SOLVED! M365DSC certificate authentication fails with "does not have a private key" error

Shawn Goodwin 176 Reputation points
2024-11-12T16:02:46.0466667+00:00

I am deploying an M365DSC infra for my org. I've followed the pre-requisites and installed and updated DSC on a stand-alone Azure VM. I intend to use certificate authentication and created the EntraID application using the Update-M365DSCAzureAdApplication cmdlet. I am a Global Admin and ran this command using my creds and permissions.

PS C:\Windows\System32> Update-M365DSCAzureAdApplication
>> -ApplicationName 'Microsoft365DSC'
>> -AdminConsent
>> -Type Certificate
>> -CreateSelfSignedCertificate
>> -CertificatePath C:\temp\M365DSC.cer
>> -Permissions @(
>> @{Api='Graph';PermissionName='User.Read.All'},
>> @{Api='Graph';PermissionName='UserAuthenticationMethod.Read.All'},
>> ......lots of permissions.....
>> )

The cert gets created and I install the cert to the User Personal store. (I know the instructions on the official documentation say to install the cert to the LocalMachine Personal store, but I was having connection problems and found that the Connect-MgGraph cmdlet only looks for certs in the User Personal store, so I installed the cert in both locations).

I connect using the following values:

$TenantId='mycompany.onmicrosoft.com'
$AppId='xxxxxxxx-xxxx-xxxx-xxxx-xxxxxxxxxxx'
$CertThumbprint='xxx....'  #cert thumprint copied from certificate entry in EntraID Application.

I am trying to connect with connect-mggraph -ApplicationId $AppId -CertificateThumbprint $CertThumbprint -TenantId $TenantId

Each time I try to connect, I get the following error; Connect-MgGraph: ClientCertificateCredential authentication failed: The certificate certificate does not have a private key.

By default, the cert created by the Update-M365DSCAzureAdApplication cmdlet does not have a private key. What am I doing wrong?

edit: clarity

Windows Server PowerShell
Windows Server PowerShell
Windows Server: A family of Microsoft server operating systems that support enterprise-level management, data storage, applications, and communications.PowerShell: A family of Microsoft task automation and configuration management frameworks consisting of a command-line shell and associated scripting language.
5,576 questions
0 comments No comments
{count} votes

2 answers

Sort by: Most helpful
  1. Rich Matheisen 47,391 Reputation points
    2024-11-12T20:01:09.5266667+00:00

    I think this addresses your problem: https://github.com/microsoft/Microsoft365DSC/issues/2910


  2. Shawn Goodwin 176 Reputation points
    2024-11-13T22:21:28.5566667+00:00

    SOLVED!! Turns out PowerShell 7 is the culprit here. I was executing all previous commands using PowerShell 7.4 (because that's my preferred version). I took all the steps required to use PS7+, per https://microsoft365dsc.com/user-guide/get-started/powershell7-support/.

    On the EntraID App, I deleted all permissions and the previous certificate. I executed the same Update-M365DSCAzureAdApplication command using PowerShell 5.1. The cert was created and the same permissions assigned. I installed the cert to the user store and executed the Export-M365DSCConfiguration command. It authenticated successfully and exported the requested items.

    I then opened another PS7 session and executed the same Export command, and it successfully authenticated with the same cert thumbprint; no other changes were made!

    It would seem that the self-signed cert created under the PS7 session somehow differs than the one created under the PS5 session. I reported this to the devs on GitHub. Hopefully, this little knowledge-nugget makes its way into the documentation.
