Cannot connect to dataset in ADF data flow

asked 2021-04-25T13:27:37.963+00:00

I am tring to set a data flow in ADF. The input sink from a dataset, there is a parameter in the dataset, it is defining the filename. When I do not use parameter to test connection, it is success. But if I set a parameter, it failed and throw below exception.


Connection failed
{
"Message": "ErrorCode=InvalidTemplate, ErrorMessage=Unable to parse expression 'body('DataFlowDebugExpressionResolver')?.Get links from SmallOcrUrlListTestConnection1463b7d26602d4a4d9087b926d630631e?.Output.outputfolder': expected token 'EndOfData' and actual 'Identifier'."
} - RunId: 78273469-cfdc-4a1c-8d3c-dbe415945deb

If I set the static file name, the test connection will be success.

Both way can preview data in dataset.

   Dataset code:

   {
       "name": "smallocrurllistfile",
       "properties": {
           "linkedServiceName": {
               "referenceName": "REFERENCENAME",
               "type": "LinkedServiceReference"
           },
           "parameters": {
               "filename": {
                   "type": "string",
                   "defaultValue": "smallOcrUrlList_1.tsv"
               }
           },
           "annotations": [],
           "type": "DelimitedText",
           "typeProperties": {
               "location": {
                   "type": "AzureBlobStorageLocation",
                   "fileName": {
                       "value": "@dataset().filename",
                       "type": "Expression"
                   },
                   "folderPath": "SmallOcrUrlList",
                   "container": "CONTAINERNAME"
               },
               "columnDelimiter": "\t",
               "escapeChar": "\\",
               "quoteChar": ""
           },
           "schema": [
               {
                   "type": "String"
               },
               {
                   "type": "String"
               },
               {
                   "type": "String"
               }
           ]
       }
   }


   dataflow code:

   {
       "name": "Get links from SmallOcrUrlList",
       "properties": {
           "type": "MappingDataFlow",
           "typeProperties": {
               "sources": [
                   {
                       "dataset": {
                           "referenceName": "smallocrurllistfile",
                           "type": "DatasetReference"
                       },
                       "name": "SmallOcrUrlList"
                   }
               ],
               "sinks": [
                   {
                       "dataset": {
                           "referenceName": "filteredSmallOcrUrlFile",
                           "type": "DatasetReference"
                       },
                       "name": "Output"
                   }
               ],
               "transformations": [
                   {
                       "name": "SearchKeyword"
                   }
               ],
               "script": "parameters{\n\tKeyword as string\n}\nsource(output(\n\t\timage_key as string,\n\t\timage_url as string,\n\t\tOCRText as string\n\t),\n\tallowSchemaDrift: true,\n\tvalidateSchema: false,\n\tignoreNoFilesFound: false) ~> SmallOcrUrlList\nSmallOcrUrlList filter(instr(lower(OCRText), $Keyword) > 0) ~> SearchKeyword\nSearchKeyword sink(allowSchemaDrift: true,\n\tvalidateSchema: false,\n\tfilePattern:'links[n].txt',\n\tmapColumn(\n\t\timage_url\n\t),\n\tpartitionBy('roundRobin', 2),\n\tskipDuplicateMapInputs: true,\n\tskipDuplicateMapOutputs: true,\n\theader: (array($Keyword))) ~> Output"
           }
       }
   }

B.T.W, I do this to allow the data flow to batch process files in a directory in the pipeline, so I want data flow get the input from 'GetMetadata' activitiy's output.

Please tell me how to solve this problem, thanks.

Azure Open Datasets
Azure Open Datasets
An Azure service that provides curated open data for machine learning workflows.
13 questions
Azure Data Factory
Azure Data Factory
An Azure service for ingesting, preparing, and transforming data at scale.
6,257 questions
No comments
{count} votes

1 answer

Sort by: Most helpful
  1. answered 2021-04-26T19:39:30.173+00:00
    Saurabh Sharma 17,286 Reputation points Microsoft Employee

    Hi @Junjian Xia (PACTERA TECHNOLOGIES INC) ,

    Thanks for using Microsoft Q&A !!

    I do not see any issues while using parameterized source dataset in DataFlow. You cannot directly verify the dynamic dataset source connection in DataFlow using "Test Connection". You need to go to "Data Preview" tab to preview the data and then you can pass the source dataset parameter while refreshing the data. Please refer to the below gif.

    You can add the parameter values using "Debug Settings" as well.

    Also, please make sure to pass source dataset parameter values by going to "Settings" tab of your data flow activity while referring to the corresponding dataflow from your pipeline. (Refer to the above Gif).

    Please let me know if you have any questions or still see any issues.

    Thanks
    Saurabh
