Adding a Hypervisor on Azure VM

Sheik Mohamed Yasar 105 Reputation points
2024-04-03T08:25:40.56+00:00

Is it possible to add a hypervisor such as Hyper V or Vmware Esxi on top of an Azure VM for production environment?

Azure VMware Solution
Azure VMware Solution
An Azure service that runs native VMware workloads on Azure.
313 questions
Hyper-V
Hyper-V
A Windows technology providing a hypervisor-based virtualization solution enabling customers to consolidate workloads onto a single server.
2,529 questions
{count} votes

Accepted answer
  1. Yanhong Liu 1,315 Reputation points Microsoft Vendor
    2024-04-03T09:43:43.3633333+00:00

    Hello,

    As mentioned earlier, it's feasible to run Hyper-V on Azure VMs. However, you may not be able to install VMware ESXi in an Azure VM. Reference Links: Can Azure VMs allow for nested VMWare and VirtualBox VMs? - Microsoft Q&A

    Best Regards,

    Yanhong Liu

    ============================================

    If the Answer is helpful, please click "Accept Answer" and upvote it.

    0 comments No comments

4 additional answers

Sort by: Most helpful
  1. Anveshreddy Nimmala 2,150 Reputation points Microsoft Vendor
    2024-04-03T09:15:15.74+00:00

    Hello Sheik Mohamed Yasar,

    Welcome to microsoft Q&A, Thankyou for posting your query here.

    Yes it can done , using SKU Standard_D2s_v3 VM size that supports Nested Virtualization.

    The Standard_D2s_v3 variant is compatible with Nested Virtualization, but it's crucial to configure it to Standard security.

    When you get to the Review page, right before you click to deploy the VM, setting up this VM with the D2s_v3 model, it's mandate to select Standard security.

    This selection is available under the Basics tab during the VM's creation phase in the portal, labeled as 'azure security type : standard'.

    User's image

    Once you have the VM created you can install Hyper-V inside of it, create VMs, etc.

    please refer the link for the same.

    https://learn.microsoft.com/en-us/virtualization/hyper-v-on-windows/user-guide/enable-nested-virtualization

    Hope this helps you.If an answer has been helpful, please consider accepting the answer to help increase visibility of this question for other members of the Microsoft Q&A community. If not, please let us know what is still needed in the comments so the question can be answered. Thank you for helping to improve Microsoft Q&A

    f0c6ee09-372a-46c3-b232-747087569b29




  2. Andreas Baumgarten 95,336 Reputation points MVP
    2024-04-03T09:22:49.0033333+00:00

    Hi @Sheik Mohamed Yasar ,

    at least it's possible to run Hyper-V on an Azure VM. This configuration is called "Nested Virtualization".

    There are How-To articles around in the web. One I tried my self with success is this on: How to set up Nested Virtualization in Microsoft Azure


    (If the reply was helpful please don't forget to upvote and/or accept as answer, thank you)

    Regards

    Andreas Baumgarten


  3. Arzan Patel 0 Reputation points
    2024-04-03T12:09:00.8433333+00:00

    Hello,
    Yes, it is possible to add a hypervisor (Hyper V) on top of an Azure VM for production environment; however, you need to perform extra steps for routing etc. as the networking within Hyper-V on Azure is different than the traditional Hyper-V we are aware of.

    Kind regards,

    Arzan Patel

    0 comments No comments

  4. Alex Bykovskyi 1,681 Reputation points
    2024-04-09T11:42:57.9433333+00:00

    Hey,

    As already noted, it is possible to run nested hypervisor on top of Azure VM. You should choose specific instances to be able to install hypervisor. https://azure.microsoft.com/en-us/blog/nested-virtualization-in-azure/

    The following article should help with configuration: https://www.starwindsoftware.com/blog/nested-virtualization-in-azure-with-starwind-vsan

    Cheers,

    Alex Bykovskyi

    StarWind Software
