It's in the Anti-phishing policies. You can review those and if you don't see it explicitly blocked, create a new policy that allows QR codes though. Another place to double check would be safe links.
How to allow QR Code images to show in the email body
Petrus Hishekwa
36
Reputation points
Hi Support,
I have an issue or QR code images being removed from emails.
I have investigated on my mail filtering systems, but I am failing to find where the rule is configured.
I am would like to know if anyone can help to point me where to look in Microsoft Defender, Exchange, Intune as this are the Microsoft product we are using in our environment.
I am implementing an MDM with manage engine plus and when I send the invite email to users for enrollment the QR CODE Image is being removed.
Please guide me on where to look for this.
Thank you.
Outlook | Windows | Classic Outlook for Windows | For business
{count} votes
-
SokiGuo-MSFT 31,541 Reputation points Microsoft External Staff2024-04-12T08:10:32.7133333+00:00 Hi @Petrus Hishekwa
Welcome to our forum！
Please kindly understand that the Outlook tag here we mainly focus on general issues about Outlook desktop client.
Do you mean the QR code won't show up on the Outlook client?
Will other images or links be displayed properly?
Are there any error messages or codes? If there are screenshots, please make sure to hide your private information.
-
Shawn Collins 610 Reputation points2024-04-13T01:54:18.8966667+00:00 Downloading image is generally off by default, so you can enable that. Also, are your clients using HTML or rich text? Plain text won't show the images.
-
Petrus Hishekwa 36 Reputation points
2024-04-13T14:03:18.5866667+00:00 @SokiGuo-MSFT Thank you for your reply.
Yes, the QR code is not showing on the outlook client, other links in the same email body are showing. The error says: "QR Code Image is removed" in the new outlook and outlook (PWA). In the normal outlook client the error read as: "The linked image cannot be displayed. The file may have been moved, renamed, or deleted. Verify that the link points to the correct file and location."
Screenshots:
Waiting on your guidance.
Thank you.
-
Shawn Collins 610 Reputation points
2024-04-13T14:09:44.79+00:00 You can try clearing cookies and also verify your security software policies aren't removing it. Do they show up in OWA or other mail client?
-
Petrus Hishekwa 36 Reputation points
2024-04-13T14:22:21.2433333+00:00 @Shawn Collins I tried opening the email in Gmail and it shows the QR code due to that I assumed the QR is being removed somewhere in Office 365, I am looking for direction to where to look at make adjustment in Office 365. I have checked with all the security tools and could find anywhere that this is ruled. No one in my domain is able to see the code thus I believe this is configured centrally somewhere.
-
Shawn Collins 610 Reputation points
2024-04-13T15:18:23.8366667+00:00 So that’s likely EOP which is part of defender. Check your anti-phishing, etc policies. QRs were blocked by MS by default.
-
Petrus Hishekwa 36 Reputation points
2024-04-13T16:45:16.6366667+00:00 @Shawn Collins This point to what I think is happening too. I have checked the policy and Rules on MS defender, I am still failing to pin point where QRs are seem to be blocked. Do you know specifically where I should look for the default setting, rule or policy by MS that blocks QRs?
-
john mcdermott 0 Reputation points2024-08-11T20:14:13.2433333+00:00 8/12/2024
on email select PRINT. a PRINT PREVIEW displays for print options, chose MORE SETTINGS, OPTIONS: CHECK BACKGROUND GRAPHICS at bottom.
VOILA!
Sign in to comment
2 answers
Sort by: Most helpful
-
Shawn Collins 610 Reputation points
2024-04-13T17:52:18.5466667+00:00 -
SokiGuo-MSFT 31,541 Reputation points Microsoft External Staff
2024-04-19T05:10:59.84+00:00 Hi @Petrus Hishekwa
Is there any update on this case?
Please feel free to drop us a note if there is any update.
-
Petrus Hishekwa 36 Reputation points
2024-04-20T15:23:52.4666667+00:00 Hi @SokiGuo-MSFT ,
I haven't find a solution on this yet. I am still trying to see where exactly in defender or exchange could this be configured by default.
I will appreciate it if you have other new guides.
-
SokiGuo-MSFT 31,541 Reputation points Microsoft External Staff
2024-04-22T08:13:41.7033333+00:00 Hi @Petrus Hishekwa
According to my research, this also has something to do with the security settings of Internet Explorer. To resolve this problem, disable the Internet Explorer Security setting Do not save encrypted pages to disk.
- Exit Outlook
- Open Internet Options, and then select the Advanced tab.
- Under the Security heading, disable the Do not save encrypted pages to disk option.
- Select OK.
- Start Outlook.
In the event you are unable to disable the Do not save encrypted pages to disk option, it is being managed by Group Policy. Contact your system administrator to determine the appropriate configuration for this setting.
-
SokiGuo-MSFT 31,541 Reputation points Microsoft External Staff
2024-04-30T07:24:46.14+00:00 Hi @Petrus Hishekwa
Just checking in to see if above information was helpful. If you have any further updates on this issue, please feel free to post back.
Sign in to comment -
-
هنية عبدالحفيظ القماطي 0 Reputation points2024-04-13T18:13:15.7166667+00:00 Thank you all. I have asked for comments on the topic
