Deploying new Azure Stack HCI cluster "The selected physical network adapter os not binded to the management virtual switch"
CM
15
Reputation points
Hi all,
I'm currently deploying a HCI cluster. the first time I deployed it, the network drivers and TPM module were missing. so after fixing those I deleted everythhing and started over again. but this time I have a new error.
This time at the Networking tab, under "Provide intent details" I have the following error
"The selected physical network adapter os not binded to the management virtual switch"
I have already checked on the two nodes, there is no switch, and I believe the error is incorrect, because the deployment of the cluster will create that intent.
Thanks in advance !
Regards
Che
{count} votes
-
-
CM 15 Reputation points
2024-08-21T11:50:48.8766667+00:00 Thank you! included a screenshot.
-
Christian Götz 15 Reputation points2024-08-21T13:44:15.0333333+00:00 Same Problem here
-
Christian Götz 15 Reputation points
2024-08-22T10:36:39.0433333+00:00 I opend a Support case for that, The solution was, to unregister the Node in azure Arc using the follwing Command ->
Remove-AzStackHciArcInitialization -SubscriptionID $Subscription -ResourceGroup $RG -TenantID $Tenant -Cloud AzureCloud -ArmAccessToken $ARMtoken -AccountID $id
Reboot the Hosts and Register it again. This worked for me
-
Christian Götz 15 Reputation points
2024-08-22T10:38:12.7933333+00:00 I made a Support Case for that, and the solution was to unregister the Hosts with azure Arc and register it again.
to unregister us the following command
Remove-AzStackHciArcInitialization -SubscriptionID $Subscription -ResourceGroup $RG -TenantID $Tenant -Cloud AzureCloud -ArmAccessToken $ARMtoken -AccountID $id
this worked for me
-
Srinud 2,425 Reputation points Microsoft Vendor
2024-08-26T11:13:47.4333333+00:00 Hi CM,
Based on your response. the selected physical network adapter is not binded to the management virtual switch.
Please find the troubleshoot documentation for your reference: https://learn.microsoft.com/en-us/azure-stack/hci/manage/troubleshoot-deployment
Thank you.
-
CM 15 Reputation points
2024-08-26T14:27:31.2533333+00:00 Remove-AzStackHciArcInitialization indeed did the trick.
I have a different error now :-) regarding switchname, while I specifically did not chose a switch,...
Type 'InvokeEnvironmentChecker' of Role 'DeploymentService' raised an exception: System.Management.Automation.RuntimeException: Fail to initialize cloud deployment: Cannot validate argument on parameter 'SwitchName'. The argument is null or empty. Provide an argument that is not null or empty, and then try the command again.
-
-
CM 15 Reputation points
2024-08-30T10:54:47.94+00:00 I've checked the generated file "Unattended.json", and idd during generation of that file, there is no parameter or reference for SwitchName
-
This is NOT Jochen (Admin) 0 Reputation points2024-09-02T07:48:12.71+00:00 Same error here, 3rd time now I do the setup. First TPM, then network drivers and now this one.
-
Srinud 2,425 Reputation points Microsoft Vendor
2024-09-04T10:54:08.2666667+00:00 Hi CM,
Thanks for getting back with the detailed explanation. This issue needs deeper investigation and Azure technical support team will be able to help with this. I would recommend you open an azure support case. If you don't have the ability to open a technical support ticket, please let me know and I can help you further with this.
-
Edwin Ron Ocampo 0 Reputation points2024-09-26T01:06:27.8733333+00:00 Has there been any resolution to this issue yet? I am also seeing the same exact error on to of my Azure Stack HCI clusters.
Error:
Type 'InvokeEnvironmentChecker' of Role 'DeploymentService' raised an exception: System.Management.Automation.RuntimeException: Fail to initialize cloud deployment: Cannot validate argument on parameter 'SwitchName'. The argument is null or empty. Provide an argument that is not null or empty, and then try the command again.
