Hybrid Pipeline Error

Question

I'm trying to create a hybrid pipeline for ml purposes. Firstly, I run the data preparation step on my local machine, then I want to upload the new dataset to azure and run the train on azure. If I run the train step manually in Azure there is no error. But if I run the train step in a pipeline(still on azure) an error occurs: UserErrorException: Pipeline input expected azure.ai.ml.Input or primitive types (str, bool, int or float) but received type <class 'main.Train'>. The error occurs in cnc_miling_pipelinev2 function

class Train(BaseEstimator, TransformerMixin):
    def __init__(self,train_src_dir,train_data_csv_path,test_data_csv_path):
        self.train_src_dir = train_src_dir
        self.train_data_csv_path = train_data_csv_path
        self.test_data_csv_path = test_data_csv_path
        self.azure_authenticate()
    def azure_authenticate(self):
        try:
            credential = DefaultAzureCredential()
            # Check if given credential can get token successfully.
            credential.get_token("https://management.azure.com/.default")
        except Exception as ex:
            # Fall back to InteractiveBrowserCredential in case DefaultAzureCredential not work
            credential = InteractiveBrowserCredential()
        self.ml_client = MLClient.from_config(credential=credential)
    def fit(self,X=None, y=None):
        return self

    def data_load(self,):
        self.train_data_csv = Data(
            name="train_data_csv",
            path=self.train_data_csv_path,
            type=AssetTypes.URI_FILE,
            description="train_data_csv",
            tags={"source_type": "local", "source": "AzureML CNC blob"},
            version="1.2.9")
        self.train_data_csv = self.ml_client.data.create_or_update(self.train_data_csv)
		print(
            f"Dataset with name {self.train_data_csv.name} was registered to workspace, the dataset version is {self.train_data_csv.version}"
        )
        self.test_data_csv = Data(
            name="test_data_csv",
            path=self.test_data_csv_path,
            type=AssetTypes.URI_FILE,
            description="test_data_csv",
            tags={"source_type": "local", "source": "AzureML CNC blob"},
            version="1.2.9")
        self.test_data_csv = self.ml_client.data.create_or_update(self.test_data_csv)
        print(
            f"Dataset with name {self.test_data_csv.name} was registered to workspace, the dataset version is {self.test_data_csv.version}"
        )

    @dsl.pipeline(compute="x",description="CNC prep train pipeline v2",)
    def cnc_miling_pipelinev2(self,
        pipeline_train_data,
        pipeline_test_data,
        pipeline_job_learning_rate,
        pipeline_job_registered_model_name):
        print("HELLO")
        # using data_prep_function like a python call with its own inputs

        # using train_func like a python call with its own inputs
        train_job = self.train_component(
            train_data=pipeline_train_data,  # note: using outputs from previous step
            test_data=pipeline_test_data,  # note: using outputs from previous step
            learning_rate=pipeline_job_learning_rate,  # note: using a pipeline input as parameter
            registered_model_name=pipeline_job_registered_model_name
        )

            # a pipeline returns a dictionary of outputs
            # keys will code for the pipeline output identifier

    def transform(self,X=None, y=None):
        # Loading the component from the yml file
        self.train_component = load_component(source=os.path.join(self.train_src_dir, "train.yml"))
        # Now we register the component to the workspace
        self.train_component = self.ml_client.create_or_update(self.train_component)

        # Create (register) the component in your workspace
        print(
            f"Component {self.train_component.name} with Version {self.train_component.version} is registered"
        )
        self.data_load()
        registered_model_name = "cnc_miling_modelV2"
        # Let's instantiate the pipeline with the parameters of our choice
        # Let's instantiate the pipeline with the parameters of our choice
        print("self.train_data_csv.path" , self.train_data_csv.path, "self.test_data_csv.path: ", self.test_data_csv.path)
        print("\n\n")
        pipeline_train = self.cnc_miling_pipelinev2(
            pipeline_train_data=Input(type="uri_file", path=self.train_data_csv.path),
            pipeline_test_data=Input(type="uri_file", path=self.test_data_csv.path),
            pipeline_job_learning_rate=0.05,
            pipeline_job_registered_model_name=registered_model_name
        )
        print("self.cnc_miling_pipelinev2 OK")
        self.ml_client.jobs.create_or_update(pipeline_train,
                                            # Project's name
                                            experiment_name="cnc_miling_exp_v2")

Answer 1

@Halil Yeşil I think you have setup the components correctly but trying to use then under Train() class is passing the class as input to the pipeline_train job or pipeline instead. Try to use them directly instead as mentioned in this sample. I think as you mentioned just using self.cnc_miling_pipelinev2() might have worked like self.data_load() but with setting it up as pipeline as self.ml_client.jobs.create_or_update() it fails.

If this answers your query, do click Accept Answer and Yes for was this answer helpful. And, if you have any further query do let us know.
