How to remove bottom border on MAUI Navigation Bar

SSB 86 Reputation points
2024-02-29T13:51:45.0333333+00:00

Hi on a navigation page, how to remove the bottom grey border on the top navigation bar?

.NET MAUI
.NET MAUI
A Microsoft open-source framework for building native device applications spanning mobile, tablet, and desktop.
2,831 questions
0 comments No comments
{count} votes

1 answer

Sort by: Most helpful
  1. Leon Lu (Shanghai Wicresoft Co,.Ltd.) 67,781 Reputation points Microsoft Vendor
    2024-03-01T02:44:17.0866667+00:00

    Hello,

    ===========Update==============

    there appears to be some lag where the top of the bar is gray for a second and then turns back to white when first opening the navigation page. This is where the status bar is at the top.

    Yes, I can reproduce this issue. Please add UINavigationBar.Appearance.ShadowImage = new UIImage(); in your AppDelegate.cs like following code. And remove following NavigationRenderer solution. I test it in my device. Here is no grey status bar after navigating.

    [Register("AppDelegate")]
    public class AppDelegate : MauiUIApplicationDelegate
    {
        protected override MauiApp CreateMauiApp()
        {
           UINavigationBar.Appearance.ShadowImage = new UIImage();
             return   MauiProgram.CreateMauiApp();
        }
    }


    =========NavigationRenderer solution=============

    I tested all the platforms, and only iOS platform has bottom grey border on the top navigation bar.

    You can create a custom NavigationRenderer in the Platfroms/iOS folder, then set NavigationBar.ShadowImage to a new UIImage like following code.

    using UIKit;
    using Microsoft.Maui.Controls.Handlers.Compatibility;

    namespace MauiSwipeViewDemo.Platforms.iOS
    {
        public class MyNavigationPageRenderer : NavigationRenderer
        {
            public MyNavigationPageRenderer()
            {
            }
            public override void ViewDidLoad()
            {
                base.ViewDidLoad();
                NavigationBar.ShadowImage = new UIImage();
                NavigationBar.ClipsToBounds = true; // optional
            }
        }
    }


    In the end, you can register the custom renderer by ConfigureMauiHandlers in the MauiProgram.cs

    builder.ConfigureMauiHandlers((hanlders) =>
                    {
    #if IOS
                        hanlders.AddHandler(typeof(NavigationPage),typeof(MauiSwipeViewDemo.Platforms.iOS.MyNavigationPageRenderer));
    #endif

                   })


    Best Regards,

    Leon Lu
