Auto ML model endpoint deployment (Container Instance): Error No module named 'azureml.api'

Question

Auto ML model endpoint deployment (Container Instance): Error No module named 'azureml.api'

Leo, Sabato 6

Hi,

I am trying to deploy a model trained using AutoML directly from the Portal but the deployment to Container Instance fails. From the logs I can read the errors reported below.

I am not sure what's the problem, it only appeared recently and fun fact is that if I try to deploy a model that was trained about 10 days ago it works without problem.
Did anything change in the meantime? What am I missing?

Exception in worker process
Traceback (most recent call last):
File "/var/azureml-server/routes_common.py", line 37, in <module>
from azureml.api.exceptions.ClientSideException import ClientSideException
ModuleNotFoundError: No module named 'azureml.api'

and

Traceback (most recent call last):
File "/azureml-envs/azureml_058f846b7dd22d1daecb37981c0969bb/lib/python3.6/site-packages/gunicorn/arbiter.py", line 589, in spawn_worker
worker.init_process()
File "/azureml-envs/azureml_058f846b7dd22d1daecb37981c0969bb/lib/python3.6/site-packages/gunicorn/workers/base.py", line 134, in init_process
self.load_wsgi()
File "/azureml-envs/azureml_058f846b7dd22d1daecb37981c0969bb/lib/python3.6/site-packages/gunicorn/workers/base.py", line 146, in load_wsgi
self.wsgi = self.app.wsgi()
File "/azureml-envs/azureml_058f846b7dd22d1daecb37981c0969bb/lib/python3.6/site-packages/gunicorn/app/base.py", line 67, in wsgi
self.callable = self.load()
File "/azureml-envs/azureml_058f846b7dd22d1daecb37981c0969bb/lib/python3.6/site-packages/gunicorn/app/wsgiapp.py", line 58, in load
return self.load_wsgiapp()
File "/azureml-envs/azureml_058f846b7dd22d1daecb37981c0969bb/lib/python3.6/site-packages/gunicorn/app/wsgiapp.py", line 48, in load_wsgiapp
return util.import_app(self.app_uri)
File "/azureml-envs/azureml_058f846b7dd22d1daecb37981c0969bb/lib/python3.6/site-packages/gunicorn/util.py", line 359, in import_app
mod = importlib.import_module(module)
File "/azureml-envs/azureml_058f846b7dd22d1daecb37981c0969bb/lib/python3.6/importlib/init.py", line 126, in import_module
return _bootstrap._gcd_import(name[level:], package, level)
File "<frozen importlib._bootstrap>", line 978, in _gcd_import
File "<frozen importlib._bootstrap>", line 961, in _find_and_load
File "<frozen importlib._bootstrap>", line 950, in _find_and_load_unlocked
File "<frozen importlib._bootstrap>", line 655, in _load_unlocked
File "<frozen importlib._bootstrap_external>", line 678, in exec_module
File "<frozen importlib._bootstrap>", line 205, in _call_with_frames_removed
File "/var/azureml-server/entry.py", line 1, in <module>
import create_app
File "/var/azureml-server/create_app.py", line 4, in <module>
from routes_common import main
File "/var/azureml-server/routes_common.py", line 39, in <module>
from azure.ml.api.exceptions.ClientSideException import ClientSideException
ModuleNotFoundError: No module named 'azure.ml'

GiftA-MSFT 11,176 Reputation points

2021-08-13T04:14:36.833+00:00

Hi, thanks for reaching out. Can you share more details about your training environment?
Leo, Sabato 6 Reputation points

2021-08-13T05:58:38.007+00:00
Sure,

i am using autoML, therefore I do not manage the environment.
If I looked at the outputs folder of the model I want to deploy I see the following conda enviroment and environment dependencies files.
I copy paste here the content of the conda env file for reading convenience. For the environment dependencies please refer to the attachment:

Conda environment specification. The dependencies defined in this file will

be automatically provisioned for runs with userManagedDependencies=False.

Details about the Conda environment file format:

https://conda.io/docs/user-guide/tasks/manage-environments.html#create-env-file-manually

name: project_environment
dependencies:

The python interpreter version.

Currently Azure ML only supports 3.5.2 and later.

python=3.6.2

pip:

azureml-train-automl-runtime==1.33.0

inference-schema

azureml-interpret==1.33.0

azureml-defaults==1.33.0

numpy>=1.16.0,<1.19.0

pandas==0.25.1

scikit-learn==0.22.1

py-xgboost<=0.90

fbprophet==0.5

holidays==0.9.11

psutil>=5.2.2,<6.0.0
channels:

anaconda

conda-forge
I

122867-conda-env-v-1-0-0-yml.txt 123011-env-dependencies-json.txt

3 answers

Your answer

GiftA-MSFT 11,176 Reputation points

2021-08-13T04:14:36.833+00:00

Hi, thanks for reaching out. Can you share more details about your training environment?
Leo, Sabato 6 Reputation points

2021-08-13T05:58:38.007+00:00

Sure,

i am using autoML, therefore I do not manage the environment.
If I looked at the outputs folder of the model I want to deploy I see the following conda enviroment and environment dependencies files.
I copy paste here the content of the conda env file for reading convenience. For the environment dependencies please refer to the attachment:

Conda environment specification. The dependencies defined in this file will

be automatically provisioned for runs with userManagedDependencies=False.

Details about the Conda environment file format:

https://conda.io/docs/user-guide/tasks/manage-environments.html#create-env-file-manually

name: project_environment
dependencies:

The python interpreter version.

Currently Azure ML only supports 3.5.2 and later.

python=3.6.2

pip:

azureml-train-automl-runtime==1.33.0

inference-schema

azureml-interpret==1.33.0

azureml-defaults==1.33.0

numpy>=1.16.0,<1.19.0

pandas==0.25.1

scikit-learn==0.22.1

py-xgboost<=0.90

fbprophet==0.5

holidays==0.9.11

psutil>=5.2.2,<6.0.0
channels:

anaconda

conda-forge
I

122867-conda-env-v-1-0-0-yml.txt 123011-env-dependencies-json.txt

Answer 1

romungi-MSFT 48,906 Microsoft Employee Moderator

@Leo, Sabato I think this is because of a recent change in the SDK, release notes are mentioned here.

This change is causing an issue:

azureml-defaults
We are removing the dependency azureml-model-management-sdk==1.0.1b6.post1 from azureml-defaults.

An issue is also reported on a different github repo.

The workaround for now is to update your conda environment yaml file to include the package azureml-model-management-sdk under pip after azureml-defaults

I hope this helps.

Leo, Sabato 6 Reputation points

2021-08-13T07:57:09.587+00:00

Cool thanks, I suspected something like that :)

Since I am new to Azure ecosystem, is there any way that I could modify the yaml file and trigger the deployment from the portal or using the SDK is the only available way at the moment?
Leo, Sabato 6 Reputation points

2021-08-13T08:21:02.497+00:00

Actually I found a way using Azure Storage Explorer.

Thanks for your help :)
romungi-MSFT 48,906 Reputation points Microsoft Employee Moderator

2021-08-13T08:47:35.807+00:00

I don't see version 1.32.0 in this package release history. May be you could try to run again without the specific version you mentioned?
Leo, Sabato 6 Reputation points

2021-08-13T09:05:18.237+00:00

You are right I made a mistake.

I used azureml-model-management-sdk==1.0.1b6.post1 but at the end it failed as well.
Leo, Sabato 6 Reputation points

2021-08-13T09:06:43.72+00:00

So I tried with the wrong version of the package before.

Howere using the rghht one azureml-model-management-sdk==1.0.1b6.post1 does not solve the problem.
Leo, Sabato 6 Reputation points

2021-08-13T09:32:55.467+00:00

I also tried to roll back to the previous version of azureml-defaults (same environment that works for previous models) but it fails as well.

Maybe only changing the yaml file though Azure Store Explorer is not enough?
Leo, Sabato 6 Reputation points

2021-08-13T10:19:33.34+00:00

Final attempt with the modified yml below also gave the same problem.

It seams that modifying the yaml file in the outputs folder of the model I want to deploy has no effect as if dependencies are read from somewhere else.
Any idea?

pip:
azureml-train-automl-runtime==1.33.0
inference-schema
azureml-interpret==1.33.0
azureml-defaults==1.33.0
azure-ml-api-sdk
azureml-model-management-sdk
romungi-MSFT 48,906 Reputation points Microsoft Employee Moderator

2021-08-13T10:39:35.533+00:00

@Leo, Sabato I think with automl the base images need to be updated. I am checking internally if there is a workaround for this issue until this is fixed. Thanks.
romungi-MSFT 48,906 Reputation points Microsoft Employee Moderator

2021-08-17T04:31:14.697+00:00

@Leo, Sabato Could you please try the scenario again as a hot fix has been deployed to all regions a few hours ago. Please let us know if there is any issue.
Leo, Sabato 6 Reputation points

2021-08-17T06:42:11.237+00:00

@romungi-MSFT Also this scenario (modify the yml file using Storage Manager, upload it to the cloud and trigger the deploy from the Portal) fails.

However I got a different error this time:

Starting gunicorn 20.1.0
Listening at: http://127.0.0.1:31311 (11)
Using worker: sync
worker timeout is set to 300
Booting worker with pid: 38
SPARK_HOME not set. Skipping PySpark Initialization.
Generating new fontManager, this may take some time...

Answer 2

Hello

I also got in to this issue 3 days back when I tried to deploy a pytorch based recommender model with a newer variation. I tried with both the recommended solution - explicitly installing either the library azure-ml-api-sdk. or azureml-model-management-sdk

Both landed on this new error

message": "Error in entry script, AttributeError: Can't get attribute 'new_block' on <module 'pandas.core.internals.blocks' from '/azureml-envs/azureml_a9071edb452f2dedb0ab60b9e2450ad3/lib/python

Somewhere I found that Pandas 1.3 is causing this error and 1.2 would solve it- I tried with Pandas 1.2 / 0.25 also but the "Cant get Attribute "new block" stays --

I had to reschedule a planned demo as I never thought I would get this problem for a very similar model that is running in production.

Any help is much appreciated -

Thanks

Answer 3

Radhakrishnan, Ramaiah 1

Update

The pandas 1.2 library is working for this issue- Originally I was using it as a reference in the YML file during deployment - But I tried changing it in my environment and ran all the scripts including train and validate scripts and now the deployment worked. Hope this saves sometime for people out there who struggled like me

Thank you
