Getting MSDTC error 0x8004D02B though all things look fine...

2021-03-03T11:16:48.923+00:00

Hi,

Getting below error related to MSDTC. Did some research for weeks. Every thing looks fine

  • Firewall configuration looks correct
  • Systems are pining by host name in both directions
  • MSDTC uninstalled and installed again
  • Component services configurations to allow network access is also granted
  • DTCPing is giving success
  • Registry entries(specifically the CID's) look good.

Finally gave up...
If any one can help me troubleshoot this issue, I will be great full to them....

Regards
JP

System.Transactions.TransactionManagerCommunicationException: Communication with the underlying transaction manager has failed. ---> System.Runtime.InteropServices.COMException: The MSDTC transaction manager was unable to pull the transaction from the source transaction manager due to communication problems. Possible causes are: a firewall is present and it doesn't have an exception for the MSDTC process, the two machines cannot find each other by their NetBIOS names, or the support for network transactions is not enabled for one of the two transaction managers. (Exception from HRESULT: 0x8004D02B) at System.Transactions.Oletx.IDtcProxyShimFactory.ReceiveTransaction(UInt32 propgationTokenSize, Byte[] propgationToken, IntPtr managedIdentifier, Guid& transactionIdentifier, OletxTransactionIsolationLevel& isolationLevel, ITransactionShim& transactionShim) at System.Transactions.TransactionInterop.GetOletxTransactionFromTransmitterPropigationToken(Byte[] propagationToken) --- End of inner exception stack trace --- at System.Transactions.TransactionInterop.GetOletxTransactionFromTransmitterPropigationToken(Byte[] propagationToken) at System.Transactions.TransactionStatePSPEOperation.PSPEPromote(InternalTransaction tx) at System.Transactions.TransactionStateDelegatedBase.EnterState(InternalTransaction tx) at System.Transactions.EnlistableStates.Promote(InternalTransaction tx) at System.Transactions.Transaction.Promote() at System.Transactions.TransactionInterop.ConvertToOletxTransaction(Transaction transaction) at System.Transactions.TransactionInterop.GetExportCookie(Transaction transaction, Byte[] whereabouts) at System.Data.SqlClient.SqlInternalConnection.GetTransactionCookie(Transaction transaction, Byte[] whereAbouts) at System.Data.SqlClient.SqlInternalConnection.EnlistNonNull(Transaction tx) at System.Data.SqlClient.SqlInternalConnection.Enlist(Transaction tx) at System.Data.ProviderBase.DbConnectionInternal.ActivateConnection(Transaction transaction) at System.Data.ProviderBase.DbConnectionPool.PrepareConnection(DbConnection owningObject, DbConnectionInternal obj, Transaction transaction) at System.Data.ProviderBase.DbConnectionPool.TryGetConnection(DbConnection owningObject, UInt32 waitForMultipleObjectsTimeout, Boolean allowCreate, Boolean onlyOneCheckConnection, DbConnectionOptions userOptions, DbConnectionInternal& connection) at System.Data.ProviderBase.DbConnectionPool.TryGetConnection(DbConnection owningObject, TaskCompletionSource1 retry, DbConnectionOptions userOptions, DbConnectionInternal& connection) at System.Data.ProviderBase.DbConnectionFactory.TryGetConnection(DbConnection owningConnection, TaskCompletionSource1 retry, DbConnectionOptions userOptions, DbConnectionInternal oldConnection, DbConnectionInternal& connection) at System.Data.ProviderBase.DbConnectionInternal.TryOpenConnectionInternal(DbConnection outerConnection, DbConnectionFactory connectionFactory, TaskCompletionSource1 retry, DbConnectionOptions userOptions) at System.Data.SqlClient.SqlConnection.TryOpenInner(TaskCompletionSource1 retry) at System.Data.SqlClient.SqlConnection.TryOpen(TaskCompletionSource1 retry) at System.Data.SqlClient.SqlConnection.Open() at System.Data.Linq.SqlClient.SqlConnectionManager.UseConnection(IConnectionUser user) at System.Data.Linq.SqlClient.SqlProvider.get_IsSqlCe() at System.Data.Linq.SqlClient.SqlProvider.InitializeProviderMode() at System.Data.Linq.SqlClient.SqlProvider.System.Data.Linq.Provider.IProvider.Execute(Expression query) at System.Data.Linq.DataQuery1.System.Collections.Generic.IEnumerable<T>.GetEnumerator() at System.Linq.Buffer1..ctor(IEnumerable1 source) at System.Linq.Enumerable.ToArrayTSource at sDx.Services.QueryUtilities.<>c__DisplayClass7_0.<GetRoles>b__0() at sDx.Utilities.Configuration.Cache.FromCacheT at sDx.Services.QueryUtilities.FromCacheT at System.Linq.Enumerable.<SelectManyIterator>d__233.MoveNext() at System.Linq.Enumerable.<DistinctIterator>d__641.MoveNext() at System.Linq.Enumerable.ContainsTSource

SQL Server
SQL Server
A family of Microsoft relational database management and analysis systems for e-commerce, line-of-business, and data warehousing solutions.
13,102 questions
0 comments No comments
{count} votes

2 answers

Sort by: Most helpful
  1. Olaf Helper 42,561 Reputation points
    2021-03-03T13:07:52.257+00:00

    On which action do you get the error message? Access a linked server? What for a query, an UPDATE/INSERT?

    The MSDTC transaction manager was unable to pull the transaction from the source transaction manager due to communication problems

    If it's a distributed transact, is MS DTC also setup on the other system? By the error message it looks like not.

    0 comments No comments

  2. Teemo Tang 11,366 Reputation points
    2021-03-04T07:04:40.12+00:00

    That 0x8004D02B error code is an MSDTC error code basically saying that MSDTC was unreachable on the other machine. When this happens every time, it's indicative of one of the issues in the error message, like NetBIOS resolution or firewall or MSDTC security settings.

    Check this similar case for a hint
    https://forums.asp.net/t/2084329.aspx?Problems+with+TransactionScope

    -------------------------------------------------------------------------------------

    If the Answer is helpful, please click "Accept Answer" and upvote it.
    Note: Please follow the steps in our documentation to enable e-mail notifications if you want to receive the related email notification for this thread.
