Microsoft DHCP server not sending offer packet to notebook request

kaushal parab 26 Reputation points
2020-07-27T09:30:18.82+00:00

Hi,

i have configurd a dhcp scope in windows 2019 and did - ipconfig /renew on notebook. it shows me error with " unable to contact your DHCP server. Request has time out."

when i run wireshark on notebook then i can only see " Discover " packet has been sent from notebook but could not any " offer " packet in the wireshark.

i also run wireshark on the Windows 2019 dhcp server, but in the server there is not DHCP request at all.

Can anyone give some insight where could be the issue pls? Thanks a lot.

Windows for business Windows Client for IT Pros Networking Network connectivity and file sharing

1 answer

Sort by: Most helpful
Most helpful Newest Oldest
  1. Anonymous
    2020-07-28T02:27:01.723+00:00

    Hi ,

    Welcome to our new Q&A platform.

    >>when i run wireshark on notebook then i can only see " Discover " packet has been sent from notebook but could not any " offer " packet in the wireshark.

    Before we go further, I would like to confirm the following questions:

    1. Was the DHCP server on the same IP segment with client?
    2. Did you use any network device?

    Please first check if DHCP server receives the DHCP Discover message from the client.

    If not, check intermediate device like relay agent.

    If DHCP server receives the DHCP Discover message from the client, then you need to check if DHCP server send a DHCP offer message.

    If not, we need to troubleshoot from server side.

    Hope this can help you understand better.

    Best Regards,

    Candy

    2 people found this answer helpful.
