My PC has a 2tb HDD with windows on it. I bought a 2tb m.2 nvme SSD with the intention of cloning the HDD onto the SSD, however, when I installed the SSD into the PC it will boot to the windows login screen then reboot to the automatic repair/recovery screen. The PC boots as normal when the SSD is removed.
How can I fix this? I have tried: removing cmos battery, reseating ram, switched between CMS/UEFI, resetting boot order in BIOS
Locked Question. This question was migrated from the Microsoft Support Community. You can vote on whether it's helpful, but you can't add comments or replies or follow the question.
These 1024 kb mean not free space on disk but the size of unpartitioned space.
Could it be your SSD was initialized as MBR already, but partitions were not created or were deleted? In yes. clean it from diskpart tool, disable CSM, set SSD as primary boot drive, and install Windows.
I had to take a photo of the screen as I can’t actually get into windows. I believe disk 0 is my HDD boot drive but I’m not sure why it says it has 1024kb free. It has about 100GB free.
Please run diskpart, in this tool run
lis dis
command and show the result.
I haven’t got as far as cloning, it’s a fresh ssd. When the ssd is in the pc it refuses to go to windows and keeps rebooting until it eventually goes to recovery.
Hi Connor,
My name is Igor, it's a pleasure for me to help others and I'll do all my best to help you.
What tool did you use for cloning?
What happens when you disconnect not SSD but HDD?
Please run diskpart, in this tool run
lis dis
command and show the result.
