Help with "STRING" value in Alert Description

Question

Basic how to question hoping someone can help me with. Trying to show number of running Process for a Process Monitor but when i use the ActiveInstance Count parameter it asks for a STRING value to be supplied.

I thought it was the actual "process name" but that doesnt work and the alert comes up blank for Instance Count.

Can someone tell me what is required here:

---

Moved from: System Center Operations Manager

Answer 1

Hi,

You’re on the right track – the ActiveInstanceCount value is correct, it’s just the XPath that needs one more piece.

The ProcessInformationProvider returns a set of processes under:

ProcessInformations/ProcessInformation

Each ProcessInformation node has a ProcessName and an ActiveInstanceCount. Because there can be more than one process, SCOM adds this placeholder:

[ProcessName=<STRING>]

to tell you “filter this collection by a string value”.

You need to replace <STRING> with the actual process name in quotes (XPath string comparison), for example:

$Data/Context/ProcessInformations/ProcessInformation[./ProcessName='myprocess.exe']/ActiveInstanceCount$

Key points:

• Keep the [ ./ProcessName = '…' ] part – the ./ and single quotes are important.
• Just putting ProcessName=myprocess.exe without quotes will result in no match, so the alert text shows a blank value.
• Use the exact name that the monitor is configured for (including .exe if that’s how you defined it).

After you change your alert description to something like:

Process 'myprocess.exe' is running $Data/Context/ProcessInformations/ProcessInformation[./ProcessName='myprocess.exe']/ActiveInstanceCount$ times.

the alert should display the correct instance count.

---

Best Regards

Stoyan Chalakov

"If my response was useful, please consider marking it as the answer. It keeps the forum clean, structured, and more helpful for everyone. Thank you for supporting the community."
