How to stick some text on an Image via a Label?

Question

Hi all,

In short: I am trying to add a text via a label on an image placed in a picturebox.
My code below is working in some case, but not always. I am using a weird number (3.16) which help most of the case, but I don't really understand why.

What I am looking for is:
1- To stick the text of the label over my Image
2- The label (coming from the class TGlass) displayed over my Image must appeared exactly as it is displayed on the screen (in my picturebox "pbCheckImage01" 400x266px)
3- My image can change in term of pixels (example: 6016x4000 or 2256x1504 or 317x212 ... with always the same ratio 1.5)
4- The size of the label can change via a personalised and limited FontDialog (size 48 to 108)

Any ideas, corrections, improvements are welcome. Hope my explanations were clear enough.

I tried with the method DrawToBitmap, but it doesn't work as I am losing pixels.
I also tried with the method MeasureString without success, but it is maybe the way to go.

Below is the code I am using to stick my label on my image.

            Dim myBitmap As Bitmap = Nothing
            Using fs As New System.IO.FileStream(myPath, System.IO.FileMode.Open, System.IO.FileAccess.Read)
                'Dim img2 As Image = Image.FromStream(fs)
                Dim img2 As Bitmap = CType(Bitmap.FromStream(fs), Bitmap)
                pbCheckImage01.BackgroundImage = img2
                Dim g As Graphics = Graphics.FromImage(img2)
                ' Text position of Label TGlass
                Dim topleft As Point
                topleft = New Point(TGlass.Left, TGlass.Top)
                ' Text content of Label TGlass
                Dim strCalendar As String = TGlass.Text
                ' Rectangle layout for the selected font
                Dim layout As New Rectangle(topleft, TGlass.Size)
                ' Rectangle position with respect of the image
                layout.X = CInt(layout.X * (img2.Height / pbCheckImage01.Height))
                layout.Y = CInt(layout.Y * (img2.Width / pbCheckImage01.Width))
                ' Text First Page
                Dim myFontSize As Integer
                myFontSize = CInt(TGlass.Font.Size * (img2.Width / pbCheckImage01.Width) / 3.16)
                Dim myFont As New Font(TGlass.Font.FontFamily, myFontSize, TGlass.Font.Style)
                Dim myBrush As New SolidBrush(TGlass.ForeColor)
                ' Drawing on Image
                g.DrawString(strCalendar, myFont, myBrush, layout.X, layout.Y)
                ' Remove the TextWindow class
                ckbYear.Checked = False
                myBitmap = img2
            End Using
            ' Update the new image on FirstPage
            pb00.BackgroundImage = myBitmap
            pb00.BackgroundImageLayout = ImageLayout.Stretch
            pb00.Size = fSizeTransfer(myBitmap.Width, myBitmap.Height, 120)
            ' Save (Replace) the Image in the right folder
            myBitmap.Save(myPath, System.Drawing.Imaging.ImageFormat.Jpeg)

And here the code of the TextWindow class TGlass.

Public Class cTextWindow

    Inherits Label ' Control Text
    ' Variable initialisation
    Dim a As Integer
    Dim b As Integer
    Dim newPoint As Point
    Public bClick As Boolean

    Public Sub New()
        ' Initialisation
        Me.Cursor = Cursors.SizeAll
        bClick = True
    End Sub

    Protected Overrides Sub OnPaint(ByVal e As System.Windows.Forms.PaintEventArgs)
        ' Draw the border of the label
        Try
            If bClick = True Then
                e.Graphics.DrawRectangle(New Pen(Brushes.Blue, 4), Me.ClientRectangle)
            Else
                e.Graphics.DrawRectangle(New Pen(Brushes.Transparent, 4), Me.ClientRectangle)
            End If
            MyBase.OnPaint(e)
        Catch ex As Exception
            MsgBox(ex.Message)
        End Try
    End Sub

    Protected Overrides Sub OnMouseDown(ByVal e As System.Windows.Forms.MouseEventArgs)
        ' Find the position of the label
        Try
            a = MousePosition.X - Me.Location.X
            b = MousePosition.Y - Me.Location.Y
        Catch ex As Exception
            MsgBox(ex.Message)
        End Try
    End Sub

    Protected Overrides Sub OnMouseMove(ByVal e As System.Windows.Forms.MouseEventArgs)
        ' Update the position of the label
        Try
            ' New location
            If e.Button = MouseButtons.Left Then
                newPoint = MousePosition
                newPoint.X -= a
                newPoint.Y -= b
                Me.Location = newPoint
            End If
            ' Raise the MouseMove event
            MyBase.OnMouseMove(e)
        Catch ex As Exception
            MsgBox(ex.Message)
        End Try
    End Sub

    Protected Overrides Sub OnMove(ByVal e As System.EventArgs)
        ' Control the position of the label
        Try
            ' Keep it inside the main PictureBox
            If Me.Location.X < 0 Then Me.Location = New Point(0, Me.Location.Y)
            If Me.Location.Y < 0 Then Me.Location = New Point(Me.Location.X, 0)
            If Me.Location.X + Me.Width > frmECalendar.pbCheckImage01.Width Then Me.Location = New Point(frmECalendar.pbCheckImage01.Width - Me.Width, Me.Location.Y)
            If Me.Location.Y + Me.Height > frmECalendar.pbCheckImage01.Height Then Me.Location = New Point(Me.Location.X, frmECalendar.pbCheckImage01.Height - Me.Height)
            ' Control to be redrawn
            'Me.Invalidate()
            Me.Update()
            ' Raise the Move event
            MyBase.OnMove(e)
        Catch ex As Exception
            MsgBox(ex.Message)
        End Try
    End Sub

    Protected Overrides Sub OnMousedoubleClick(e As MouseEventArgs)
        ' Display the label frame with a mouse click
        Try
            bClick = Not bClick
            ' Raise the MouseClick event
            MyBase.OnMouseDoubleClick(e)
            Refresh()
        Catch ex As Exception
            MsgBox(ex.Message)
        End Try
    End Sub

End Class

Answer 1

Hi @Jean-Luc Coudret ,

especially about these numbers 3 or 4 depending of the way I do it.

*(intRenderer.Width / PictureBox1.Width) * img.Width* cannot be used as font size.
In 'Button4_Click', you set TGlass.Font = New Font("Arial", 80, FontStyle.Bold)
So consider :

            Dim WidthRate = img.Width / PictureBox1.Width
            Dim myFontSize = CInt(WidthRate * 80)

Best Regards,
Xingyu Zhao
*
If the answer is helpful, please click "Accept Answer" and upvote it.
Note: Please follow the steps in our documentation to enable e-mail notifications if you want to receive the related email notification for this thread.

Answer 2

Hi @Jean-Luc Coudret ,
You can consider drawing a string directly on a PictureBox image.
For example:

        Dim bmp As Bitmap = New Bitmap("image path")
        Using g As Graphics = Graphics.FromImage(bmp)
            TextRenderer.DrawText(g, "Hello", New Font("Arial", 76, FontStyle.Bold), New Point(5, 75), Color.Red)
        End Using
        bmp.Save("image path")

Result of my test:

Also check:

1. Custom AntiAliasing with GDI+
2. Drawing smooth text and pictures on the extended glass area of your WinForm in Windows Vista

Hope them could be helpful.

Best Regards,
Xingyu Zhao
*
If the answer is helpful, please click "Accept Answer" and upvote it.
Note: Please follow the steps in our documentation to enable e-mail notifications if you want to receive the related email notification for this thread.

Answer 3

Hi,

And thanks for your help.
I did a short version of what I want to achieved in a small Apps, but I was not able to attach the zipped file.
Then, I added the main code I used in my small Apps below. The TGlass class I used is already shared in the previous post.

Note it will create a Test folder on your desktop with the various images.
Click BTN01 or BTN02, BTN04 (you can move the label) and finally BTN05 and check the created images N_img1 and N_img2 in the Test folder.
Target: I would like to have the text on the N_image in the folder as it appeared on the picturebox. It worked a bit (not perfectly) with img1, but not with img2 (text too small).

img1 size: W=6016px, H=4000px
img2 size: W=995px, H=661px

If you prefer, I can share it on Google Drive, but I will need your email address.

Public Class Form1

    Private ReadOnly TGlass As New cTextWindow
    Private myPath As String

    Private Sub Form1_Load(sender As Object, e As EventArgs) Handles MyBase.Load
        myPath = System.IO.Path.Combine(System.IO.Path.Combine(System.IO.Path.Combine(Environment.GetFolderPath(Environment.SpecialFolder.Desktop))), "Test")
        If (Not (System.IO.Directory.Exists(myPath))) Then
            System.IO.Directory.CreateDirectory(myPath)
            My.Resources.img1.Save(myPath & "\img1.jpg", System.Drawing.Imaging.ImageFormat.Jpeg)
            My.Resources.img2.Save(myPath & "\img2.jpg", System.Drawing.Imaging.ImageFormat.Jpeg)
        End If
    End Sub

    Private Sub Button1_Click(sender As Object, e As EventArgs) Handles Button1.Click
        PictureBox1.BackgroundImage = Nothing
        Dim bmp As Bitmap = New Bitmap(My.Resources.img1, PictureBox1.Size)
        PictureBox1.BackgroundImage = bmp
        'PictureBox1.Image = My.Resources.img1
        PictureBox1.BackgroundImageLayout = ImageLayout.Stretch
        Label1.Text = "W: " & My.Resources.img1.Width & " x H: " & My.Resources.img1.Height
        Label2.Text = "img1"
    End Sub

    Private Sub Button2_Click(sender As Object, e As EventArgs) Handles Button2.Click
        PictureBox1.BackgroundImage = Nothing
        Dim bmp As Bitmap = New Bitmap(My.Resources.img2, PictureBox1.Size)
        PictureBox1.BackgroundImage = bmp
        'PictureBox1.Image = My.Resources.img2
        PictureBox1.BackgroundImageLayout = ImageLayout.Stretch
        Label1.Text = "W: " & My.Resources.img2.Width & " x H: " & My.Resources.img2.Height
        Label2.Text = "img2"
    End Sub

    Private Sub Button4_Click(sender As Object, e As EventArgs) Handles Button4.Click
        PictureBox1.Controls.Remove(TGlass)
        TGlass.BackColor = Color.Transparent
        TGlass.ForeColor = Color.Red
        TGlass.AutoSize = True
        TGlass.Text = "Hello"
        TGlass.Font = New Font("Arial", 76, FontStyle.Bold)
        TGlass.Location = New Point(5, 75)
        PictureBox1.Controls.Add(TGlass)
    End Sub

    Private Sub Button5_Click(sender As Object, e As EventArgs) Handles Button5.Click
        Dim myBitmap As Bitmap = Nothing
        Using fs As New System.IO.FileStream(myPath & "\" & Label2.Text & ".jpg", System.IO.FileMode.Open, System.IO.FileAccess.Read)
            Dim img As Bitmap = CType(Bitmap.FromStream(fs), Bitmap)
            PictureBox1.BackgroundImage = img
            Dim g As Graphics = Graphics.FromImage(img)
            ' Text position of Label TGlass
            Dim topleft As Point
            topleft = New Point(TGlass.Left, TGlass.Top)
            ' Text content of Label TGlass
            Dim strCalendar As String = TGlass.Text
            ' Rectangle layout for the selected font
            Dim layout As New Rectangle(topleft, TGlass.Size)
            ' Rectangle position with respect of the image
            layout.X = CInt(layout.X * (img.Height / PictureBox1.Height))
            layout.Y = CInt(layout.Y * (img.Width / PictureBox1.Width))


            ' Text First Page
            Dim myFontSize As Integer
            myFontSize = CInt(TGlass.Font.Size * (img.Width / PictureBox1.Width) / 3.16)


            Dim myFont As New Font(TGlass.Font.FontFamily, myFontSize, TGlass.Font.Style)
            Dim myBrush As New SolidBrush(TGlass.ForeColor)
            ' Drawing on Image
            g.DrawString(strCalendar, myFont, myBrush, layout.X, layout.Y)
            myBitmap = img
        End Using
        ' Save (Replace) the Image in the right folder
        myBitmap.Save(myPath & "\N_" & Label2.Text & ".jpg", System.Drawing.Imaging.ImageFormat.Jpeg)
        PictureBox1.Controls.Remove(TGlass)
    End Sub

End Class

Thanks,
Jean-Luc

Answer 4

Hi,

I followed your advice (also with the help of this link).
It is much better, but not perfect. But I don't think now it is possible to have something perfect because of the conversion pixels to points, need to consider dpi, screen resolution... (or maybe I am wrong).
Anyway, below is the code I am using now. Note there is still something I don't understand as I need to divide by 3 or 4 (depending of the code I used) in the formula calculating myFontSize. If someone understand why, do not hesitate to tell me.

    Private Sub Button5_Click(sender As Object, e As EventArgs) Handles Button5.Click
        Dim myBitmap As Bitmap = Nothing
        Using fs As New System.IO.FileStream(myPath & "\" & Label2.Text & ".jpg", System.IO.FileMode.Open, System.IO.FileAccess.Read)
            Dim img As Bitmap = CType(Bitmap.FromStream(fs), Bitmap)
            PictureBox1.BackgroundImage = img
            Dim g As Graphics = Graphics.FromImage(img)

            ' Text position of Label TGlass
            Dim topleft As Point
            topleft = New Point(TGlass.Left, TGlass.Top)
            ' Text content of Label TGlass
            Dim strCalendar As String = TGlass.Text
            ' Text ForeColor
            Dim myColor As Color
            myColor = TGlass.ForeColor
            ' Rectangle layout for the selected font
            Dim layout As New Rectangle(topleft, TGlass.Size)
            ' Rectangle position with respect of the image
            layout.X = CInt(layout.X * (img.Height / PictureBox1.Height))
            layout.Y = CInt(layout.Y * (img.Width / PictureBox1.Width))

            ' Text First Page
            Dim intRenderer As SizeF
            Dim myFontSize As Integer
            'intRenderer = TextRenderer.MeasureText(strCalendar, New Font(TGlass.Font.FontFamily, TGlass.Font.Size, TGlass.Font.Style, GraphicsUnit.Pixel))
            'myFontSize = CInt((intRenderer.Width / PictureBox1.Width) * img.Width / 3)
            intRenderer = TextRenderer.MeasureText(strCalendar, TGlass.Font)
            myFontSize = CInt((intRenderer.Width / PictureBox1.Width) * img.Width / 4)
            ' New Font for Text applied on Image
            Dim myFont As New Font(TGlass.Font.FontFamily, myFontSize, TGlass.Font.Style)
            ' Drawing on Image
            TextRenderer.DrawText(g, strCalendar, myFont, New Point(layout.X, layout.Y), myColor)

            myBitmap = img
        End Using
        ' Save (Replace) the Image in the right folder
        myBitmap.Save(myPath & "\N_" & Label2.Text & ".jpg", System.Drawing.Imaging.ImageFormat.Jpeg)
        PictureBox1.Controls.Remove(TGlass)
    End Sub
