Hi @RAVI,
You can use QRCoder, an open source library QR code generator, by Manage Nuget Packages download.
I wrote an example based on your code for your reference.
<asp:GridView ID="GridView1" runat="server" AutoGenerateColumns="false" OnRowDataBound="GridView1_RowDataBound">
<Columns>
<asp:BoundField ItemStyle-Width="150px" DataField="CustomerID" HeaderText="Customer ID" />
<asp:TemplateField HeaderText="NAME">
<ItemTemplate>
<asp:Label ID="PN" runat="server" ForeColor="Black" Text='<%# Bind("Name") %>'></asp:Label>
<asp:Image ID="QRImage1" runat="server" Width="50" Height="50" Visible="false" />
</ItemTemplate>
<HeaderStyle ForeColor="Teal"></HeaderStyle>
<ItemStyle HorizontalAlign="Center" />
</asp:TemplateField>
</Columns>
</asp:GridView>
protected void Page_Load(object sender, EventArgs e)
{
if (!this.IsPostBack)
{
this.BindGrid();
}
}
private void BindGrid()
{
string constr = ConfigurationManager.ConnectionStrings["ConString"].ConnectionString;
using (SqlConnection con = new SqlConnection(constr))
{
using (SqlCommand cmd = new SqlCommand("SELECT CustomerId, Name FROM Customers"))
{
using (SqlDataAdapter sda = new SqlDataAdapter())
{
cmd.Connection = con;
sda.SelectCommand = cmd;
using (DataTable dt = new DataTable())
{
sda.Fill(dt);
GridView1.DataSource = dt;
GridView1.DataBind();
}
}
}
}
}
protected void GridView1_RowDataBound(object sender, GridViewRowEventArgs e)
{
if (e.Row.RowType == DataControlRowType.DataRow)
{
Label lbName = (e.Row.FindControl("PN") as Label);
System.Web.UI.WebControls.Image image = (e.Row.FindControl("QRImage1") as System.Web.UI.WebControls.Image);
lbName.Visible = false;
image.Visible = true;
QRCodeGenerator qrGenerator = new QRCodeGenerator();
QRCodeData qrCodeData = qrGenerator.CreateQrCode(lbName.Text, QRCodeGenerator.ECCLevel.Q); QRCode qrCode = new QRCode(qrCodeData);
using (Bitmap bitMap = qrCode.GetGraphic(10))
{
using (MemoryStream ms = new MemoryStream())
{
bitMap.Save(ms, System.Drawing.Imaging.ImageFormat.Png);
byte[] byteImage = ms.ToArray();
}
}
}
}
Best regards,
Lan Huang
