Heartbeat alert Azure Monitor
Adrian Chirtoc
126
Reputation points
Hello,
I am trying to figure out a way to monitor missing data / heartbeat..
First of all is : Why does the following does not work? Basically, if you have data => The Alert should be triggered. Is due to dimensions that for value 0 it is removed and not getting triggered any longer?
Second way: I am doing the way to export the systems where the heartbeat is missing for more then 5 min. Sadly in this way the Alert is keep generating each 5 min. Why does it not listen on Dimensions?
How can we have a easy and correct way to discover Heartbeat / Missing of data and generate for each System 1 Alert that will close Automatically when is starting to receive data again?
Isn`t there a way?
{count} votes
-
Adrian Chirtoc 126 Reputation points
2025-03-15T05:33:23.82+00:00 Now i am doing another test like this:
Stil.. i am geting an alert at each 5 min for the same server... Why?
-
Vinod Pittala 1,505 Reputation points Microsoft External Staff2025-03-24T08:24:46.22+00:00 Hello Adrian Chirtoc,
Apologies for the delay in response.
First of all is : Why does the following does not work? Basically, if you have data => The Alert should be triggered. Is due to dimensions that for value 0 it is removed and not getting triggered any longer?
Yes, if the data is available to be present, the alert can be triggered. however, Azure when a Threshold value is 0, it may not trigger alerts. To address this, set the aggregation type to "Count" and ensure the threshold value matches the evaluation granularity. Please refer to the documentation for more details. and see if it works.
Please refer to the below doc.
Second way: I am doing the way to export the systems where the heartbeat is missing for more then 5 min. Sadly in this way the Alert is keep generating each 5 min. Why does it not listen on Dimensions?
This happens because the frequency of evaluation is set to 5 minutes, meaning Azure Monitor checks the condition defined in your alert rule every 5 minutes. If the condition is met, the alert will trigger within that interval, resulting in repeated alerts.
How can we have a easy and correct way to discover Heartbeat / Missing of data and generate for each System 1 Alert that will close Automatically when is starting to receive data again?
Make sure you set up the Aggregation type to Count and the Threshold value to match the Evaluation granularity.
If the comment helpful, please click Upvote it.
Thanks
-
Vinod Pittala 1,505 Reputation points Microsoft External Staff
2025-03-25T07:47:23.3233333+00:00 Hello Adrian Chirtoc,
We haven't heard back from you regarding the solution i provided earlier. Could you please let us know if it was helpful? If you have any questions or encounter any issues, please don't hesitate to reach out. We are committed to resolving your concerns as a priority.
Thanks
-
Vinod Pittala 1,505 Reputation points Microsoft External Staff
2025-03-26T07:07:06.2066667+00:00 Hi Adrian Chirtoc,
I would like to check if the issue has been resolved or if you need any assistance. Please feel free to let us know, as we are always here to help.
Additionally, if you have a moment, please consider upvoting it if the information provided has been helpful. This can be beneficial to other community members and would be greatly appreciated.
Thank you.
