Treeview in .Net Core Console Application

Question

Hi,
How to create treeview in .Net Core console application dynamically

Answer 1

The treeview object has no meaning in console applications. Do you want to get tree-structured data in console applications?

That doesn't need a treeview object, but a class like this:

class Node
{
    public string Name { get;  set; }
    public List<Node> Children { get; set; }
    public Node()
    {
        Children = new List<Node>();
    }
}

You can use this class to store the tree structure and display it.

    static Node Node = new Node();
    static void Main(string[] args)
    {
        LoadDirectory(@"d:\test");

        List<Node> nodes = Node.Children;
        //......

        Console.WriteLine("Press any key to continue...");
        Console.ReadLine();
    }
    public static void LoadDirectory(string Dir)
    {
        DirectoryInfo di = new DirectoryInfo(Dir);
        Node.Name = di.Name;
        LoadFiles(Dir,  Node);
        LoadSubDirectories(Dir,  Node);
    }
    private static void LoadSubDirectories(string dir,  Node node)
    {
        string[] subdirectoryEntries = Directory.GetDirectories(dir);
        foreach (string subdirectory in subdirectoryEntries)
        {
            DirectoryInfo di = new DirectoryInfo(subdirectory);

            Node node1 = new Node();
            node1.Name = di.Name;
            node.Children.Add(node1);

            LoadFiles(subdirectory, node1);
            LoadSubDirectories(subdirectory, node1);
        }
    }
    private static void LoadFiles(string dir,  Node node)
    {
        string[] Files = Directory.GetFiles(dir, "*.*");

        foreach (string file in Files)
        {
            FileInfo fi = new FileInfo(file);

            Node node1 = new Node();
            node1.Name = fi.Name;
            node.Children.Add(node1);
        }
    }

---

If the response is helpful, please click "Accept Answer" and upvote it.
Note: Please follow the steps in our documentation to enable e-mail notifications if you want to receive the related email notification for this thread.

Answer 2

You cannot use any controls in a console application. If you need a GUI create a windows forms or WPF application

Answer 3

According to https://www.bing.com/search?q=add+reference+windows+forms+console+core and https://learn.microsoft.com/en-US/dotnet/core/project-sdk/msbuild-props-desktop, try right-clicking the project in Solution Explorer, then select “Edit Project File” and add two elements:

<Project Sdk="Microsoft.NET.Sdk">
  <PropertyGroup>
    . . .
    <UseWindowsForms>true</UseWindowsForms>
    <DisableWinExeOutputInference>true</DisableWinExeOutputInference>
  </PropertyGroup>
</Project>

Now the next line should work:

var t = new System.Windows.Forms.TreeView( );
