I have setup some distributed applications and they display without issues in the windows console however in the web console I get the following error. Not sure how to get around this. Thanks.
Rene
A family of System Center products that provide infrastructure monitoring, help ensure the predictable performance and availability of vital applications, and offer comprehensive monitoring for datacenters and cloud, both private and public.
Answer accepted by question author
As per error said, modify the folder "TempImages" folder under e:\operations Manager\WebConsole\MonitoringView, the path is depend on your webconsole installation path, permission.
From my experience, i just grant the "Authenticated Users" permission to read and write.
Roger
Thank you, Its working now.
@Rene Paquin , Thanks for the response. I am glad to heat that the issue is resolved. If there's anything else we can help, feel free to post in Q&A to discuss together.
Thanks for your time and have a nice day!
,
That looks like the "Known issue" at the end of that article : https://kevinholman.com/2021/03/31/ur3-for-scom-2019-step-by-step/
So as Roger said, granting the "write" permission to authenticated users on that folder should fix your issue.
@Rene Paquin , For the error, it seems current the user didn't have enough permission on the folder. Here, we suggest to configure the permission to see if it is working.
https://learn.microsoft.com/en-us/system-center/scom/deploy-install-web-console?view=sc-om-2019#to-configure-permissions-inheritance-for-the-web-console
Hope it can help.
