Windows Form Table

Question

Hi,

I would like to add a user input table to a windows form, I would like the user to be able to enter the number of rows required but restrict the maximum number of rows to 6.

The table would have 5 columns, (1 description entry & 4 numerical value entries) & the user can either select the number of rows required from a drop down list or enter the number in a textbox or something, but only be able to enter a maximum of 6 rows.

I would then like use the to numerical values entered to calculate various equations & create a chart.

I am not very experienced with coding but would appreciate it if anyone could tell me if this is possible & hopefully provide some guidance on how to do this.

Best Regards,

Sean

Answer 1

hopefully provide some guidance on how to do this.

Mainly you can use a DataGridView Control (Windows Forms) to enter data row-wise.

The article have several links with guidance & details, go through them.

Answer 2

Hello,

If you want to create a table-like structure in a Windows Forms application using C#, you can use the DataGridView control. The DataGridView control is a versatile control that allows you to display and edit data in tabular format. Here's a simple example to get you started:

1. Open Visual Studio and create a new Windows Forms Application project.
2. Drag and drop a DataGridView control from the Toolbox onto your form.
3. Set the properties of the DataGridView control, such as Name (e.g., dataGridView1) and adjust its size.
4. Open the code-behind file (Form1.cs) and add the following code:

using System;
using System.Collections.Generic;
using System.Windows.Forms;

namespace WindowsFormsTableExample
{
    public partial class Form1 : Form
    {
        public Form1()
        {
            InitializeComponent();

            // Call a method to populate the DataGridView with data
            PopulateDataGridView();
        }

        private void PopulateDataGridView()
        {
            // Create a list of data (you can replace this with your data source)
            List<Person> people = new List<Person>
            {
                new Person { Name = "John", Age = 25, City = "New York" },
                new Person { Name = "Jane", Age = 30, City = "Los Angeles" },
                new Person { Name = "Bob", Age = 22, City = "Chicago" }
            };

            // Bind the list to the DataGridView
            dataGridView1.DataSource = people;
        }

        // Define a simple data model (replace this with your actual data model)
        public class Person
        {
            public string Name { get; set; }
            public int Age { get; set; }
            public string City { get; set; }
        }
    }
}
