Adding skill from Azure portal to Copilot studio 401 error

Question

I have receievd the below error when I imported healthcare agent bot to Copilot studio. Can anyone help me to resolve this?
Error Message: Invoking skill 'healthcare-agent-skill' was not successful. HTTP status code 401. Error Code: SkillNotSuccesfulResponseCode Conversation Id: 124e4f99-6f26-4844-bdb8-1cc2e69a75a0 Time (UTC): 2025-05-15T10:03:15.341Z

Answer 1

Hello @Seena Khan ,

✅ Step-by-Step Solution

Step 1: Confirm the Skill Endpoint is Secured

Ensure the skill (healthcare-agent-skill) has a valid App ID and Password configured in the Azure Bot Channels Registration or in the configuration files if running locally.

---

Step 2: Match the Caller Bot’s Allowed Callers

In your skill bot's app settings (e.g., appsettings.json or in Azure under Application Settings), confirm the AllowedCallers configuration includes the App ID of the calling bot (parent bot):

"AllowedCallers": [ "<PARENT_BOT_APP_ID>" ]

✅ If you're using "AllowedCallers": [ "*" ], it means all bots are allowed, which can help for debugging but is insecure in production.

---

Step 3: Ensure Proper Credentials in the Parent Bot

In your parent bot (caller bot) configuration:

• It must have the skill’s App ID and Password set correctly in the bot's BotFrameworkSkills section (e.g., appsettings.json, BotServices.cs, or via Azure).

"BotFrameworkSkills": [

{

"Id": "healthcare-agent-skill",

"AppId": "<SKILL_BOT_APP_ID>",

"SkillEndpoint": "https://<SKILL_BOT_ENDPOINT>/api/messages"

}

]

---

Step 4: Confirm OAuth Identity

If you are using Azure Bot Services, make sure both bots (parent and skill) are:

• Registered in the same tenant, or
• Trusted using appropriate AAD permissions (cross-tenant calls require additional configuration).

---

Step 5: Verify Tokens and Environment

If running locally:

• Use the Bot Framework Emulator and ensure you provide the correct Microsoft App ID and Password.
• Restart the bot with updated environment variables if they changed.

---

Step 6: Check Bot-to-Skill Communication in Code

Ensure you're using the correct adapter and enabling skill communication. In .NET, for instance, this is handled using SkillHttpClient and SkillConversationIdFactory.

---

Step 7: Re-test After Fixing

After making these changes:

• Restart both parent and skill bots (if local).
• Retry the conversation.
• Watch the logs for updated status (should be 200 OK).

Thanks,

Shah

*************************************************************************
