachineAccessFromOnPremise, Action`1 writeAccessDeniedLog, Action`1 writeDnsFailureLog, Boolean throwExceptionUponValidationFailure)
at Microsoft.DataTransfer.SecurityValidation.HostValidator.IsAllowed(String hostOrUri, NetworkType networkType, Boolean enableLocalMachineAccessFromOnPremise, Action`1 writeAccessDeniedLog, Action`1 writeDnsFailureLog, Boolean throwExceptionUponValidationFailure)
at Microsoft.DataTransfer.Common.HostValidationRuntimeCommonHelper.ValidateHostWithLogging(String host, Guid jobId, Guid activityId, ComputeType computeType, Boolean enableLocalMachineAccessFromOnPremise, Boolean disableLocalFolderPathValidation, Boolean throwExceptionUponValidationFailure, Boolean supportLocalFolderPathValidation, Boolean shouldValidateFolderPath)
at Microsoft.DataTransfer.Runtime.FileServerConnectionSettings..ctor(IDictionary`2 properties, Boolean skipHostValidation)
at Microsoft.DataTransfer.Runtime.FileServerConnection..ctor(IDictionary`2 properties)
at Microsoft.DataTransfer.Runtime.FileServerConnector.CreateConnection(IDictionary`2 properties)
at Microsoft.DataTransfer.Runtime.Provider.HybridRuntimeConnection.Initialize(ConnectionSetting connectionSettings, PluginRegistration plugins, String dataFactoryName, String dataFactoryId, String dataFactoryRegionAbbrev, String linkedIRCredential, AzureCloudType azureCloudType, String miStoreVersion, DataTransferCredentials credentials)
at Microsoft.DataTransfer.Runtime.Provider.HybridRuntimeConnection..ctor(ConnectionSetting connectionSettings, PluginRegistration plugins, IMemoryLimit memoryLimit, String dataFactoryName, String dataFactoryId, String dataFactoryRegionAbbrev, String linkedIRCredential, AzureCloudType azureCloudType, String miStoreVersion, DataTransferCredentials credentials)
at Microsoft.DataTransfer.Runtime.TableDefinitionHelper.GetSourceSchema(IDictionary`2 transferPayload, PluginRegistration plugins)
at Microsoft.DataTransfer.TransferTask.CopyTask.RemoveExtraColumns(IDictionary`2 payload)
at Microsoft.DataTransfer.TransferTask.CopyTask.PreProcessSourceSchemaInfo()
at Microsoft.DataTransfer.TransferTask.CopyTask.PrepareCopyPipeline()
at Microsoft.DataTransfer.TransferTask.CopyTask.DoCopy()
at Microsoft.DataTransfer.TransferTask.CopyTaskBase.Execute(),'
Job ID: eca28d80-7efd-6ca8-6fbf-767c0784439c
Log ID: Error
Hello @Patrick DeLine, @Madhukar Muddasani,
Please send an email to azcommunity@microsoft.com with the below details, so that we can work closely on this matter.
Your Email Subject : Attn Satish Boddu
Your Email Body content must include the below:
Thread URL: Link to this thread.
Your Azure Subscription ID: <This is must to be provided to us>
Same issue here - 3:14am June 16th. SHIR - same error.
Hello @Jeremy Banas, Thanks for reaching out on this forum and informing us about the issue!
Please submit a Technical support ticket on this issue from your Azure Subscription to get an immediate help!
Hello all, We have escalated this internally, please leave a comment in the below section:
Your impacted region:
Impact time started at UTC:
Your impacted region: East US
Impact time started at UTC: 7: 14 AM - June 16
As described above - this coincided with an update to the SHIR 529.8535.1
Noted! Thanks for sharing!
Solved for us. Thank you!
@Patrick DeLine How did you check the date & time of the SHIR update? I'm only able to verify that I'm on the latest version:
This was the solution for us:
C:\Program Files\Microsoft Integration Runtime\5.0\Shared> .\dmgcmd.exe -elma
@Jeremy Banas, As per the offline discussion, the below steps would be helpful in resolving the issue!!!
Set up or manage an existing self-hosted IR.
Dmgcmd.exe is included in the self-hosted installer. It's typically located in the C:\Program Files\Microsoft Integration Runtime\4.0\Shared\ folder. This application supports various parameters and can be invoked via a command line using batch scripts for automation.
Open a PowerShell and run the below command:
dmgcmd -elma
This should be resolving your issue!!
Hello @Madhukar Muddasani Just checking if we are still connected on this discussion? Please let us know if you need to add more info so that we better assist you!
If the response is helpful, please click "Accept Answer" and upvote it. So that we can close this thread.
I just applied the command "dmgcmd -elma" and the IR was fixed. The error occurred when trying to copy files to the node machine.
Thanks for this help.
I'm using a network shared folder path like \serverA\foldername. But still have this problem.
Did you try the below command?
C:\Program Files\Microsoft Integration Runtime\5.0\Shared> .\dmgcmd.exe -elma
We had another customer having the same problem and the above worked for them.
To me it sounds like a regression defect if you have to run that cmd for the network shared folder path.
A MS ticket opened for this with TrackingID#2306200030003178
We also experience the same problem when reading files from a On-prem file storage. Worked well before latest version on IR. Should a support ticket be registered for us as well?
Same issue per 23-06-2023, seems to be related to the SHIR update 5.29.8535.1.
Even we encountered the same issue post IR version upgrade to (5.32.8600.2) version, running (C:\Program Files\Microsoft Integration Runtime\5.0\Shared> .\dmgcmd.exe -elma) on SHIR VM fixed the issue.
