How do I extract only specific files from a compressed file using ADF?

Question

I am working on a File Extraction pipeline.

I have one compressed file (i.e., CompressedA) stored in one container which contains 5 separate files (i.e., File1-File5). In a scenario where user only requires File1, File2 and File5, how do I extract them without rerunning the pipeline multiple times?

The flow is as such:

Container 1: CompressedA >> decompressed to Container2: File1-File5 >> extract specific files to UserContainer.

Answer 1

Hi Alfi Khair

After decompressing the file, if you want to extract specific files, you can use the combination of get metadata activity, foreach loop and an if condition plus a copy activity.

1. use an array variable (called filenames) to hold the list of files that need to be copied to UserContainer. for instance like below. ["File1.txt","File2.txt","File5.txt"]. You can alternatively have this in a lookup file or table. choice is yours. Here let's consider using an array in the pipeline.
2. use Get Metadata activity to get list of decompressed files
3. use a foreach loop to loop over decompressed files
   1. inside foreach use if condition to check if item().name is in the array variable using the below expression: @contains(variables('filenames'),item().name)
   . The above condition will check if the current file name in foreach loop matches any of the array value. In the true part have a copy activity to copy file from source to UserContainer. Leave the false part empty.
   1. Hope it helps. Please feel free to write back if you have any further questions on it.
