Change Label Data In to QR code For Free

Question

Hello

This is my gridview data

<asp:TemplateField HeaderText="NAME">
<ItemTemplate>
 <asp:Label ID="PN" runat="server" ForeColor="Black" Text='<%# Bind("process_name") %>'></asp:Label>
</ItemTemplate>
<HeaderStyle ForeColor="Teal"></HeaderStyle>
<ItemStyle HorizontalAlign="Center" />
</asp:TemplateField>

I need to convert this data into QR code and it should be free license for commercial use.

Answer 1

Hi @RAVI,

You can use QRCoder, an open source library QR code generator, by Manage Nuget Packages download.

I wrote an example based on your code for your reference.

 <asp:GridView ID="GridView1" runat="server" AutoGenerateColumns="false" OnRowDataBound="GridView1_RowDataBound">
              <Columns>
                  <asp:BoundField ItemStyle-Width="150px" DataField="CustomerID" HeaderText="Customer ID" />
                  <asp:TemplateField HeaderText="NAME">
                      <ItemTemplate>
                          <asp:Label ID="PN" runat="server" ForeColor="Black" Text='<%# Bind("Name") %>'></asp:Label>
                          <asp:Image ID="QRImage1" runat="server" Width="50" Height="50" Visible="false" />
                      </ItemTemplate>
                      <HeaderStyle ForeColor="Teal"></HeaderStyle>
                      <ItemStyle HorizontalAlign="Center" />
                  </asp:TemplateField>
              </Columns>
          </asp:GridView>

protected void Page_Load(object sender, EventArgs e)
{
    if (!this.IsPostBack)
    {
        this.BindGrid();
    }
}
private void BindGrid()
{
    string constr = ConfigurationManager.ConnectionStrings["ConString"].ConnectionString;
    using (SqlConnection con = new SqlConnection(constr))
    {
        using (SqlCommand cmd = new SqlCommand("SELECT CustomerId, Name FROM Customers"))
        {
            using (SqlDataAdapter sda = new SqlDataAdapter())
            {
                cmd.Connection = con;
                sda.SelectCommand = cmd;
                using (DataTable dt = new DataTable())
                {
                    sda.Fill(dt);
                    GridView1.DataSource = dt;
                    GridView1.DataBind();
                }
            }
        }
    }
}
protected void GridView1_RowDataBound(object sender, GridViewRowEventArgs e)
{
    if (e.Row.RowType == DataControlRowType.DataRow)
    {
        Label lbName = (e.Row.FindControl("PN") as Label);
        System.Web.UI.WebControls.Image image = (e.Row.FindControl("QRImage1") as System.Web.UI.WebControls.Image);
        lbName.Visible = false;
        image.Visible = true;
        QRCodeGenerator qrGenerator = new QRCodeGenerator();
        QRCodeData qrCodeData = qrGenerator.CreateQrCode(lbName.Text, QRCodeGenerator.ECCLevel.Q); QRCode qrCode = new QRCode(qrCodeData);
        using (Bitmap bitMap = qrCode.GetGraphic(10))
        {
            using (MemoryStream ms = new MemoryStream())
            {
                bitMap.Save(ms, System.Drawing.Imaging.ImageFormat.Png);
                byte[] byteImage = ms.ToArray();
            }
        }
    }
}

Best regards,
Lan Huang

---

If the answer is the right solution, please click "Accept Answer" and kindly upvote it. If you have extra questions about this answer, please click "Comment".
Note: Please follow the steps in our documentation to enable e-mail notifications if you want to receive the related email notification for this thread.

Answer 2

see this article:

https://www.c-sharpcorner.com/article/generate-qr-code-in-asp-net-core-mvc2/
