Collapse/Expand image icon in Expander's header

ron123 1 Reputation point
2021-01-07T03:38:28.497+00:00

I am designing a page where I need to add expanders programmatically with every button click. In the expander's header, I want to show an image icon that displays the expand/collapse state. The expander is getting created without any problem, but the image icon representing Expand/collapse state is not working accurately.

I expect the Expander header to initially show "Icon_Expand.png", as shown below:

When a user clicks on the expander, the image should be replaced with "Icon_Collapse.png", as shown below:

The image icon changes for the first time to "Icon_Collapse.png" when I expand, but then it doesn't change back at all. I have posted the sample code below. Can somebody please guide what's wrong/missing?

 private Expander getNewExpander()
        {
            Entry EntryName = new Entry
            {
                Text = "",
                MinimumWidthRequest = 50,
                Placeholder = "Enter Name",
                FontSize = 16,
                VerticalOptions = LayoutOptions.Center
            };

            DataTrigger dTrigger = new DataTrigger(typeof(Image));
            Binding b = new Binding();
            b.Source = new RelativeBindingSource(RelativeBindingSourceMode.FindAncestor, typeof(Expander));
            b.Path = "IsExpanded";
            dTrigger.Binding = b;
            dTrigger.Value = true;
            Setter setterTrigger = new Setter();
            setterTrigger.Property = Image.SourceProperty;
            setterTrigger.Value = "Icon_Collapse.png";
            dTrigger.Setters.Add(setterTrigger);

            Image imgExpandCollapse = new Image
            {
                Source = "Icon_Expand.png",
                HorizontalOptions = LayoutOptions.End,
                VerticalOptions = LayoutOptions.CenterAndExpand,
                HeightRequest = 30
            };
            imgExpandCollapse.Triggers.Add(dTrigger);

            StackLayout stackHeader = new StackLayout
            {
                Orientation = StackOrientation.Horizontal,
                Spacing = 5
            };
            stackHeader.Children.Add(EntryName);
            stackHeader.Children.Add(imgExpandCollapse);

            Expander expander = new Expander
            {
                Header = stackHeader
            };
            StackLayout stackExpanderContent = new StackLayout();
            Entry entryDetails = new Entry
            {
                Text = "",
                Placeholder = "Enter Position",
                FontSize = 16,
                VerticalOptions = LayoutOptions.Center
            };
            stackExpanderContent.Children.Add(entryDetails);
            expander.Content = stackExpanderContent;

            return expander;
        }
