Saving <div> as an image cuts out huge part of the image

Question

Saving <div> as an image cuts out huge part of the image

Donald Symmons 3,066

I tried to capture an image displayed on a web page into pdf, the entire image is cut during the capturing.

After I uploaded a certificate image ( in .jpeg or .png), I tried to capture the whole certificate using the html2canvas library but the image is cut. The only image I see is the top-left corner of the certificate image. But when the image is in image format, the entire image shows. I think the issue could be from where the captured image is converted into pdf

How can I make it to capture the entire certificate, please?

Here is my result when converting to PDF

cut out

You can sse that I have only top-left part of the certificate.

But this is the result when the capture is in image format (.png)

HTML

Here is my HTML and JavaScript

<div class="row col-sm-12" style="width: 100%; margin: 0 auto; padding: 6px; margin-right: auto; margin-left: auto; margin-bottom: 20px">
                <div class="col-sm-3" style="width: 100%; margin: 0 auto; padding: 7px; margin-top: 10px;">
                    <div class="row">
                        <div class="col-md-12">
                            <div class="form-group">
                                <asp:Label runat="server">Choose Font</asp:Label>
                                <div class="input-group">
                                    <input type="text" runat="server" class="fonts form-control" id="fonts" />
                                </div>
                            </div>
                        </div>
                    </div>
                    <div class="row">
                        <div class="col-md-12">
                            <div class="form-group">
                                <label runat="server" id="Label6">Name Font Size</label>
                                <div class="input-group">
                                    <asp:DropDownList ID="NameFontSize" runat="server" CssClass="form-control" onchange="NameSize(this.value)">
                                    </asp:DropDownList>
                                </div>
                            </div>
                        </div>
                    </div>
                    <div class="row">
                        <div class="col-md-12">
                            <div class="form-group">
                                <label runat="server" id="Label22">Date Font Size</label>
                                <div class="input-group">
                                    <asp:DropDownList ID="DateFontSize" runat="server" CssClass="form-control" onchange="ChangeDateSize(this.value)">
                                    </asp:DropDownList>
                                </div>
                            </div>
                        </div>
                    </div>
                    <div class="btnfront" runat="server" id="portraitBtn" style="margin: 0 auto; width: 100%; margin-top: 5%; padding-bottom: 6px;">
                        <asp:Button ID="SaveCert" runat="server" CssClass="btn btn-primary navbar-btn" Text="Save Certificate" OnClick="ConvertImgTopdf" UseSubmitBehavior="false" OnClientClick="return ConvertCert(this)" />
                    </div>
                    <div id="dvMessage" runat="server" visible="false" class="alert alert-danger" style="margin-bottom: 1%; padding: 6px;">
                        <asp:Label ID="lblMessage" runat="server" Font-Size="9pt" />
                    </div>
                </div>
                <div class="col-sm-9" runat="server" id="section">
                    <asp:Image Class="imgfile" ID="imgfile" runat="server" ImageUrl="~/images/4.jpeg" />
                    <asp:Label ID="LabelName" runat="server" Text="Recipient Name"></asp:Label>
                    <asp:Label ID="LabelDate" runat="server" Text="Date"></asp:Label>
                </div>
                <asp:HiddenField ID="ImageDatahf" runat="server" />
            </div>
                <script src="https://cdnjs.cloudflare.com/ajax/libs/popper.js/1.14.3/umd/popper.min.js" integrity="sha384-ZMP7rVo3mIykV+2+9J3UJ46jBk0WLaUAdn689aCwoqbBJiSnjAK/l8WvCWPIPm49" crossorigin="anonymous"></script>
    <script src="https://stackpath.bootstrapcdn.com/bootstrap/4.1.3/js/bootstrap.min.js" integrity="sha384-ChfqqxuZUCnJSK3+MXmPNIyE6ZbWh2IMqE241rYiqJxyMiZ6OW/JmZQ5stwEULTy" crossorigin="anonymous"></script>
    <script src="https://cdnjs.cloudflare.com/ajax/libs/popper.js/1.14.0/umd/popper.min.js" integrity="sha384-cs/chFZiN24E4KMATLdqdvsezGxaGsi4hLGOzlXwp5UZB1LY//20VyM2taTB4QvJ" crossorigin="anonymous"></script>
    <script src="https://stackpath.bootstrapcdn.com/bootstrap/4.1.0/js/bootstrap.min.js" integrity="sha384-uefMccjFJAIv6A+rW+L4AHf99KvxDjWSu1z9VI8SKNVmz4sk7buKt/6v9KI65qnm" crossorigin="anonymous"></script>
    <script src="https://ajax.googleapis.com/ajax/libs/jquery/2.1.1/jquery.min.js"></script>
    <link rel="stylesheet" href="https://rawgit.com/tommoor/fontselect-jquery-plugin/master/fontselect.css" />
    <script src="https://rawgit.com/tommoor/fontselect-jquery-plugin/master/jquery.fontselect.js"></script>
    <script src="js/bootstrap.min.js"></script>
    <script type="text/javascript">
        $(document).ready(function () {
            function selectFontAndApplyToEle(fontName, callback) {
                $('div.font-select').find('.fs-results li').removeClass('active');
                var dropEle = $('div.font-select').find('.fs-drop');
                var fontToSelect = $('div.font-select').find('.fs-results li:contains(' + fontName + ')');
                dropEle.addClass('fs-drop-op');
                var posFont = fontToSelect.offset().top
                var posFontOffset = $('div.font-select').find('.fs-results li:first').offset().top
                $('div.font-select').find('.fs-results').scrollTop(posFont - posFontOffset);
                fontToSelect.addClass('active').trigger('click');
                setTimeout(function () {
                    $('div.font-select a div').trigger('click');
                    dropEle.removeClass('fs-drop-op');
                    callback && callback(fontToSelect.data('value').replace(/\+/g, ' '));
                }, 500);
            }
            $(function () {
                $('input.fonts').fontselect({
                    style: 'font-select',
                    placeholder: 'Select a font',
                    lookahead: 2
                }).on('change', function (e) {
                    var fontFamily = $(this).val().replace(/\+/g, ' ');
                    $('#LabelName').css('font-family', fontFamily);
                    $('#LabelDate').css('font-family', fontFamily);
                });
                selectFontAndApplyToEle('Anton', function (fontFamily) {
                    $('#LabelName').css('font-family', fontFamily);
                    $('#LabelDate').css('font-family', fontFamily);
                    setTimeout(function () {
                        selectFontAndApplyToEle('Anonymous Pro', function (fontFamily) {
                            $('#LabelName').css('font-family', fontFamily);
                            $('#LabelDate').css('font-family', fontFamily);
                        });
                    }, 1000);
                });
            });
        });
    </script>
    <script type="text/javascript" src="https://html2canvas.hertzen.com/dist/html2canvas.min.js"></script>
    <script type="text/javascript">
        function ConvertCert(SaveCert) {
            html2canvas($("#section")[0], { scale: 3 })
                .then(function (canvas) {
                    var base64 = canvas.toDataURL();
                    $("[id*=ImageDatahf]").val(base64);
                    __doPostBack(SaveCert.name, "");
                });
        }
    </script>

C#

        //This is when the Image is downloaded in it's normal format e.g. .png or .jpeg
        protected void ExportToImage(object sender, EventArgs e)
        {
            string base64 = Request.Form[ImageDatahf.UniqueID].Split(',')[1];
            byte[] bytes = Convert.FromBase64String(base64);
            Response.Clear();
            Response.ContentType = "image/png";
            Response.AddHeader("Content-Disposition", "attachment; filename=HTML.png");
            Response.Buffer = true;
            Response.Cache.SetCacheability(HttpCacheability.NoCache);
            Response.BinaryWrite(bytes);
            Response.End();
        }
        //This is the code that it converts to PDF
        protected void ConvertImgTopdf(object sender, EventArgs e)
        {
            string imagedata = ImageDatahf.Value;
            byte[] imagebytes = Convert.FromBase64String(convert);

            //Initialize the PDF document object.
            using (Document pdfDoc = new Document())
            {
                PdfWriter writer = PdfWriter.GetInstance(pdfDoc, Response.OutputStream);
                pdfDoc.Open();

                //Add the Image file to the PDF document object.
                iTextSharp.text.Image img = iTextSharp.text.Image.GetInstance(imagebytes);
                pdfDoc.Add(img);
                pdfDoc.Close();

                //Download the PDF file.
                Response.ContentType = "application/pdf";
                Response.AddHeader("content-disposition", "attachment;filename=ImageExport.pdf");
                Response.Cache.SetCacheability(HttpCacheability.NoCache);
                Response.Write(pdfDoc);
                Response.End();
            }
        }

Lan Huang-MSFT 30,191 Reputation points Microsoft External Staff

2023-12-15T09:15:09.9133333+00:00

Hi @Donald Symmons,

I tested your code and it can be successfully converted to images but there will be problems when converting to PDF. I think the main reason is that your image is too large, exceeding the size that the PDF can render. Because iTextSharp is a third-party library, I don’t know much about it. It may also be a limitation of PDF itself.

Maybe you save directly as an image?

Accepted answer

0 additional answers

Your answer

Lan Huang-MSFT 30,191 Reputation points Microsoft External Staff

2023-12-15T09:15:09.9133333+00:00

Hi @Donald Symmons,

I tested your code and it can be successfully converted to images but there will be problems when converting to PDF. I think the main reason is that your image is too large, exceeding the size that the PDF can render. Because iTextSharp is a third-party library, I don’t know much about it. It may also be a limitation of PDF itself.

Maybe you save directly as an image?

Answer 1

Lan Huang-MSFT 30,191 Microsoft External Staff

Hi @Donald Symmons,

I found that there is a way to design the image size in the iTextSharp library, maybe you can try it.

The following places need to be changed:

 <div class="col-sm-9" runat="server" id="section" style="width:80%;height:80%">
                    <asp:Image Class="imgfile" ID="imgfile" runat="server" Width="100%" Height="100%" ImageUrl="~/images/4.png" />
                    <asp:Label ID="LabelName" runat="server" Text="Recipient Name"></asp:Label>
                    <asp:Label ID="LabelDate" runat="server" Text="Date"></asp:Label>
                </div>

 //Add the Image file to the PDF document object.
                iTextSharp.text.Image img = iTextSharp.text.Image.GetInstance(imagebytes);
                img.SetDpi(100, 100);

                img.ScaleToFit(500f, 1000f);
                pdfDoc.Add(img);
                pdfDoc.Close();

User's image

Best regards,
Lan Huang

If the answer is the right solution, please click "Accept Answer" and kindly upvote it. If you have extra questions about this answer, please click "Comment".
Note: Please follow the steps in our documentation to enable e-mail notifications if you want to receive the related email notification for this thread.

Donald Symmons 3,066 Reputation points

2023-12-16T04:46:10.61+00:00

Hi @Lan Huang-MSFT

You're very good!. Thanks @Lan Huang-MSFT . I have learnt a lot from you, and hope to learn more.

If I may, I still have about a question or two to ask regarding this. Is it possible to make automatically adjust the PDF to the orientation of the certificate?

What I mean is, if the certificate document is in landscape mode, the PDF should also be in landscape, and if the certificate is portrait, the PDF should be portrait mode.

Secondly, I tried to make the certificate image fit, and cover the full width and height of the PDF but it did not work.
Lan Huang-MSFT 30,191 Reputation points Microsoft External Staff

2023-12-18T03:43:03.4666667+00:00

Hi @Donald Symmons,

In fact, both of your questions require simply converting the <div> content to an image. I don't quite understand why you would go to all the trouble of converting it to a PDF file.

If you want to cover the entire width and height of the PDF, you must also consider the size and column ratio of the <div> itself, otherwise the rendering will not be very good.
Donald Symmons 3,066 Reputation points

2023-12-18T05:07:22.9166667+00:00

Hi @Lan Huang-MSFT , the reason why I want to convert it to pdf is that, most ecertificates are downloaded in pdf. So I am trying to create a situation where a user can create ecertificates and send to recipients. After user uploads his or her certificate background design in .png, and adding recipient's name and issue date, the user will save the certificate in pdf for onward sending to each recipient.

Lan Huang-MSFT 30,191 Microsoft External Staff

Hi @Donald Symmons,

After some research, I found that one way to create a landscape PDF would be to use a RectangleReadOnly with switched width and height values:

Document doc = new Document(new RectangleReadOnly(842,595), 10f, 10f, 10f, 10f);

I modified the code and it should do what you need.

 //This is the code that it converts to PDF
        protected void ConvertImgTopdf(object sender, EventArgs e)
        {
            string imagedata = ImageDatahf.Value;
            byte[] imagebytes = Convert.FromBase64String(convert);
            System.Drawing.Image image = System.Drawing.Image.FromStream(new System.IO.MemoryStream(imagebytes));
            if (Convert.ToInt64(image.Width.ToString()) > Convert.ToInt64(image.Height.ToString()))
            {
                //Initialize the PDF document object.
                using (Document pdfDoc = new Document(new RectangleReadOnly(842, 595), 0f, 0f, 0f, 0f))
                {
                    PdfWriter writer = PdfWriter.GetInstance(pdfDoc, Response.OutputStream);
                    pdfDoc.Open();

                    //Add the Image file to the PDF document object.
                    iTextSharp.text.Image img = iTextSharp.text.Image.GetInstance(imagebytes);
                    img.SetDpi(100, 100);

                    img.ScaleToFit(842, 595);

                    pdfDoc.Add(img);
                    pdfDoc.Close();

                    //Download the PDF file.
                    Response.ContentType = "application/pdf";
                    Response.AddHeader("content-disposition", "attachment;filename=ImageExport.pdf");
                    Response.Cache.SetCacheability(HttpCacheability.NoCache);
                    Response.Write(pdfDoc);
                    Response.End();
                }
            }
            else
            {
                using (Document pdfDoc = new Document(new RectangleReadOnly(595, 842), 0f, 0f, 0f, 0f))
                {
                    PdfWriter writer = PdfWriter.GetInstance(pdfDoc, Response.OutputStream);
                    pdfDoc.Open();

                    //Add the Image file to the PDF document object.
                    iTextSharp.text.Image img = iTextSharp.text.Image.GetInstance(imagebytes);
                    img.SetDpi(100, 100);

                    img.ScaleToFit(595, 842);

                    pdfDoc.Add(img);
                    pdfDoc.Close();

                    //Download the PDF file.
                    Response.ContentType = "application/pdf";
                    Response.AddHeader("content-disposition", "attachment;filename=ImageExport.pdf");
                    Response.Cache.SetCacheability(HttpCacheability.NoCache);
                    Response.Write(pdfDoc);
                    Response.End();
                }
            }

        }

<html xmlns="http://www.w3.org/1999/xhtml">
<head runat="server">
    <title></title>
      <script src="https://cdnjs.cloudflare.com/ajax/libs/popper.js/1.14.3/umd/popper.min.js" integrity="sha384-ZMP7rVo3mIykV+2+9J3UJ46jBk0WLaUAdn689aCwoqbBJiSnjAK/l8WvCWPIPm49" crossorigin="anonymous"></script>
    <script src="https://stackpath.bootstrapcdn.com/bootstrap/4.1.3/js/bootstrap.min.js" integrity="sha384-ChfqqxuZUCnJSK3+MXmPNIyE6ZbWh2IMqE241rYiqJxyMiZ6OW/JmZQ5stwEULTy" crossorigin="anonymous"></script>
    <script src="https://cdnjs.cloudflare.com/ajax/libs/popper.js/1.14.0/umd/popper.min.js" integrity="sha384-cs/chFZiN24E4KMATLdqdvsezGxaGsi4hLGOzlXwp5UZB1LY//20VyM2taTB4QvJ" crossorigin="anonymous"></script>
    <script src="https://stackpath.bootstrapcdn.com/bootstrap/4.1.0/js/bootstrap.min.js" integrity="sha384-uefMccjFJAIv6A+rW+L4AHf99KvxDjWSu1z9VI8SKNVmz4sk7buKt/6v9KI65qnm" crossorigin="anonymous"></script>
    <script src="https://ajax.googleapis.com/ajax/libs/jquery/2.1.1/jquery.min.js"></script>
    <link rel="stylesheet" href="https://rawgit.com/tommoor/fontselect-jquery-plugin/master/fontselect.css" />
    <script src="https://rawgit.com/tommoor/fontselect-jquery-plugin/master/jquery.fontselect.js"></script>
    <script src="js/bootstrap.min.js"></script>
    <script type="text/javascript">
        $(document).ready(function () {
            function selectFontAndApplyToEle(fontName, callback) {
                $('div.font-select').find('.fs-results li').removeClass('active');
                var dropEle = $('div.font-select').find('.fs-drop');
                var fontToSelect = $('div.font-select').find('.fs-results li:contains(' + fontName + ')');
                dropEle.addClass('fs-drop-op');
                var posFont = fontToSelect.offset().top
                var posFontOffset = $('div.font-select').find('.fs-results li:first').offset().top
                $('div.font-select').find('.fs-results').scrollTop(posFont - posFontOffset);
                fontToSelect.addClass('active').trigger('click');
                setTimeout(function () {
                    $('div.font-select a div').trigger('click');
                    dropEle.removeClass('fs-drop-op');
                    callback && callback(fontToSelect.data('value').replace(/\+/g, ' '));
                }, 500);
            }
            $(function () {
                $('input.fonts').fontselect({
                    style: 'font-select',
                    placeholder: 'Select a font',
                    lookahead: 2
                }).on('change', function (e) {
                    var fontFamily = $(this).val().replace(/\+/g, ' ');
                    $('#LabelName').css('font-family', fontFamily);
                    $('#LabelDate').css('font-family', fontFamily);
                });
                selectFontAndApplyToEle('Anton', function (fontFamily) {
                    $('#LabelName').css('font-family', fontFamily);
                    $('#LabelDate').css('font-family', fontFamily);
                    setTimeout(function () {
                        selectFontAndApplyToEle('Anonymous Pro', function (fontFamily) {
                            $('#LabelName').css('font-family', fontFamily);
                            $('#LabelDate').css('font-family', fontFamily);
                        });
                    }, 1000);
                });
            });
        });
    </script>
    <script type="text/javascript" src="https://html2canvas.hertzen.com/dist/html2canvas.min.js"></script>
    <script type="text/javascript">
        function ConvertCert(SaveCert) {
            html2canvas($("#section")[0])
                .then(function (canvas) {
                    var base64 = canvas.toDataURL();
                    $("[id*=ImageDatahf]").val(base64);
                    __doPostBack(SaveCert.name, "");
                });
        }
    </script>
</head>
<body>
    <form id="form1" runat="server">
        <div class="row col-sm-12" style="width: 100%; margin: 0 auto; padding: 6px; margin-right: auto; margin-left: auto; margin-bottom: 20px">
                <div class="col-sm-3" style="width: 100%; margin: 0 auto; padding: 7px; margin-top: 10px;">
                    <div class="row">
                        <div class="col-md-12">
                            <div class="form-group">
                                <asp:Label runat="server">Choose Font</asp:Label>
                                <div class="input-group">
                                    <input type="text" runat="server" class="fonts form-control" id="fonts" />
                                </div>
                            </div>
                        </div>
                    </div>
                    <div class="row">
                        <div class="col-md-12">
                            <div class="form-group">
                                <label runat="server" id="Label6">Name Font Size</label>
                                <div class="input-group">
                                    <asp:DropDownList ID="NameFontSize" runat="server" CssClass="form-control" onchange="NameSize(this.value)">
                                    </asp:DropDownList>
                                </div>
                            </div>
                        </div>
                    </div>
                    <div class="row">
                        <div class="col-md-12">
                            <div class="form-group">
                                <label runat="server" id="Label22">Date Font Size</label>
                                <div class="input-group">
                                    <asp:DropDownList ID="DateFontSize" runat="server" CssClass="form-control" onchange="ChangeDateSize(this.value)">
                                    </asp:DropDownList>
                                </div>
                            </div>
                        </div>
                    </div>
                    <div class="btnfront" runat="server" id="portraitBtn" style="margin: 0 auto; width: 100%; margin-top: 5%; padding-bottom: 6px;">
                        <asp:Button ID="SaveCert" runat="server" CssClass="btn btn-primary navbar-btn" Text="Save Certificate" OnClick="ConvertImgTopdf" UseSubmitBehavior="false" OnClientClick="return ConvertCert(this)" />
                    </div>
                    <div id="dvMessage" runat="server" visible="false" class="alert alert-danger" style="margin-bottom: 1%; padding: 6px;">
                        <asp:Label ID="lblMessage" runat="server" Font-Size="9pt" />
                    </div>
                </div>
                <div class="col-sm-9" runat="server" id="section" style="width:80%;height:80%">
                    <asp:Image Class="imgfile" ID="imgfile" runat="server" Width="100%" Height="100%" ImageUrl="~/images/4.PNG" />
                    <asp:Label ID="LabelName" runat="server" Text="Recipient Name"></asp:Label>
                    <asp:Label ID="LabelDate" runat="server" Text="Date"></asp:Label>
                </div>
                <asp:HiddenField ID="ImageDatahf" runat="server" />
            </div>
    </form>
</body>
</html>

User's image

Donald Symmons 3,066 Reputation points

2023-12-18T06:52:15.0333333+00:00

Hi @Lan Huang-MSFT ,

Document doc = new Document(new RectangleReadOnly(842,595), 10f, 10f, 10f, 10f);

Could this mean that if the certificate of a user is in portrait mode, RectanlgeReadOnly will not work? Because from the name, I'm thinking that it's only to read rectangle mode.
Lan Huang-MSFT 30,191 Reputation points Microsoft External Staff

2023-12-18T07:02:58.7533333+00:00

Hi @Donald Symmons,

Judging from the screenshots I provided above, I have tested both results for you. Why do you think the portrait mode doesn't work?

From my understanding, RectangleReadOnly(width, height) defines a rectangle with width 842 and height 595. To incorporate the portrait you want, just change the width and height.
Donald Symmons 3,066 Reputation points

2023-12-18T07:19:01.5833333+00:00

Hi @Lan Huang-MSFT ,

Judging from the screenshots I provided above, I have tested both results for you.

The second screenshot is blank in my end, nothing is displayed.

Thank you

Share via

Saving <div> as an image cuts out huge part of the image

0 additional answers

Your answer
