BUG in Azure Machine Configuration assignment for ARC machines
Andrew
31
Reputation points
When trying to assign Machine Configuration in the ARC machine portal GUI it always fails with a ResourceNotFound error.
I guess it is because, when creating Machine Configuration, it always uses Microsoft.Compute/virtualMachines instead of Microsoft.HybridCompute/machines in the JSON template type key.
I think this is the problem, because if I manually customize the JSON template to look like this
And deploy it as a custom template, it works and policy gets assigned to the device.
Same goes when creating such assignment via "Guest Assignment" portal.
{count} votes
-
AnuragSingh-MSFT 21,076 Reputation points2024-06-20T08:06:49.12+00:00 @Andrew, thank you for posting this question on Q&A.
All the screenshots attached with the thread are missing. Could you please attach them again.
I am sorry, I could not understand the question. Could you please share the steps that you are following (or relevant document) to he me understand the issue better.
-
Andrew 31 Reputation points
2024-06-20T08:23:36.26+00:00 Edited
-
AnuragSingh-MSFT 21,076 Reputation points
2024-06-20T13:31:57.98+00:00 @Andrew, thank you for the clarification. I tested and I was able to see similar behavior. I am reaching out to the team to get more details and will update this thread.
