mkosi config to build a bootable OS disk for confidential VM

Question

I want to create a bootable OS image using mkosi that I can use to create a confidential VM. My mkosi.conf so far is:

[Distribution]
Distribution=ubuntu
Release=jammy
Architecture=x86-64
Repositories=main,universe,restricted,multiverse

[Build]
ToolsTree=default
[Content]
Bootable=yes
Bootloader=uki
Initrds=./initrd
InitrdPackages=cryptsetup-initramfs
               libdevmapper1.02.1
               dmsetup
               kmod
               busybox-initramfs

RootPassword=root
Packages=systemd
         kmod
         udev
         dbus
         tzdata
         tpm2-tools
         linux-azure
         linux-headers-azure
         grub-efi-amd64
         grub-efi-amd64-bin
         linux-firmware
         apparmor
         apparmor-utils
         iptables-persistent
         netfilter-persistent
         ca-certificates
         vim
         docker.io
         docker-compose

KernelCommandLine="console=ttyS0 systemd.volatile=overlay"

[Runtime]
Firmware=uefi-secure-boot
TPM=true

[Output]
Format = disk
ManifestFormat = json

and my partitions are pretty simple:

$ cat mkosi/rootfs/mkosi.rcat mkosi/rootfs/mkosi.repart/00-esp.conf
[Partition]
Type=esp
Format=vfat
CopyFiles=/efi:/
CopyFiles=/boot:/
SizeMinBytes=1G
SizeMaxBytes=1G

$ cat mkosi/rootfs/mkosi.repart/12-root.conf
[Partition]
Type=root
Format=ext4
CopyFiles=/
Minimize=guess
ExcludeFilesTarget=/var/
ReadOnly=yes

When I boot the resulting image using qemu locally, on a Ubuntu Azure VM:

sudo qemu-system-x86_64     -enable-kvm     -cpu host     -smp 6     -m 4096     -bios /usr/share/qemu/OVMF.fd     -drive format=raw,file=/mnt/scratch/os_disk_azure.raw     -nographic

I get a kernel panic:

[    1.128508] /dev/root: Can't open blockdev
[    1.129344] VFS: Cannot open root device "" or unknown-block(0,0): error -6
[    1.130693] Please append a correct "root=" boot option; here are the available partitions:

this is very likely due to incorrect initramfs. But note that this works when linux-generic is used instead of linux-azure i.e. this image boots up fine in a generic kernel: 5.15.0-143-generic but fails on the azure linux kernel: 6.8.0-1031-azure.

Are there additional parameters I need to add to the mkosi.conf file? I am assuming an Azure image i.e. 6.8.0-1031-azure is needed to boot up a confidential VM.

Answer 1

Hi Hitesh Bhagchandani

Your configuration is precise. To make sure Secure Boot works seamlessly for confidential VMs, here are a few key validations and suggestions:

Your Validation section looks solid. Just ensure:

• MOK.priv and MOK.crt are valid PEM-encoded key and certificate files.
• They are not expired and match each other.
• You generated them using mkosi genkey or equivalent tooling.

Since you're using:

Bootloader=grub

ShimBootloader=signed

UnifiedKernelImages=false

Make sure:

• The signed shim binary is present and correctly installed in the ESP.
• GRUB is properly chained from shim and signed if needed.
• Your ESP partition includes /EFI/BOOT/BOOTX64.EFI pointing to shim.

Hope this helps!

Please Let me know if you have any queries.

Answer 2

Hi Hitesh Bhagchandani,
Confidential VMs (CVMs) in Azure should ideally run the Azure-tuned kernel, such as linux-azure, especially for support of features like SEV-SNP, TDX, TPM, measured boot, and UEFI Secure Boot.

Kernel panic - not syncing: VFS: Unable to mount root fs on unknown-block(0,0) https://learn.microsoft.com/en-us/troubleshoot/azure/virtual-machines/linux/linux-kernel-panic-troubleshooting#prerequisites

This error occurs because of a recent system update (kernel). It's most commonly seen in RHEL-based distributions. You can identify this issue from the Azure serial console. You'll see the following error message:

1. "Kernel panic - not syncing: VFS: Unable to mount root fs on unknown-block(0,0)"

This kind of error indicates that the initramfs file isn't generated, the GRUB configuration file has the initrd entry missing after a patching process, or a GRUB manual misconfiguration.

Before rebooting a server, we recommend validating the GRUB configuration and /boot contents if there's a kernel update by running one of the following commands. It's important to ensure the update is done and there are no missing initramfs files.

ls -l /bootThe error says: You must add the root= parameter:KernelCommandLine="console=ttyS0 systemd.volatile=overlay root=/dev/sda2"

Replace /dev/sda2 with the actual partition where your root filesystem is — you can check this by running lsblk on the raw image after building.

[https://learn.microsoft.com/en-us/troubleshoot/azure/virtual-machines/linux/linux-kernel-panic-troubleshooting#scenario-1-kernel-panic-occurs-at-boot-time]

https://learn.microsoft.com/en-us/troubleshoot/azure/virtual-machines/linux/kernel-related-boot-issues#missing-initramfs

https://learn.microsoft.com/en-us/troubleshoot/azure/virtual-machines/linux/linux-kernel-panic-troubleshooting#how-to-identify-a-kernel-panic

Hope it helps!

Let me know if you have any further queries!
